Lorex SG19LD804-161 Guide d'installation

Copyright ©2007 LOREX Technology Inc.

www.lorexcctv.com

19” LCD / 8 CHANNEL DVR

COMBO WITH 160GB HDD

& 4 CAMERAS

Overview - Auto

Recording

MODEL:

SG19LD804-161

Auto Recording Overview

2

Auto Recording Overview

How do I set the Auto-Recording to OFF? ................................................ 3

Setting An Individual Time Block ................................................................................................. 3

Setting Multiple Time Blocks ....................................................................................................... 4

If you have any additional questions or technical issues, please contact the Sentinel CCTV Help

desk for further assistance at 1-888-425-6739 (Option 1 - 1) or mail your questions to

[email protected]

How do I set the Auto-Recording to OFF?

3

How do I set the Auto-Recording to OFF?

The system is set to automatically start recording when powered on. You may wish to change

these settings to better suit your security needs. These settings can be changed for an individual

camera on one time block, or can be set for multiple cameras for multiple time blocks.

Setting An Individual Time Block

1. Enter MENU mode by pressing the MENU button

on the front panel of the system (or on the Remote

Control). Select the RECORD MENU Option.

2. Select the SIMPLE RECORDING MODE menu.

Navigate using the up and down arrows on the

front panel (or remote control). Navigate using

the arrow keys

3. Select the Channel Menu (highlights the area in

PINK).

4. Press the ENTER key to enter the configuration mode.

One time block will be highlighted in GREEN.

5. Navigate to the desired time block and press ENTER.

The selected time block will be highlighted ORANGE.

6. Press Enter once more to access the Configuration

Menu. Select NONE, CONTINUOUS, MOTION or

ALARM by pressing the UP and DOWN arrows. Press

ENTER again to accept the change.

How do I set the Auto-Recording to OFF?

4

Setting Multiple Time Blocks

1. Enter MENU mode by pressing the MENU button

on the front panel of the system (or on the Remote

Control). Select the RECORD MENU Option.

2. Select the SIMPLE RECORDING MODE menu.

Navigate using the up and down arrows on the

front panel (or remote control). Navigate using

the arrow keys

3. Select the Channel Menu (highlights the area in

PINK).

4. Press the ENTER key to enter the configuration mode.

One time block will be highlighted in GREEN.

5. Navigate to the desired time block and press

ENTER. The selected time block will be

highlighted ORANGE. Press the UP, DOWN,

LEFT and RIGHT Arrow keys to highlight multiple

time blocks.

6. Press Enter once more to access the Configuration

Menu. Select NONE, CONTINUOUS, MOTION or

ALARM by pressing the UP and DOWN arrows. Press

ENTER again to accept the change.
