MODEL:

SGQ4160

COLOR QUAD PROCESSOR

Instruction Manual

www.lorexcctv.com

English Version1.0

Please be sure to read carefully and follow all the

safety information.

Keep the manual in a safe place for future reference.

INTRODUCTION

Congratulations on your purchase of the Color Quad Processor from Lorex.

The Color Quad Processor turns any monitor into a Quad monitor with security features. Connect up to four

cameras to the Quad Splitter and view all four locations simultaneously in Real-Time (30 fps). The Quad

Processor is an ideal security solution for small to medium sized commercial enterprises as it allows you to

use an existing monitor as a 4 Channel Observation System.

Connect the Quad Processor to a Time Lapse VCR or DVR to capture footage and enable alarm recording.

You can also connect PIR motion sensors to the Quad Processor in order to have Motion Detection

capability.To learn more about this system or to find out more about other products available, please visit

our website at www.lorexcctv.com

FEATURES

Color Quad Processor Features

• Turns a single screen monitor into a Quad system

•View up to 4 camera locations simultaneously in real-time

(30 fps)

•Four Alarm Inputs for connection of external PIR sensors / Magnetic Sensor

•Viewing modes: Quad*Full-Screen*Auto Sequencing

•Video Loss alarm

•Digital freeze frame

•On Screen Display: date*time*camera

•Event Log lists instances of video loss & alarms

•Picture adjustable by channel (brightness/ contrast/ color)

All the safety and operating instructions should be read before the appliance is operated. The improper

operation may cause irreparable damage to the appliance.

• Please lift and place this equipment gently.

• Do not expose this equipment under to direct sunlight.

• Do not use this equipment near water or in contact with water.

• Do not spill liquid of any kind on the equipment.

• Do not unplug the power connector before turn the power off correctly.

• This equipment should be operated using only the power source from standard package.

• Unauthorized repair or parts substitutions may result in fire, electric shock or other hazards.

• Do not switch the Power On & Off within short period (within 3 seconds).

• Do not attempt to service this equipment by yourself. Refer all servicing to qualified service personnel.

• This unit should be operated only from the type of power source indicated on the manufacturer’s label.

• This installation should conform to all local codes.

SAFETY WARNING

CAUTION

RISK OF ELECTRIC SHOCK. DO NOT OPEN.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

Explanation of two Symbols

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert

the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that

may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence

of important operating and maintenance-(servicing) instructions in the literature accompanying

the appliance.

TABLE OF CONTENTS PAGE

1. SYSTEM INCLUDES -----------------------------------------------------------------------------

2. FRONT PANEL CONTROLS -------------------------------------------------------------------

3. LED INDICATORS -------------------------------------------------------------------------------

4. MENU CONTROLS ------------------------------------------------------------------------------

5. MENU OPTIONS ----------------------------------------------------------------------------------

6. BACK PANEL ---------------------------------------------------------------------------------------

7. ALARM AND VIDEO LOSS ---------------------------------------------------------------------

8. RS232 REMOTE PROTOCOL -----------------------------------------------------------------

9. TROUBLESHOOTING ---------------------------------------------------------------------------

10. TECHNICAL SPECIFICATIONS --------------------------------------------------------------

11. APPENDIX #1 – TYPICAL CONFIGURATION --------------------------------------------

12. APPENDIX #2 – CONNECTION TO A PIR MOTION SENSOR ----------------------

13. APPENDIX #3 – CONNECTION TO A LOREX TIME LAPSE VCR

FOR ALARM RECORDING ----------------------------------------------

14. APPENDIX #4 – PIN CONFIGURATIONS FOR CONNECTION TO PC ------------

SYSTEM INCLUDES

Color Quad Splitter

Owner’s Manual

12V DC Power Supply

CHECK YOUR PACKAGE TO MAKE SURE THAT YOU RECEIVED THE COMPLETE SYSTEM, INCLUDING THE COMPONENTS SHOWN ABOVE.

