Mastech MS6503 Manuel utilisateur

HUMIDITY TEMPERATURE METER

INSTRUCTION MANUAL

HUMIDITY TEMPERATURE METER

INSTRUCTION MANUAL CONTENTS

CONTENTS

TITLE PAGE

1. SAFETY INFORMATION

……………………………………………………

1.1 PRELIMINARY

……………………………………………………

1.2 DURING USE

……………………………………………………

1.3 SYMBOLS

……………………………………………………

1.4 MAINTENANCE

……………………………………………………

2. DESCRIPTION

……………………………………………………

2.1 NAMES OF COMPONENTS

……………………………………………………

2.2 SYMBOL DEFINITION

……………………………………………………

2.3 BUTTONS ELUCIDATION

……………………………………………………

3. SPECIFICATIONS

……………………………………………………

3.1 GENERAL SPECIFICATIONS

……………………………………………………

HUMIDITY TEMPERATURE METER

INSTRUCTION MANUAL CONTENTS

3.2 ELECTRICAL SPECIFICATIONS

……………………………………………………

4. OPERATING INSTRUCTION

……………………………………………………

4.1 POWER-UP

……………………………………………………

4.2 HUMIDITY MEASUREMENT

……………………………………………………

4.3 TEMPERATURE MEASUREMENT

……………………………………………………

4.4 SELECTING THE TEMPERATURE SCALE

……………………………………………………

4.5 MAX/MIN OPERATION

……………………………………………………

4.6 READ HOLD

……………………………………………………

4.7 TIMER OPERATION

……………………………………………………

4.8 BACK LIGHT

……………………………………………………

4.9 AUTO POWER OFF

……………………………………………………

4.10 DIGITAL OUTPUT

……………………………………………………

4.11 BATTERY REPLACEMENT

……………………………………………………

4.12 USE THE TRIPOD CONNECTOR

……………………………………………………

HUMIDITY TEMPERATURE METER

INSTRUCTION MANUAL CONTENTS

5. ENCLOSED SOFTWARE PCLINK

……………………………………………………

5.1 ILLUMINATION FOR INSTALLATION

……………………………………………………

5.2 INSTALLATION OF PCLINK

……………………………………………………

5.3 EXECUTION OF PCLINK

……………………………………………………

5.4 TIMELY DATA GRAPH AND SHEET WINDOW

……………………………………………………

6. ACCESSORIES

……………………………………………………

6.1 SUPPLIED WITH THE MULTIMETER

……………………………………………………

6.2 OPTIONAL ACCESSORIES

……………………………………………………

HUMIDITY TEMPERATURE METER

INSTRUCTION MANUAL SAFETY INFORMATION

1. SAFETY INFORMATION

Read the following safety information carefully before attempting to operate or service the meter. Use the

meter only as specified in this manual, otherwise, the protection provided by the meter may be impaired.

With proper use and care, your digital meter will provide you satisfactory service for years.

1.1 PRELIMINARY

1.1.1 When the meter is delivered, check that it has not been damaged in transit.

1.1.2 When poor condition under harsh preservation or shipping conditions caused, inspect and confirm this

meter without delay.

1.2 DURING USE

1.2.1 Operate the meter under the condition of stated temperature and humidity.

1.2.2 If any faults or abnormalities are observed, the meter can not be used any more and it has to be checked

out.

1.2.3 Please do not store or use meter in areas exposed to direct sunlight, high temperature, humidity or

- 1 -

HUMIDITY TEMPERATURE METER

INSTRUCTION MANUAL SAFETY INFORMATION

condensation.

1.2.4 Don't touch or manipulate the sensor.

1.2.5 Don't expose the sensor to direct light, this causes a false reading.

1.2.6 Don't expose the sensor to static electricity.

1.2.7 Never dip the sensor directly in the water or impregnant.

1.3 SYMBOLS

Comply with EMC

Important safety information, refer to the operating manual.

1.4 MAINTENANCE

1.4.1 Repairs or servicing not covered in this manual should only be performed by qualified personnel.

1.4.2 If it exists dust on the sensor, use clean air to blow it away or use alcohol to scrub it away lightly. Do not

use other chemical impregnant for scrubbing.

1.4.3 Do not use abrasives or solvents on the meter, use a damp cloth and mild detergent only.

- 2 -

HUMIDITY TEMPERATURE METER

INSTRUCTION MANUAL SAFETY INFORMATION

1.4.4 Always set the power switch to the OFF position when the meter is not in use.

1.4.5 If the meter is to be stored for a long period of time, the batteries should be removed to prevent damage

to the unit.

- 3 -

HUMIDITY TEMPERATURE METER

INSTRUCTION MANUAL DESCRIPTION

2. DESCRIPTION

- This meter is a digital Humidity/Temperature meter for use a polymer capacitive and semiconductor sensor.

- This meter is a portable professional measuring instrument with large LCD and back light for easily reading.

- This meter can be connected with the computer for large recording of measuring data, analysis and printing,

etc.

- This meter has function of data hold.

- This meter has function for measurement of MAX/MIN value.

- When using, it can show ranges engineering unit enunciators measuring results.

- This meter has function of auto power off.

- Low battery indication are provided.

2.1 NAMES OF COMPONENTS

⑴

Dust mask

⑵

Sensor probe

⑶

AC power adapter connector

- 4 -

HUMIDITY TEMPERATURE METER

INSTRUCTION MANUAL DESCRIPTION

(1)

(2)

(3)

(4)

(5)

(6)

(7)

(8)

(9)

(10)

(11)

(12)

(13)

(14)

(15)

- 5 -

HUMIDITY TEMPERATURE METER

INSTRUCTION MANUAL DESCRIPTION

⑷

RS-232 Digital output connector

⑸

Tripod connector

⑹

Hang Ring

⑺

LCD display

⑻

“ ”

→

→→

→

ON/OFF button

⑼

“ ”

→

→→

→

Back light button

⑽

“

℉

℉℉

℉

”

→

→→

→

Fahrenheit control button

⑾

Battery cabinet cover

⑿

“

℃

℃℃

℃

”

→

→→

→

Centigrade control button

⒀

“MAX/MIN”

→

→→

→

MAX, MIN function control button

⒁

“TIMER”

→

→→

→

Timer display button

⒂

“HOLD”

→

→→

→

HOLD button

- 6 -
