Lorex LW2201 Series Manuel utilisateur

BUSINESS AND HOME SECURITY





Receiver Features:

Micro Receiver Easily Installs Anywhere

High Gain Antenna Ensures Improved Long Distance Operation

Viewing Options:

Quad Mode Shows up to 4 Camera Views on Same Screen

Switching Mode Shows all Cameras in Full Screen

View in VGA Resolution for High Quality Video or CIF for Real Time

Observation

Easily Connects to Any TV/Monitor or DVR/DVD Recorder

Safety Warning Feature Notifies You When out of Range

System Expandable up to 4 Cameras

Mix & Match Indoor and Outdoor Night Vision Cameras

Camera Features:

VGA (640x480) Resolution Camera

46ft IR Night Vision

Mechanical IR Cut Filter Moves Automatically in Front or Away from

Lens to Enhance Color Reproduction in All Lighting Conditions

Durable Metal Weatherproof Housing Ideal for Indoor/Outdoor Use

Microphone for Listen-in Surveillance



www.lorexcctv.com





 











Imaging Sensor Type: CMOS

Picture Total Pixels: 640 x 480pxl (NTSC)

Minimum Illumination: 0Lux (IR on)

Night Video Distance: 46ft / 14m

View Angle: Diagonal 48°

Consumption Current (Max.): Max 330mA

Power Supply: 12V DC

Dimensions (W x D x H): 75x160x265mm / 3x2.6x5.3”

(with antenna and sunshade)

Weight: 0.54g / 1.2lbs

Resolution Supported: 640 x 480 @ 12fps or 320 x 240 @ 30fps

Receiving Sensitivity: -81dBm

Consumption Current (Max.): 130mA

Power Supply: 12V DC

Dimensions (W x D x H): 45x98x116mm / 1.8x3.9x4.6”

(with antenna attached)

Weight: 0.1kg / 0.22lbs





Transmission Frequency: ISM 2,400~2,482 MHz

Transmission Power: 16dBm

Unobstructed Effective Range: 450ft / 150m

Spread Spectrum: FHSS

Modulation Mode: GFSK

Operating Tempurature: 14 ~ 122° Fahrenheit / - 10 ~ +50° Celsius)

Operating Humidity: <85%



BUSINESS AND HOME SECURITY





As our product is subject to continuous improvement, Lorex Technology & subsidiaries reserve

the right to modify product design, specifications & prices without notice and without incurring

any obligation. E&OE

3700 Koppers Street

Baltimore, Maryland 21227,

USA.

Lorex Technology Inc.

250 Royal Crest Court, Markham,

Ontario L3R 3S1

Canada. 3-21052009



UPC: LW2201 - English Package - 7-78597-02201-8

LW2201F - Universal Package - 7-78597-22013-1

Package Weight: 1.3kg/2.9lb

Package Dimensions:

(WxDxH)

300mm x 83mm x 198mm /

11.8” x 3.2” x 7.8”

Package Cube: 0.005m x 0.174ft

LW2201 1 x Wireless Quad Micro Receiver

1 x Color Outdoor Night Vision Camera

2 x Power Adapters

1 x RCA/BNC Adapter





 Wireless outdoor accessory camera

UPC: 7-78597-22011-7

Package Weight: 1.04kg/2.29lbs

Package Dimensions:

(WxDxH)

252mm x 202mm x 80mm /

9.9” x 8” x 3.1”

Package Cube: 0.004m x 0.141ft
