SD card real time data recorder

PM2.5, %RH, Temp.,CO2,Barometer

AIR QUALITY MONITOR RECORDER

Model : PM-1064SD

Your purchase of this AIR QUALITY MONITOR with SD CARD DATA RECORDER

marks a step forward for you into the field of precision measurement. Although

this Meter is a complex and delicate instrument, its durable structure developed.

Please read the following instructions carefull yand always keep this manual

within easy reach.

OPERATION MANUAL

TABLE OF CONTENTS

1. FEATURES.............................................................................................................

2. SPECIFICATIONS.......................................................................................................

2-1 General Specifications...............................................................................................

2-2 Electrical Specifications.............................................................................................

3. FRONT PANEL DESCRIPTION...........................................................................

Measurement preparation............................................................................................

5. Measurement procedure...................................................................................................

5-1.METER POWER ON........................................................................................................................

5-2.PM2.5 Measurement.........................................................................................

5-3.Humidity and Temperature measurement....................................................................

5-4.CO2 measurement.............................................................................................................

5-5.Barometer measurement.............................................................................................................

5-6.Time Display.............................................................................................................

6. OTHER FUNCTION...................................................................................................

6-1 Data Hold........................................................................................................................

6-2 Record ( Max./ Min. reading ).........................................................................................

6-3 LCD Backlight ON/OFF.........................................................................................

6-4 ALARM function..............................................................................................................

6-5 User calibration function.........................................................................................

7. DATALOGGER...............................................................................................................

7-1 Preparation before execute datalogger function...............................................................................

7-2 Auto Datalogger ( Set sampling time ≧

2 second )......................................................

7-3 Manual Datalogger ( Set sampling time = 0 second )....................................................

7-4 Check time,sampling time information...............................................................................

7-5 SD Card Data structure.......................................................................................................................

8. Saving data from the SD card to the computer.......................................................

9. Air filter net REPLACEMENT...............................................................................

10. POWER SUPPLY from DC ADAPTER..........................................................................

11. BATTERY REPLACEMENT............................................................................................

12. SYSTEM RESET................................................................................................................

13. RS232 PC SERIAL INTERFACE....................................................................................

14. Micro suspend the particle (PM2.5) Parallel

table of the indicator and activity are proposed................................................................................

15. PATENT....................................................................................................................

1. FEATURES

* Real time recorder, save the data into the SD memory

card and can be down load to the Excel, extra software

is no need. User can make the further data or graphic

analysis by themselves. under the Excel software.

* Monitoring air pollutant source from dust, petrochemical industry,

steel-making plant, thermal power plant, restaurant, smoke, burning plants,

driving automobiles.

* The meter is a real-time air quality monitor instrument used to monitor

the concentration of PM2.5, humidity and temperature in the indoor

environment.

* PM2.5 : 0 to 250 μg/m³.

* Humidity : 5 to 95 %RH.

*Temperature : 0 to 50 ℃,℃/℉.

* CO2 : 0 to 10,000 ppm

* Barometer : 10.0 to 1100.0 hPa, 7.5 to 825.0 mmHg, 0.29 to 32.48 inHg.

* PM2.5 time weighted average reading.

* Data hold,Record(Max,Min)

* ALARM setting, there is beeper sound output and external device control

output,

* Health index(0-9) detection and alarm .

* Can replacement air filter net.

* Built-in clock and Calendar, real time data record with SD memory card,

sampling time can be set from 2 second to 3600 seconds. Just slot the SD

card into the computer, all the measured values with the time information

(year, month, data, hour, minute, second) can be downloaded to the Excel

Directly, then user can make the further data analysis by themselves.

* Power by UM3/AA(1.5V) X 6 batteries or DC 9V adapter

* RS232/USB PC computer interface

* Meter can cooperate with 1 GB to 32 GB SD card.

* Patented.

2. SPECIFICATIONS

2-1 General Specifications

Circuit Custom one-chip of microprocessor LSI

circuit.

Display LCD Size: 2.18 X 2.87” (55.4 X 72.9 mm)(Dot Matrix)

LCD with green backlight ( ON/OFF ).

