Lorex SG19LD804-161 Guide d'installation

www.lorexcctv.com

19” LCD / 8 CHANNEL DVR

COMBO WITH 160GB HDD

& 4 CAMERAS

Overview - Video

Playback

MODEL:

SG19LD804-161

Video Playback - Overview

How do I playback Previously Recorded Data? ........................................ 3

Search By Time ........................................................................................................................... 3

Search By Event .......................................................................................................................... 4

Playback and Navigation Controls ...............................................................................................4

If you have any additional questions or technical issues, please contact the Sentinel CCTV Help

desk for further assistance at 1-888-425-6739 (Option 1 - 1) or mail your questions to

[email protected]

How do I playback Previously Recorded Data?

Search mode allows you to locate previously recorded video by Date and Time, or by Event

Type.

• Press the Search Button on the front panel

or Remote Control

• Enter the User Name and Password (if

required).

• Use the Left / Right arrows on the Front

Panel or Remote Control to switch

between the Search By Time and Search

By Event screens.

Search By Time

Searches the system based on date and time.

• Press the Enter button to access the

Calendar (on the left side of the screen).

Press a second time to change the

highlight to white.

• Navigate within the calendar using the

Arrow Keys on the front panel or remote

control.

• Once the date has been located, press the

Enter button to accept the date, and to

access the Time Search (on the right side

of the screen).

• Press and Hold the arrow keys to select the

Time (increments of 15 minutes). Pressing

the button without holding will increment 1

minutes.

• Press the Enter button to start the playback.

Press the Return button to stop playback

and return to the Search By Time screen.

NOTE: The unit will continue to record data

while in Playback Mode.

The Date and Time will be displayed at

the bottom of the screen. A playback icon

will appear indicating that the unit is in

Playback mode.

Any days highlighted with GREEN

indicate that there is recorded video data.

How do I playback Previously Recorded Data?

Search By Event

Searches the system based on Event Type (Alarm, Motion, Continuous or System).

• Press the right arrow button on the front

panel or remote control to access the

Search By Event screen.

• Select From and To dates, Events (Alarm,

Continuous, Motion and Other) and

Cameras

• Navigate within the options using the Arrow

Keys on the front panel or remote control.

Press the Enter button to select or deselect

options (Note: Multiple event types can be

selected).

• Navigate to the Start button at the bottom

of the screen and press the Enter button.

A listing of events will be displayed.

• Navigate to an event, and press the Enter button to start the playback. Press the Return

button to stop the playback.and return to the Event Search screen.

Playback and Navigation Controls

Navigation Controls - Move Up/Down/Left/Right

Play Button - Normal Speed Playback

Reverse Playback Button - Normal Speed Reverse Playback

Pause Button - Pause the onscreen Playback. The Fast Forward and Reverse playback

buttons can be used while the video is paused to move to the Next / Previous frame.

Fast Forward Button - Fast Forward the current video (2~64 Speed)

Rewind Button - Reverse playback of the current video (2~64 Speed)

Enter Button - Used to set options ON/OFF, and to start playback

Return Button - Used to stop playback, and exit menus and search mode.
