LuxaFlex LUMINETTE Dessin dimensionnel

ISSUE DATE: FEBRUARY 2018 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: NOVEMBER 2015 APPROVED BY: S. GONZALEZ PAGE 1 OF 38

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

LUMINETTE

PRIVACY SHEERS

ISSUE DATE: FEBRUARY 2018 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: NOVEMBER 2015 APPROVED BY: S. GONZALEZ PAGE 2 OF 38

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

ISSUE DATE: NOVEMBER 2015 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: JANUARY 2011 APPROVED BY: S. GONZALEZ PAGE 2 OF 25

LUMINETTE®Privacy Sheers - Diagram

Standard Parts

201802S12V01

ISSUE DATE: FEBRUARY 2018 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: NOVEMBER 2015 APPROVED BY: S. GONZALEZ PAGE 3 OF 38

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

ISSUE DATE: NOVEMBER 2015 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: JANUARY 2011 APPROVED BY: S. GONZALEZ PAGE 3 OF 25

LUXAFLEX®LUMINETTE®

Privacy Sheers offer an

inspired, elegant alternative to

the traditional curtain with its

innovative design.

Luminette Privacy Sheers are a patented window covering

providing a unique take on light and privacy control. The sheer

fabric face diffuses light coming into the house and soft fabric

vanes rotate for privacy and light control. Perfect for large windows

and sliding glass doors.

CLEARLY APPEALING

ISSUE DATE: FEBRUARY 2018 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: NOVEMBER 2015 APPROVED BY: S. GONZALEZ PAGE 4 OF 38

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

ISSUE DATE: NOVEMBER 2015 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: JANUARY 2011 APPROVED BY: S. GONZALEZ PAGE 4 OF 25

Luminette®Privacy Sheers Hardware Colours

The exclusive SOFTTRAK®Scissor Hardware System provides incredibly smooth and reliable operation. The header conceals the

patented operating system as the Luminette Privacy Sheers traverse along the sleek, low proﬁle headrail.

With 6 on-trend hardware colours to coordinate with the wide variety of Luminette fabric colours. This provides the perfect ﬁnish

that enhances the overall look of your Luminette Privacy Sheers.

126 White Diamond

437 Mushroom Sparkle

530 Silver

534 Champagne

580 Graphite

528 Bronze

ISSUE DATE: FEBRUARY 2018 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: NOVEMBER 2015 APPROVED BY: S. GONZALEZ PAGE 5 OF 38

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

ISSUE DATE: NOVEMBER 2015 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: JANUARY 2011 APPROVED BY: S. GONZALEZ PAGE 5 OF 25

The beautiful nature of the vanes

diffuse light to provide a warm glow

when closed, ideal for living rooms

whilst still preserving outside views

through the sheers as shown when

the vanes are open.

Luminette Privacy Sheers fabric vanes

darken any room and provide privacy

without total blockout, making them ideal

for bedrooms.

Translucent

Room Darkening

ISSUE DATE: FEBRUARY 2018 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: NOVEMBER 2015 APPROVED BY: S. GONZALEZ PAGE 6 OF 38

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

ISSUE DATE: NOVEMBER 2015 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: JANUARY 2011 APPROVED BY: S. GONZALEZ PAGE 6 OF 25

You decide between the safety-minded wand/cord combination,

Travelling Wand or motorised Platinum Technology with its sleek,

single-touch remote.

COMBINATION WAND / CORD

Combine the tilt and traverse functions into

one control, the combination wand/cord

system makes opening, closing and rotating

the vanes quick and easy.

• Pullcordtotraversesheer.

• Twistwandtorotatevanes.

• Sheerstacksonthesamesideaswand/cord.

TRAVELLING WAND

Perfect for sliding glass doors, the Travelling

Wand system is a simple solution for easy,

one-handed access. Simply push or pull the

wand to traverse the product and twist to

rotate the vanes.

• Perfectforslidingglassdoors.

• Pushorpullwandtotraversesheer.

• Twistwandtorotatevanes.

• Sheerstacksonoppositesideofwand.

POWERVIEW WITH

PLATINUM TECHNOLOGY

Thanks to its wireless technology, PowerView

controls incoming light and energy usage

throughout the home with the simple press of

a button.

• Perfectsolutionforlargeorhard-to-reach

windows and doors.

• Nocordsforenhancedchildandpet

safety.

• Batterypoweredremotecontroleasily

traverses sheer and rotates vanes.