Measurement * PM2.5(Particulate matter)

* Humidity

* Temperature

* CO2

* Barometer

Over-range * LCD display show " OL "

* The data save into the Micro SD card will show

" 999 "(overleap the decimal point).

Datalogger Auto 2 sec to 3600 sec.

Sampling Time

Setting range

Manual Push the data logger button

once will save data one time.

@ Set the sampling time to

0 second.

@ Manual mode, can also select the

1 to 99 position ( Location ) no.

Data error no. 0.1% of total saved data max.

Memory Card SD memory card. 1 GB to 32 GB.

Measurement * SD memory card Format

preparation * Set clock time

setting * Set sampling time

@ main setting * Auto power OFF management

* Set beep Sound ON/OFF

* Decimal point of SD card setting

* Temp. unit setting

* Barometer unit setting

* Alarm value setting

* TWA setting

* Altitude value setting

Data Hold Freeze the display reading.

Memory Recall Maximum & Minimum value.

Sampling Time Approx. 1 second.

of Display

Data Output RS 232/USB PC computer interface.

* Connect the optional RS232 cable

UPCB-02 will get the RS232 plug.

* Connect the optional USB cable

USB-01 will get the USB plug.

Alarm Output * Open collector output

* Input impedance:330Ω

* Maximum applied voltage: 24 V DC

* Maximum starting current: 70mA DC

Power Supply * DC 1.5 V ( UM3, AA ) x 6 PCs, or equivalent.

* AC to DC 9 V power adapter

Power Current DC 230 mA approximately.

Backlight ON approximately DC 250 mA.

Operating 0 to 50 ℃. ( 32 to 122 ℉ ).

Temperature

Operating Less than 80% R.H.

Humidity

Weight 387 g/0.85 LB.

Dimension 164 X 93 X 72 mm(6.5 X 3.7 X 2.8 inch)

Accessories

Instruction manual....................................................................

1 PC

Included

AC to DC 9 V adapter.......................................................

1 PC

Optional Air filter net ( AF-01 )

Accessories USB cable, USB-01.

RS232 cable, UPCB-02.

Data Acquisition software, SW-U801-WIN.

SD memory card ( 4 GB )

2-2 Electrical Specifications (23±5

℃

)

PM2.5(Particulate matter)

0 to 250 μg/m³

1 μg/m³

±(10 % reading + 15μg/m³)

Resolution

Accuracy

PM2.5

Range

Humidity

Humidity Range 5 % to 95 % R.H.

Resolution 0.1 % R.H.

Accuracy ≧70% RH :

±(3% reading + 1% RH).

< 70% RH :

±3% RH.

Temperature

Temperature Range 0 ℃ to 50 ℃,32 ℉ to 122 ℉.

Resolution 0.1 degree

Accuracy ℃ ±0.8 ℃.

℉ ±1.5 ℉.

CO2 ( Carbon dioxide )

Range 0 to 10,000 ppm

CO2 Resolution 1 ppm

( Carbon Accuracy ±40 ppm

dioxide ) *

≦

1,000 ppm.

±(50ppm +3% of reading)

23 ± 5 ℃. * > 1,000 ppm

≦

3,000 ppm.

±(50ppm +5% of reading) typically

* > 3,000 ppm

≦

10,000 ppm. ,

Repeatability ± 20 ppm *

≦

3,000 ppm.

Barometric pressure(Barometer)

0.1mmHg

0.01inHg

Accuracy

± 1.5 hPa

± 1.2 mmHg

± 0.05 inHg

Unit

hPa

Resolution

0.1 hPa

mmHg

inHg

Range

10.0 to 1100.0

7.5 to 825.0

0.29 to 32.48

3. FRONT PANEL DESCRIPTION

Fig. 1

3-1.Display 3-9.SD card socket

3-2.Power/Backlight button 3-10.RESET button

3-3.HOLD key button 3-11.ALARM socket

3-4.REC key button 3-12.RS232 socket

3-5.TIME/SET key button 3-13.DC 9V power adapter socket

3-6.ENTER/LOG key button

3-14.PM2.5 Air sampling inlet(Air filter net)

3-7.▲/FUNCTION key button 3-15.PM2.5 Air sampling outlet

3-8.▼/ALARM key button 3-16.Battery Cover/Battery compartment

4. Measurement preparation

4-1.The initial boot screen

4-2.Into the measurement screen

4-3.Key outline

4-3-1.POWER/Backlight KEY(3-2,Fig.1):

A.Long press this button> 2 SEC. Native ON / OFF function.

