M200 V2 3D Printer
User's Manual
2
CONTENTS
Welcome ..................................................................................................................... 3
SAFETY WARNINGS AND GUIDELINES
....................................................................... 3
FEATURES
.................................................................................................................... 4
PACKAGE CONTENTS ............................................................................................... 5
PRODUCT OVERVIEW
.................................................................................................... 6
SETUP
.......................................................................................................................... 7
SOFTWARE INSTALLATION AND SETUP
.................................................................. 10
SPECIFICATIONS
....................................................................................................... 18
REGULATORY COMPLIANCE
.................................................................................... 19
3
Welcome
Thank you for purchasing M200 V2 3d printer from Malyan! Wish you can enjoy your
time with your imagination! For technical support, please contact us via email at
SAFETY WARNINGS AND GUIDELINES
Be careful not to damage the printing surface on the build plate.
Do not remove the insulating tape on the extruder nozzle.
Take care to avoid touching hot parts, including heat blocks, extruder nozzle,
extruded filament, and the heated build plate.
Keep the printer and all accessories out of reach of children.
Do not remove or disconnect the USB cable when printing from a computer.
Do
not
pull
or
twist
t
he
black
ca
ble
at
any
ti
me
.
Do not force or tear anything when during unpacking and setup. This may cause
damage to the printer and/or its accessories.
Do not reach inside the printer during operation.
Always allow the printer and extruded filament to cool before reaching inside.
Ensure that the printer is turned off and unplugged from its power source before
making repairs or performing service.
Do not install this device on an unstable surface where it could fall and cause either
personal injury or damage to the device and/or other equipment.
Do not subject the product to extreme force, shock, or fluctuations in temperature
or humidity.
This device is intended for indoor use only.
4
Do not expose this device to water or moisture of any kind. Do not place drinks or
other containers with moisture on or near the device. If moisture does get in or on
the device, immediately unplug it from the power outlet and allow it to fully dry
before reapplying power.
Do not touch the device, the power cord, or any other connected cables with wet
hands.
Use only in a well-ventilated area. Do not use in close, confined spaces.
Prior to operation, check the unit and power cord for physical damage. Do not use if
physical damage has occurred.
Before plugging the unit into a power outlet, ensure that the outlet provides the
same type and level of power required by the device.
Unplug this device from the power source when not in use.
Take care to prevent damage to the power cord. Do not allow it to become
crimped, pinched, walked on, or become tangled with other cords. Ensure that the
power cord does not present a tripping hazard.
Never unplug the unit by pulling on the power cord. Always grasp the connector
head or adapter body
FEATURES
Single Extruder Head
Can print PLA, ABS, Wood, Copper Fill, Steel Fill, Bronze Fill, and other materials
Open frame design for ease of use and maintenance
Includes memory card with Cura, Repetier-Host, and a sample 3D model
Can print using USB connection, Wi-Fi® connection, or memory card
5
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items
listed below. If anything is missing or damaged, please contact us for a replacement.
1x 3D printer
1x Filament Rack
1x Plastic Scraper
1x USB Cable
1x Memory
Card
1x Hex Wrench
1x Power Adapter
1x AC power cord
6
PRODUCT OVERVIEW
1. Feed Mechanism
2. Filament Rack
3. Extruder
4. LCD Screen
5. USB port and memory card slot
6. Input Power Jack and Power Switch
7
SETUP
Perform the following steps to prepare the printer for use.
1. Remove the printer from its packaging and place it on a flat, stable surface with plenty
of ventilation and a nearby AC power outlet.
2. Open the Accessories box and remove the Filament
Rack. Slide the tab at the flat end into the slot on the
left side of the printer frame.
3. Ensure that the power switch on the rear panel is in
the OFF position (O side depressed). Plug the AC
Power Adapter into the power input jack on the printer.
Next, plug one end of AC Power Cable into the the AC power adapter, then plug the
other end into a nearby AC power outlet.
4. Insert the included memory card into the slot on the right side of the printer.
5. Turn the printer on by depressing the I side of the power switch on the rear panel.
6. Once the printer has initialized and the home
page is displayed, touch the Preheat button to
enter the Preheat Menu.
7. Touch the Nozzle button, then set the
temperature of the nozzle to the value
appropriate for the type of filament being
printed.
8. Touch the Bed button, then set the
temperature of the build plate to the value
appropriate for the type of filament being
printed.
9. Touch the Start button to start preheating the
nozzle and build plate. Once the target temperatures are reached, the button will
change to Stop Preheat and the displayed nozzle and bed temperatures should be at
or near your target values.
8
10. While the printer is heating, open your filament. Using a pair of scissors or side
cutters, diagonally snip the end of the filament to make a point, as shown in the
images below.
11. Using the control wheel, navigate to the Move menu, then select the Z Axis
option and press the wheel. Turn the control wheel counterclockwise to raise the
extruder off the build platform.
12. Place the filament reel on the filament rack on the
left side of the printer.
13. While squeezing the lever on the feed mechanism,
insert the filament and push it into the opening.
Keep pushing until you feel resistance as it hits the
extruder, then release the lever.
14. Using the control wheel, highlight the Extruder
entry on the Move menu. Press the control wheel,
then turn it counterclockwise to feed filament into
the extruder. Continue until filament starts to
extrude out of the nozzle. Wait until filament is no
longer coming out of the nozzle.
9
15. Using the included plastic scraper, clean the extruded filament from the nozzle and
build platform.
16. Using the control wheel, select the Print option from the main menu. The printer will
read the contents of the memory card and display them on screen. Highlight the
cat.gcode file, then press the control wheel to start printing the model.
17. Compare the first layer with the images in the table below to determine whether the
build platform needs to be leveled or not. If it does need adjustment, turn off the
printer and re-adjust the platform height as indicated.
Keep repeating this process
until the result is correct.
Wrong
The nozzle is too far from the
platform. This can result in the
extruded material not sticking to the
build platform.
Correct
The nozzle is at the correct
height above the platform.
Wrong
The nozzle is too close to the
platform. This can result in damage
to the nozzle and build platform.
10
SOFTWARE INSTALLATION AND SETUP
As you've seen, you can print a model directly from a gcode file on the memory
card,
you can download the gcode files you like from the Internet and print them directly.
However, some users would like to create their own model using an open source
program, such as Cura or Repetier-Host, which are pre-installed on the memory card
that comes with the printer.
Installing Cura
1. Use a card reader to read the contents in the included memory card. Locate and
double-click the Cura_15.04.6.exe file to start the setup program.
2. Choose a new location for the program files or accept the default (recommended).
Click Next button to continue.
