Lutron Electronics VB-8206SD Manuel utilisateur

SD card real time datalogger, RS232/USB

VIBRATION METER

Model : VB-8206SD

Your purchase of this

VIBRATIONMETERwith

SDCARDDATALOGGE

marksastepforwardfor

you into the field of

precision measurement.

Althou

hthisMETERisa

complex and delicate

instrument, its durable

structurewillallowmany

years of use if proper

operatin

techniquesare

developed.Pleasereadthe

followin

instructions

carefullyandalwayskeep

thismanualwithineasy

reach.

OPERATION MANUAL

TABLE OF CONTENTS

1. FEATURES............................................................................... 1

2. SPECIFICATIONS..................................................................... 2

3. FRONT PANEL DESCRIPTION.................................................... 8

3-1 Display................................................................................................. 8

3-2 Power Button ( ESC, Backli

ht Button )................................................... 8

3-3 Hold Button ( Function Button, Next Button ).......................................... 8

3-4 REC Button ( Enter Button, Unit Button )...............................................

3-5 SET Button ( Button, Time check Button )..........................................

▼8

3-6 Lo

er Button ( Button, Samplin

time check Button, Zero Button )▲

Max hold reset Button )........................................................................ 8

3-7 BNC Input Socket.................................................................................

3-8 SD Card Socket..................................................................................... 8

3-9 RS-232 Output Terminal........................................................................ 8

3-10 Reset Button......................................................................................

3-11 DC 9V Power Adapter Input Socket......................................................

3-12 Battery Compartment/Cover................................................................

3-13 Battery Cover Screws.......................................................................... 8

3-14 Stand................................................................................................. 8

3-15 Tripod Fix Nut..................................................................................... 8

3-16 Ma

netic base.................................................................................... 8

3-17 Vibration Sensor................................................................................. 8

3-18 Input Socket of Vibration Sensor .........................................................

3-19 Mini Plu

of Cable...............................................................................

3-20 Sensor Cable......................................................................................

3-21 Cable BNC Plu

................................................................................... 8

4. MEASURING PROCEDURE......................................................... 9

4-1 Preparation..........................................................................................

4-2 Unit selection ( Acc./Velocity/Displacement selection ).............................

4-3 Function selection ................................................................................11

4-4 Zero ad

ustment procedures..................................................................

4-5 Data Hold.............................................................................................13

4-6 Data Record ( Max./ Min. readin

)........................................................

4-7 LCD Backli

ht ON/OFF...........................................................................14

5. DATALOGGER..........................................................................14

5-1 Preparation before execute datalo

er function.......................................14

5-2 Auto Datalo

er ( Set samplin

time 1 second ).................................≧15

5-3 Manual Datalo

er ( Set samplin

time = 0 second )..............................16

5-4 Check time information.........................................................................

5-5 Check samplin

time information...........................................................

5-6 SD Card Data structure.........................................................................

6. Savin

data from the SD card to the computer........................... 19

7. ADVANCED SETTING................................................................20

7-1 Set clock time ( Year/Month/Date, Hour/Minute/ Second )........................21

7-2 Decimal point of SD card settin

............................................................

7-3 Auto power OFF mana

ement ...............................................................22

7-4 Set beep Sound ON/OFF........................................................................23

7-5 Set samplin

time ................................................................................ 23

7-6 SD memory card format........................................................................

8. POWER SUPPLY from DC ADAPTER...........................................

9. BATTERY REPLACEMENT..........................................................24

10. SYSTEM RESET......................................................................25

11. RS232 PC serial interface........................................................25

12. CLASSIFICATION RANGES......................................................

13. SENSITIVITY RELATIVE accordin

ISO 2954............................

14. PATENT.................................................................................29

1. FEATURES

* Applications for industrial vibration monitoring :

All industrial machinery vibrates. The level of vibration is

a useful guide to machine condition. Poor balance,

misalignment & looseness of the structure will cause the

vibration level increase, it is a sure sign that the

maintenance is needed.

* Frequency range 10 Hz - 1 kHz, sensitivity relative meet

ISO 2954.

* Professional vibration meter supply with vibration sensor

& magnetic base, full set.

* Metric & Imperial display unit

* Acceleration, Velocity, Displacement measurement.

* RMS, Max hold, Peak value measurement.

* Max. Hold reset button, Zero button.

* Wide frequency range.

* Data hold button to freeze the desired reading.

* Memory function to record maximum and minimum

reading with recall.

* Separate vibration probe with magnetic base, easy operation.

* Real time SD memory card Datalogger, it Built-in Clock

and Calendar, real time data recorder , sampling time set

from 1 second to 3600 seconds.

* Manual datalogger is available ( set the sampling

time to 0 ), during execute the manual datalogger

function, it can set the different position ( location ) No.

( position 1 to position 99 ).

* Innovation and easy operation, computer is not need

to setup extra software, after execute datalogger, just

take away the SD card from the meter and plug in the

SD card into the computer, it can down load the all the

measured value with the time information (

year/month/date/ hour/minute/second ) to the Excel

directly, then user can make the further data or graphic

analysis by themselves. 1

* SD card capacity : 1 GB to 16 GB.