FRONT PANEL CONTROLS

MENU / ESC

Pressing this button performs the following functions:

1) Accesses the Menu screen;

2) Confirms selections when editing options in Menu mode;

3) Exits the Menu screen.

/ ( ▲)

Pressing this button goes to Full-Screen display of Camera 1. It also serves as the Up arrow key in Menu mode.

/ ( ▼)

Pressing this button goes to Full-Screen display of Camera 2. It also serves as the Down arrow key in Menu mode.

/ ( ◄)

Pressing this button goes to Full-Screen display of Camera 3. It also serves as the Left arrow key in Menu mode.

/ ( ►)

Pressing this button goes to Full-Screen display of Camera 4. It also serves as the Right arrow key in Menu mode.

1 2 53 4 6 7 8

9 Pin Alarm

Connector

QUAD / ( + )

Pressing this button goes to Quad display. It is also used to increase values when making selections in Menu mode.

AUTO / ( - )

Pressing this button initiates automatic sequencing between four all camera locations, in the following screen order:

CH1 ÆCH2 ÆCH3 ÆCH4 ÆQUAD ÆCH1 ……..

Note: Sequencing will automatically bypass a channel with a video loss.

VCR / FREEZE / ENTER

This button performs the following functions:

1) Press and hold this button for 3 seconds in order to enter VCR mode.

2) For the Freeze feature, press this button once. The screen will change to Quad mode, and the word “FREEZE” will

appear in the top-right corner. Press a channel button, and that corresponding channel’s screen will freeze with the

letter “Z” appearing as an indicator. You can then continue to freeze and unfreeze individual channels by pressing

their respective buttons. To exit Freeze mode, press the VCR PLAY / FREEZE / ENTER button a second time.

3) In Menu mode, pressing this button selects a menu option to be edited.

LED INDICATORS

Above each button is a red LED indicator, which shows the system’s status and helps to navigate in Menu mode.

Below is a summary of what each red LED indicator signifies:

1 2 53 4 6 7 8

1) When in Menu mode, this red indicator illuminates.

2-5) When in Full Screen viewing, the LED that is ON is the channel being viewed (CH1 / CH2 / CH3 / CH4).

When in Freeze mode, the LED’s that are ON are the channels being frozen.

During an Alarm or Video Loss, the indicator lights blink on the corresponding channels experiencing the Alarm

or Video Loss.

6) This LED illuminates when in Quad viewing mode.

7) This LED illuminates when in Auto Sequencing mode.

8) This LED illuminates when Freeze mode is activated, or blinks when in VCR mode.

NOTE: In menu mode, only relevant buttons (2~8) for programming will be illuminated.

MENU CONTROLS

Pressing the MENU button brings up the Menu screen.

Outlined below are the buttons used for navigation when using the Menu.

▲and ▼: Scroll up and down through menu options; change values.

◄and ►: Scroll sideways within a menu option that has been selected

+and -: Increase or reduce a value of a menu option when editing it (when it is blinking).

ENTER: Selects a submenu / an option in a submenu for browsing / modification

MENU: Completes modification of a menu option; exits a menu

MENU OPTIONS

( MENU )

►ALARM DURATION: 02 SEC

BAUD RATE: 9600 BPS

DWELL TIME: 02 SEC

INT AUDIBLE ALARM: ON OFF

EXT AUDIBLE ALARM: ON OFF

SET TIME: YY:MM:DD:HH:MM:SS

DWELL SETUP (CH 01): ON OFF

ALARM POLARITY (CH 01): HIGH LOW OFF

CAMERA TITLE SETUP (CH 01): CH1

EVENT LIST

VIDEO SET

SYSTEM RESET

Note: Leave the Alarm Polarity at LOW or OFF for channels with no PIR Sensor connected.

Otherwise, you will experience a continuous alarm.

Upon entering the Menu, you will see the screen shown to

the right. Below is a description of each Menu option:

Alarm Duration – Set the length of the alarm time between

1~99 seconds. Use +/- buttons to increase/

decrease duration times.

