BUSINESS AND HOME SECURITY

PORTABLE COLOR LCD

DIGITAL WIRELESS SURVEILLANCE SYSTEM

2.4” Color LCD Monitor/Receiver

Latest Ultra Digital Wireless Technology Provides Excellent Image Quality and

Clarity

Secure signal ensures complete privacy

Interference free

Connect to any TV/Monitor/VCR/DVD Recorder

Listen in with Exceptional Sound Clarity

True Portability with Receiver’s Rechargeable Battery

Camera Can be Battery Operated for True Portable Wireless Operation

Up to 450ft (150m) Wireless Transmission Range**

Night Vision Allows for Low Light Viewing up to 15ft from Camera***

Safety Warning Feature Notifies You When out of Range

Audio Level Indicator and Alarm

Convenient Receiver Charging Cradle and Belt Clip Included

FEATURES

www.lorexcctv.com

LW2002B Series

*Additional cameras sold separately.

**Maximum outdoor open space transmission range. Actual range including indoor use dependent upon building

materials and other obstructions in path of wireless signal

***IR illumination range of 15ft (5m) under ideal conditions. Objects at or beyond this range may be partially or

completely obscured, depending on the camera application

ExPANDIBLE UP TO

FOUR CAMERAS

CONNECTS TO ANY TV

BUSINESS AND HOME SECURITY

PORTABLE COLOR LCD

DIGITAL WIRELESS MONITORING SYSTEM

As our product is subject to continuous improvement, Lorex Technology & subsidiaries reserve

the right to modify product design, specifications & prices without notice and without incurring

any obligation. E&OE

3700 Koppers Street

Baltimore, Maryland 21227,

USA.

Lorex Technology Inc.

300 Alden Road, Markham,

Ontario L3R 4C1

Canada. 5-26082008

PRODUCT INFORMATION

UPC: 7-78597-02002-1

Package Weight: 0.94kg / 2.0lbs

Package Dimensions: 298mm/11.73”(w) x81mm/3.19”(d) x

235mm/9.25”(h)

Package Cube: 0.005cbm / 0.20cbf

LW2002B 1 x 2.4” LCD receiver

1 x Indoor camera with night

vision

1 x Power adaptor for receiver

1 x Power adaptor for camera

1 x Receiver Charging Cradle

1 x RCA Video Cable

CONTENTS

SPECIFICATIONS

Imaging Sensor Type: CMOS

Picture Total Pixels: 640 x 480pxl (NTSC)

Minimum Illumination: 0Lux (IR on)

Night Video Distance: 15ft / 5m

View Angle: 50°

Image Resolution: 640 x 480 @ 30fps

Consumption Current (Max.): 360mA

Power Supply: DC + 9V

Dimensions (W x D x H): 83x65x135mm / 3.3x2.6x5.3”

Weight: 140g / 0.3lbs

LCD Screen Type: 2.36 “ TFT-LCD

Effective Pixels: 320 x 240

Receiving Sensitivity: <.81dBm

Consumption Current (Max.): 400mA

Power Supply: DC + 9V

Dimensions (W x D x H): 73x33x195mm / 2.9x1.3x7.7”

Weight: 180g / 0.4lbs

Camera

Receiver

Transmission Frequency: ISM 2,400~2,482 MHz

Transmission Power: 14dBm

Unobstructed Effective Range: 450ft / 150m

Spread Spectrum: FHSS

Modulation Mode: GFSK

Operating Tempurature: 14 ~ 104° Fahrenheit / - 10 ~ +40° Celsius)

Operating Humidity: <85%

General

LW2002BAC1 black accessory camera

UPC: 7-78597-42002-9

Package

Dimensions:

215mm/8.5”(w) x74mm/2.9”(d) x

91mm/3.6”(h)

Package Weight: 0.36kg / 0.8lb

LW2002WAC1 white accessory camera

UPC: 7-78597-52002-6

Package

Dimensions:

215mm/8.5”(w) x74mm/2.9”(d) x

91mm/3.6”(h)

Package Weight: 0.36kg / 0.8lb

ACCESSORIES