AVAILABLE IN 2016

ISSUE DATE: FEBRUARY 2018 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: NOVEMBER 2015 APPROVED BY: S. GONZALEZ PAGE 7 OF 38

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

Control Placement

• Combination Wand/Cord: sheers stack on same side as wand/cord; for split stack, choose left or right control.

• Travelling Wand: sheers stack on side opposite wand; available with face mount side stack only.

• PowerView: sheers stack on same side as motor; for split stack, choose left or right motor.

Softrak™ System

• An exclusive system that is reliable and easy to

operate.

• Scissors expand when the sheer is drawn closed and

compress when the sheer is drawn open.

• Vane realignment is easy — rotate the vanes ﬁrst to

one side and then the other.

• The Traveling Wand™ system is a cordless wand

control system that traverses the fabric and rotates

the vanes.

• With the Combination Wand/Cord system, pull the

cord to traverse the fabric, and twist the wand to

rotate the vanes. Use two hands to avoid twisting the

cord.

Tenting

• When sheers are stacked, it is normal for them

to ﬂare out or “tent” at the bottom, or to stack

irregularly due to the heavier fabric.

• To minimize tenting, the consumer can simply

close the sheer less tightly.

Tiltback

• Additional weight of the face fabric in front

causes the sheer to hang at a slight angle, called

“tiltback”. This is an inherent characteristic of the

product and may be more noticeable on shorter

panels.

Luminette®Privacy Sheers - Product Details

Vane Closure Gap

• Closed Privacy Sheers vanes are designed to overlap for privacy when viewed straight on.

• Light leakage may occur due to the vane closure gap, which may increase with the length of the sheer.

• The vane closure gap is most visible when viewed from the side. It is a normal, inherent characteristic of the product and should not

be considered a defect.

• Vane closure is tighter in one direction than the other when the vanes are rotated closed.

Split Stack Centre Gap

• The maximum distance between fabric panels of a split stack design is 6mm.

Vane Closure Gap

Traveling Wand Operation Combination Wand

Cord Operation

Split Stack Centre Gap up

to 6mm

ISSUE DATE: FEBRUARY 2018 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: NOVEMBER 2015 APPROVED BY: S. GONZALEZ PAGE 8 OF 38

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

Options & Limitations

LUMINETTE

®Privacy Sheers Classic 89mm Vane Size

COMBINATION WAND/ CORD TRAVELLING WAND

SIDE STACK SPLIT STACK

SIDE STACK ONLY

MINIMUM WIDTH

300mm

MAXIMUM WIDTH

4875mm

3660mm

MINIMUM DROP

610mm

MAXIMUM DROP

3045mm

2540mm

MAXIMUM WIDTH

- End Mount

910mm

N/A

MAXIMUM WIDTH

- Side by Side

Drapes

9750mm

7320mm

REVEAL FIT

Minimum Depth

Fully Recessed

25mm

160mm

N/A

FACE FIT

Minimum Mounting Surface

Overlap Each Side

Past Sill

Floor Clearance

29mm

100mm

50mm

16mm

29mm

100mm

50mm

16mm

END MOUNTING

Minimum

Mounting Depth

32mm

STANDARD

WANDS/CORDS

FABRIC DROP

610-1018mm

1019-1526mm

1527-2161mm

2162-2415mm

2416-2667mm

2668-3070mm

WAND/CORD

540mm

845mm

1150mm

1455mm

1760mm

1910mm

FABRIC DROP

610-1216mm

1217-2130mm

2131-2540mm

TRAVELLING

WAND

585mm

760mm

1015mm

NON-STANDARD

WANDS/CORDS

760mm 2490mm

1520mm 3045mm

2030mm 3655mm

2285mm

N/A

ISSUE DATE: FEBRUARY 2018 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: NOVEMBER 2015 APPROVED BY: S. GONZALEZ PAGE 9 OF 38

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

ISSUE DATE: NOVEMBER 2015 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: JANUARY 2011 APPROVED BY: S. GONZALEZ PAGE 9 OF 25

LUMINETTE®Privacy Sheers Measuring

- Classic 89mm Vane Size -

- 5 - 5

- 5

-5

ISSUE DATE: FEBRUARY 2018 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: NOVEMBER 2015 APPROVED BY: S. GONZALEZ PAGE 10 OF 38

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

PRODUCT INFORMATION MANUAL

SECTION: 12 LUMINETTE PRIVACY SHEERS

ISSUE DATE: NOVEMBER 2015 ORIGINATOR: SKILTEC

REPLACES ISSUE DATE: JANUARY 2011 APPROVED BY: S. GONZALEZ PAGE 10 OF 25

STACKBACK CHARTS

(FACE MOUNTS ONLY) - 89MM