Baud Rate – Set the speed of the remote computer’s Baud Rate

which is the rate of data transmission. Available

Baud Rates are: 1200, 2400, 3600, 4800, 9600,

19200, 57600, 115200. Use +/- buttons to increase/

decrease the Baud Rate.

Dwell Time – Select how long a camera screen will appear in

Sequencing mode before switching to the next

screen. Programmable between 1~30 sec. Use +/- buttons to increase / decrease the Dwell time.

Int Audible Alarm – Activates / deactivates the alarm buzzer function of the Quad Processor.

Use the ◄/ ►buttons to set On / Off.

Ext Audible Alarm – Activates / deactivates the Alarm OUT function for external alarm devices.

Use the ◄/ ►buttons to set On / Off.

Set Time – Allows you to program the time. Use the ◄/ ►buttons to move positions, and +/- buttons to change.

Dwell Setup – Activate / deactivate by channel which cameras will be seen in Auto Sequencing. Use ▲/ ▼buttons to

select channel and ◄/ ►buttons to select On / Off.

Alarm Polarity – Select the Alarm Input for each PIR motion sensor from LOW, HIGH or OFF per channel.

LOW is the equivalent of Normally Open. HIGH is the equivalent of Normally Closed.

OFF disables the PIR Alarm feature. The setting is defaulted to LOW. Use ▲/ ▼buttons to

select channel and ◄/ ►buttons to set to High / Low / Off.

BACK PANEL

POWER INPUT

Connects to the DC 12V Power Adapter (included with the system).

VIDEO IN (Channels 1-4)

Four BNC Video camera inputs, for Channels 1-4. Connect four cameras to these inputs.

VCR IN

Receives video signal from a VCR or DVR.

MONITOR OUT

Transmits video signal to a monitor (a TV or a security monitor) in Full / Quad form – depending on the

setting of the Quad Processor.

QUAD OUT

Transmits video signal to a VCR or DVR in Quad format.

RS232 / ALARM INPUT / EXTERNAL ALARM OUTPUT

Connect PIR Motion Sensors / Magnetic Sensors to this terminal (refer to page 13) to enable Alarms.

Alternatively, connect this terminal to a PC (refer to page 13) and control system functions via a PC.

VIDEO INPUT

500 mA

DC 12V

OUT

QUADVCR

IN OUT

MONITOR ALARM

1 2 53 4 6

Camera Title Setup – Change the title for each camera that appears in the On Screen Display. Use ▲/ ▼buttons to

select channel, ◄/ ►buttons to move positions, and +/- buttons to change the number or

character. Alternatively, press the “Enter” button to disable the camera ID display.

Event List – Brings up a historical record of Video Loss and Alarm occurrences. For more information on

Video Loss and Alarm, refer to page 8.

Video Set – Adjusts the picture Brightness / Contrast / Color by channel. Select Channel 1~4, then adjust the settings.

System Reset – Returns system to factory default settings.

ALARM AND VIDEO LOSS

When an Alarm occurs, you will see the icon appear on the channel where motion detection is taking

place. If you have set the Internal Audible Alarm to ON, then you will also hear a Buzzer.

A Channel that does not have a camera connected will show the icon,

indicating a Video Loss. The red LED light above the channel with a Video Loss

will blink. If you have set the Internal Audible Alarm to ON, then you will also

hear a Buzzer when video is disconnected.

The Event List, available from the Menu and shown to the right, lists occurrences

of Alarms and Video Loss.

RS232 REMOTE PROTOCOL

The RS232 / Alarm input allows you to control the Quad Processor system from your PC. In order to

achieve this, you will require an RS232 COM Port communication program installed on your PC. There are

many of these software programs available on the internet, some of which are free.

The remote connection on the Quad Processor uses 8 data bits, 1 start bit, and 1 stop bit.

Below is an example of the data stream with the control codes shown.

The PC keyboard simulates the Quad Processor’s keypad. For example, pressing “V” will make the Quad

Processor go to VCR mode. Note that the letters are case sensitive. Below is a list of corresponding keys,

and their codes:

For further instructions on connecting the Quad Processor to your PC’s RS232 port, please refer to

Appendix #4.