* LCD with green light backlight, easy reading.

* Can default auto power off or manual power off.

* Data hold, record max. and min. reading.

* Microcomputer circuit, high accuracy.

* Power by UM3/AA ( 1.5 V ) x 6 batteries or DC 9V adapter.

* RS232/USB PC COMPUTER interface.

2. SPECIFICATIONS

2-1 General Specifications

Circuit Custom one-chip of microprocessor LSI

circuit.

Display LCD size : 52 mm x 38 mm

LCD with green backlight ( ON/OFF ).

Measurement Velocity, Acceleration, Displacement

Function

Acceleration, Velocity :

RMS, Peak, Max Hold.

Displacement :

p-p ( peak-peak ), Max Hold p-p.

Unit

Measurement Metric Imperial

Acceleration meter/s^2, g ft/s^2,

Velocity mm/s, cm/s inch/s

Displacement mm inch

Frequency 10 Hz to 1 KHz

range

* Sensitivity relative during the

the frequency range meet ISO 2954

Refer to table 1, page 28

Circuit Exclusive microcomputer circuit.

Peak

Acceleration, Velocity :

Measurement To measure and update the peak

value.

Displacement :

To measure and update the peak to

peak ( p-p ) value.

Max Hold

Acceleration, Velocity :

Measurement To measure and update the max. peak

value.

Displacement :

To measure and update the max.

peak to peak ( p-p ) value.

Zero Button Under Acceleration ( RMS ) measurement,

sensor motionless , press Logger Button

( 3-6, Fig. 1 ) > 5 seconds.

Max. Hold Reset Under Max. hold measurement, press

Button Logger Button ( 3-6, Fig. 1 ) > 5 seconds.

Datalogger Auto 1 second to 3600 seconds

Sampling Time

@ Sampling time can set to 1 second,

Setting range

but memory data may loss.

Manual Push the data logger button

once will save data one time.

@ Set the sampling time to

0 second.

@ Manual mode, can also select the

1 to 99 position ( Location ) no.

Memory Card SD memory card 1 GB to 16 GB.

Advanced * Set clock time ( Year/Month/Date,

setting Hour/Minute/ Second )

* Decimal point of SD card setting

* Auto power OFF management

* Set beep Sound ON/OFF

* Set sampling time

* SD memory card Format

Data error no. 0.1 % no. of total saved data typically.≦

Data Hold Freeze the display reading.

* Only available for the RMS function.

Memory Recall Maximum & Minimum value.

* Only available for the RMS function.

Data Output RS 232/USB PC computer interface.

* Connect the optional RS232 cable

UPCB-02 will get the RS232 plug.

* Connect the optional USB cable

USB-01 will get the USB plug.

Sampling Time Approx. 1 second.

of Display

Operating 0 to 50 .℃

Temperature Less than 85% R.H.

and Humidity

Power Supply

Alkaline or heavy duty DC 1.5 V battery

( UM3, AA ) x 6 PCs, or equivalent.

DC 9V adapter input. ( AC/DC power

adapter is optional ).

Power Current Normal operation ( w/o SD card save

data and LCD Backlight is OFF) :

Approx. DC 15 mA.

When SD card save the data and LCD

Backlight is OFF) :

Approx. DC 36 mA.

Weight

Meter :

515 g/ 1.13 LB.

Probe with cable and magnetic base :

99 g/0,22 LB

Dimension

Meter :

203 x 76 x 38 mm

Vibration sensor probe:

Round 16 mm Dia. x 37 mm.

Cable length : 1.2 meter.

Accessories * Instruction manual.......................

1 PC

Included * Hrad carrying case, CA-06.............1 PC

* Vibration sensor with cable...........

1 PC

* Magnetic base..............................1 PC

Optional SD Card ( 2 G )

Accessories AC to DC 9V adapter.

USB cable, USB-01.

RS232 cable, UPCB-02.

Data Acquisition software,SW-U801-WIN.

2-2 Electrical Specifications (23±5 )℃

Acceleration ( RMS, Peak, Max Hold )

Unit m/s^2

Range 0.5 to 199.9 m/s^2

Resolution 0.1 m/s^2

Accuracy ± ( 5 % + 2 d ) reading

@ 160 Hz, 80 Hz, 23 ± 5 ℃

Calibration 50 m/S^2 ( 160 Hz )

Point

Unit g

@ 1 g = 9.8 m/s^2

Range 0.05 to 20.39 G

Resolution 0.01 G

Accuracy ± ( 5 % + 2 d ) reading

@ 160 Hz, 80 Hz, 23 ± 5 ℃

Calibration 50 m/S^2 ( 160 Hz )

Point

Unit ft/s^2

Range 2 to 656 ft/s^2

Resolution 1 ft/s^2

Accuracy ± ( 5 % + 2 d ) reading

@ 160 Hz, 80 Hz, 23 ± 5 ℃

Calibration 50 m/S^2 ( 160 Hz )

Point

Remark :

RMS : To measure the true RMS value.