B.In the boot state press the button briefly, for the LCM backlight

ON / OFF function.

4-3-2.HOLD KEY(3-3,Fig.1): LCD display value lock function.

A.In measureing:LCD display value lock function.

B.In setting.:Off setting function Back to measurement mode.

4-3-3.REC KEY(3-4,Fig.1): The maximum and minimum record.

4-3-4.TIME/SET KEY(3-5,Fig.1):

A.In the measurement screen press the button will display the year、

month、 day and time of the picture.

B.In the measurement screen long press button> 2 SEC, it will Into the

setting screen, when the setting screen press the button, change the

setting of the first layer option.

4-3-5.ENTER/LOG KEY(3-6,Fig.1):

A.When the setting screen press the button briefly for the storage of

set value function.

B.In measuring screen(eg SCREEN1)long press button> 2 SEC. When you

Into the data logger function.

4-3-6.

▲

/FUNCTION KEY(3-5,Fig.1):

A.When the setting screen press the button, the value increases function.

Long function. press and hold to quickly increase the value

B.In measuring screen (eg SCREEN1) long press button> 2 SEC., Then

switch to the TWA measurement functions (eg SCREEN4).

4-3-7.

▼

/ALARM KEY(3-6,Fig.1):

A.When the setting screen press the button, the value was down function.

Long press and hold down the value of fast function.

B.In measuring screen (eg SCREEN1) long press button> 2 SEC., Then

Into the ALARM function (eg SCREEN16).

4-4.Setting function easy instructions:

* SET SD F: Executive SD memory card format.

* SET DATE: Into the year

、

month

、

day adjustment.

* SET TIME: Into the hours

、

minutes

、

seconds adjustment.

* SET SP-T: Data logger sampling time setting.

* SET P-OFF: Auto Power Off Setting.

* SET BEEP: Beeper sound ON/OFF setting

* SET DEC: SD Card Decimal character setting USA or EURO.

* SET T-C/F: Temp. Unit

℃

℉

setting.

* SET hPa(Barometer unit setting)

* SET ALARM: Upper and lower alarm value setting.

* SET PM2.5 Hour TWA: PM2.5 Time-Weighted Average setting.

* SET Meter Altitude(Altitude value setting)

* SET ESC: Escape setting.

4-5.Setting screen Description:

4-5-1.SET SD F(SD memory card format):

A.Press

▲

▼

buttons to select YES or NO, when YES is selected and press

ENTER key to start the Format function.

B.When no press ENTER KEY store, press TIME / SET KEY proceed to the

next function setting(SET SD F

→

SET DATE).

4-5-2.SET DATE(Real time clock setting):(Year/Month/Date,Hour/Minte/Second)

A.Press

▲

▼

key year value adjustment,

▲

▼

then press and hold up,

down fast adjustment. Press ENTER then the set value is stored and the

month of adjustment functions, and so on the day / time / minute / second to

do the setting.

B.When no press ENTER KEY store, press TIME / SET KEY proceed to the

next function setting(SET DATE

→

SET SP-T).

4-5-3.SET SP-T(Data logger sampling time setting):

A. Press

▲

▼

key to Data logger sampling time setting, press ENTER KEY

will set the value of the store and into the next function is set

(SET SP-TeSET P-OFF).

B.0 S: Representative Manual Logger function.

C.2

〜

3600 S: Representative Auto Logger function.

D.When no press ENTER KEY store, press TIME / SET KEY proceed

to the next function setting (SET SP-T

→

SET P-OFF).