ASCII FUNCTION ASCII FUNCTION

AAUTO 1CH1

QQUAD 2CH2

MMENU 3CH3

VVCR 4CH4

FFREEZE

CH EVENT YY/MM/DD TIME

------------------------

-----

CH1 VLOSS 01/02/10

12:20:15

CH2 ALARM 01/02/10

13:15:10

--- ----- --/--/-- --:--

:--

--- ----- --/--/-- --:--

:--

--- ----- --/--/-- --:--

:--

--- ----- --/--/-- --:--

:--

ACT – OxFF OxCO ID FUNCTION STOP – Ox7F

• Connect the video cable on Channel 1 before Power

ON. The system will automatically detect electrical

settings as PAL or NTSC.

Bad picture quality after Power ON

• Set the Alarm Polarity according to whether your PIR

motion sensor is Normally Open or Normally Closed.

• If no motion sensors are connected, set that channel’s

Alarm Polarity to OFF.

Continuous Alarm

• Check the power source cord connections

• Check that there is power at the outlet

No Power

• If you are using a TV as a slave monitor, you may need

to set the channel as AUX (or sometimes referred to as

“TV / Video”).

• Please check if the wiring between the monitor and the

Quad Processor is correct.

• Make sure that the camera is receiving power

Unable to view cameras

REMEDYPROBLEM

TROUBLESHOOTING

TECHNICAL SPECIFICATIONS

Because our products are subject to continuous improvement SVC reserves the right to modify product designs and specifications without notice and without incurring any obligations. E & O.E

Video input port 4 BNC camera inputs, 1 VCR input

Video output port 1 Quad output for VCR, 1 monitor output

Alarm input 4 (Normally High / Low selectable)

Alarm output 1 (Normally Open output)

Alarm duration 1 – 99 sec.

Camera Title 10 characters

Time / Date set Built-in real time clock

Dwell Time 1 – 30 sec.

RS-232 port Yes

Load impedance 75 Ohms

Operating environment 10~80%RH, 0oC~50oC

Power source DC 12V ±10%, 1A

Power consumption 6W maximum

Dimension (mm) 240(W) x 45 (H) x 150 (D)

Weight 1,300g

Table des matières

Autres manuels Lorex Système de sécurité

Lorex

Lorex L15D424321B Manuel utilisateur

Lorex

Lorex Vantage Manuel utilisateur

Lorex

Lorex SG4230 Manuel utilisateur

Lorex

Lorex L15LD400 series Manuel utilisateur

Lorex

Lorex VANTAGE LH110 ECO SERIES Manuel utilisateur

Lorex

Lorex SHS-2SA Manuel utilisateur

Lorex

Lorex SHS-2SA series Manuel utilisateur

Lorex

Lorex LHB926 Series Mode d’emploi

Lorex

Lorex LW2100 Series Manuel utilisateur

Lorex

Lorex LH316501C8 Manuel utilisateur

Lorex

Lorex LH041 Series Manuel utilisateur

Lorex

Lorex L14Q684 Guide d'installation

Lorex

Lorex L17LD420 Series Manuel utilisateur

Lorex

Lorex LHA4100 series Manuel de l'opérateur

Lorex

Lorex L222A8 Series Mode d’emploi

Lorex

Lorex SILVANIA SY15F6584 Manuel utilisateur

Lorex

Lorex VANTAGE LH110 ECO SERIES Manuel utilisateur

Lorex

Lorex SHS-2S6183W Manuel utilisateur

Lorex

Lorex SG17LD800 Mode d’emploi

Lorex

Lorex L20WD800 Series Manuel utilisateur

Lorex

Lorex LW1001 Series Manuel utilisateur

Lorex

Lorex SHS-4QM Series Manuel utilisateur

Lorex

Lorex LHB800 Series Manuel utilisateur

Lorex

Lorex SG17LD800 Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