Peak : To measure and update the peak value.

Max. Hold : To measure and update the max. peak value.

Velocity ( RMS, Peak, Max Hold )

Unit mm/s

Range 0.5 to 199.9 mm/s

Resolution 0. 1 mm/s

Accuracy ± ( 5 % + 2 d ) reading

@ 160 Hz, 80 Hz, 23 ± 5 ℃

Calibration 50 mm/s ( 160 Hz )

Point

Unit cm/s

Range 0.05 to 19.99 cm/s

Resolution 0. 01 cm/s

Accuracy ± ( 5 % + 2 d ) reading

@ 160 Hz, 80 Hz, 23 ± 5 ℃

Calibration 50 mm/s ( 160 Hz )

Point

Unit inch/s

Range 0.02 to 7.87 inch/s

Resolution 0.01 inch/s

Accuracy ± ( 5 % + 2 d ) reading

@ 160 Hz, 80 Hz, 23 ± 5 ℃

Calibration 50 mm/s ( 160 Hz )

Point

Remark :

RMS : To measure the true RMS value.

Peak : To measure and update the peak value.

Max. Hold : To measure and update the max. peak value.

Displacement ( p-p, Max Hold p-p )

Unit mm

Range 1.999 mm

Resolution 0.001 mm

Accuracy ± ( 5 % + 2 d ) reading

@ 160 Hz, 80 Hz, 23 ± 5 ℃

Calibration 0.141 mm ( 160 Hz )

Point

Unit inch

Range 0.078 inch

Resolution 0.001 inch

Accuracy ± ( 5 % + 2 d ) reading

@ 160 Hz, 80 Hz, 23 ± 5 ℃

Calibration 0.141 mm ( 160 Hz )

Point

Remark :

p-p :

To measure the Peak to Peak value.

Max. Hold p-p :

To measure and update the max. Peak to Peak value.

@ Above specification tests under the environment RF Field Strength

less than 3 V/M & frequency less than 30 MHz only.

3. FRONT PANEL DESCRIPTION

Fig

3-1 Disp

3-2 Power Button

(

ESC, Bac

t Button

)

3-3 Ho

Button

(

Function Button, Next Button

)

3-4 REC Button

(

Enter Button, Unit Button

)

3-5 SET Button

(

Button, Time c

Button

)

▼

3-6 Lo

er Button

(

Button, Samp

time c

Button, Zero Button,▲

Max

reset Button

)

3-7 BNC Input Soc

3-8 SD Car

Soc

3-9 RS-232 Output Termina

3-10 Reset Button

3-11 DC 9V Power A

apter Input Soc

3-12 Battery Compartment

Cover

3-13 Battery Cover Screws

3-14 Stan

3-15 Tripo

Fix Nut

3-16 Ma

netic Base

3-17 Vi

ration Sensor

3-18 Input Soc

et o

ration Sensor

3-19 Mini P

3-20 Sensor Ca

3-21 Ca

e BNC P

Table des matières

Autres manuels Lutron Electronics Instrument de mesure

Lutron Electronics

Lutron Electronics PWA-301 Manuel utilisateur

Lutron Electronics

Lutron Electronics HT-315 Manuel utilisateur

Lutron Electronics

Lutron Electronics MO-2014 Manuel utilisateur

Lutron Electronics

Lutron Electronics SL-4010 Manuel utilisateur

Lutron Electronics

Lutron Electronics LCR-9083 Manuel utilisateur

Lutron Electronics

Lutron Electronics AM-4206M Manuel utilisateur

Lutron Electronics

Lutron Electronics YK-2001PHA Manuel utilisateur

Lutron Electronics

Lutron Electronics WA-2017SD Manuel utilisateur

Lutron Electronics

Lutron Electronics SL-4023SD Manuel utilisateur

Lutron Electronics

Lutron Electronics ESF-106 Manuel utilisateur

Lutron Electronics

Lutron Electronics FORCE GAUGE FG-6005SD Manuel utilisateur

Lutron Electronics

Lutron Electronics AM-4220 Manuel utilisateur

Lutron Electronics

Lutron Electronics PM-9107 Manuel utilisateur

Lutron Electronics

Lutron Electronics SPM-1116SD Manuel utilisateur

Lutron Electronics

Lutron Electronics YK-2005LX Manuel utilisateur

Lutron Electronics

Lutron Electronics LM-8000A Manuel utilisateur

Lutron Electronics

Lutron Electronics MS-7003 Manuel utilisateur

Lutron Electronics

Lutron Electronics SL-4011 Manuel d'installation

Lutron Electronics

Lutron Electronics CM-9930R Manuel utilisateur

Lutron Electronics

Lutron Electronics PCD-431 Manuel utilisateur

Lutron Electronics

Lutron Electronics LCR-9063 Manuel utilisateur

Lutron Electronics

Lutron Electronics EMF-831SD Manuel utilisateur

Lutron Electronics

Lutron Electronics HR-3023SD Manuel utilisateur

Lutron Electronics

Lutron Electronics EMF-8218SD Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