4-5-4.SET P-OFF(Auto power off setting):

A.Press

▲

▼

KEY to select YES or NO, when select YES and press

ENTER KEY AUTO POWER OFF function is started and go to the next

function setting (SET P-OFF

→

SET BEEP).

B.When inserted into the DC 9V power adapter in battery mode will be

automatically canceled AUTO POWER OFF function.

C.When no press ENTER KEY store, press TIME / SET KEY proceed to the

next function setting (SET P-OFF

→

SET BEEP).

4-5-5.SET BEEP(Beeper sound ON/OFF setting):

A.Press

▲

▼

KEY to select YES or NO, when you select YES, press ENTER

KEY function is to store this setting and proceed to the next function setting

(SET BEEP

→

SET DEC).

B.When no press ENTER KEY store, press TIME / SET KEY proceed to the

next function setting (SET BEEP → SET DEC).

4-5-6.SET DEC(SD Card Decimal character setting):

A.Press ▲ or ▼ KEY select USA or EURO, when the ENTER KEY function is to

store this setting and will advance to the next function setting

(SET DEC → SET T-C/F).

B.When no press ENTER KEY store, press TIME / SET KEY proceed to the

next function setting(SET DEC → SET T-C/F).

4-5-7.SET T-C/F(Temp. Unit ℃/℉ setting):

A.Press

▲

▼

KEY select

℃

℉

, when the ENTER KEY function is to store

this setting and proceed to the next function setting(SET T-C/F

→

SET

ALARM).

B.When no press ENTER KEY store, press TIME / SET KEY proceed to the

next function setting (SET DEC

→

SET ALARM).

4-5-8.SET hPa BARO(Barometer unit setting):

A.Press

▲

▼

KEY select hPa or mmHg or inHg , when the ENTER KEY

function is to store this setting and proceed to the next function setting(SET

hPa BARO )

→

SET ALARM).

B.When no press ENTER KEY store, press TIME / SET KEY proceed to the

next function setting (SET hPa BARO

→

SET ALARM).

Table des matières

Autres manuels Lutron Electronics Instrument de mesure

Lutron Electronics

Lutron Electronics PE-21 Manuel utilisateur

Lutron Electronics

Lutron Electronics DW-6064 Manuel utilisateur

Lutron Electronics

Lutron Electronics LM-8010 Manuel utilisateur

Lutron Electronics

Lutron Electronics PPH-2108 Manuel utilisateur

Lutron Electronics

Lutron Electronics AM-4234SD Manuel utilisateur

Lutron Electronics

Lutron Electronics SL-4033SD Manuel utilisateur

Lutron Electronics

Lutron Electronics PH-222 Manuel utilisateur

Lutron Electronics

Lutron Electronics SL-4011 Manuel d'installation

Lutron Electronics

Lutron Electronics DW-6063 Manuel utilisateur

Lutron Electronics

Lutron Electronics Radio Powr Sav LRF2-DCRB Instructions d'installation et d'utilisation

Lutron Electronics

Lutron Electronics GCH-2018 Manuel utilisateur

Lutron Electronics

Lutron Electronics PWA-301 Manuel utilisateur

Lutron Electronics

Lutron Electronics WA-2017SD Manuel utilisateur

Lutron Electronics

Lutron Electronics VB-8206SD Manuel utilisateur

Lutron Electronics

Lutron Electronics FORCE GAUGE FG-6100SD Manuel utilisateur

Lutron Electronics

Lutron Electronics SOIL PH METER Manuel utilisateur

Lutron Electronics

Lutron Electronics DM-9027T Manuel utilisateur

Lutron Electronics

Lutron Electronics GC-2028 Manuel utilisateur

Lutron Electronics

Lutron Electronics SL-4010 Manuel utilisateur

Lutron Electronics

Lutron Electronics LX-1128SD Manuel utilisateur

Lutron Electronics

Lutron Electronics LM-8000A Manuel utilisateur

Lutron Electronics

Lutron Electronics CD-4318SD Manuel utilisateur

Lutron Electronics

Lutron Electronics MMA-386SD Manuel utilisateur

Lutron Electronics

Lutron Electronics AM-4201 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
