MODEL: SG6333

2.4 GHz WIRELESS B&W

SECURITY SYSTEM WITH

WEATHER RESISTANT* CAMERA

Instruction Manual

www.lorexcctv.com

English Version 1.0

Before operating the system, please read this manual

thoroughly and retain it for future reference.

This product broadcasts over public airwaves and its video and audio signals may be

intercepted without your consent.

* IP44 rated for Indoor and Outdoor use. Not recommended for direct exposure to water, rain or snow.

Explanation of two Symbols

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated "dangerous voltage“ within the

product's enclosure that may be of sufficient magnitude to

constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance(servicing) instructions in

the literature accompanying the appliance.

THE GRAPHIC SYMBOLS WITH SUPPLEMENTAL MARKING ARE ON

THE BOTTOM OF THE SYSTEM.

WARNING: To prevent fire or shock hazard, do not expose this unit to

rain, water, or wet locations. Do not insert any metallic object

through the ventilation grills.

FCC CLASS B NOTICE

Note:

This equipment has been tested and found to comply with the limits For a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instruction, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, (which can be determined by turning the equipment off and on), the

user is encouraged to try to correct the interference by one or more of the following

measures:

CAUTION

RISK OF ELECTRIC SHOCK. DO NOT OPEN.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER

(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

• Reorient or relocate the receiving antenna

• Increase the separation between the monitor and the camera.

• Connect the equipment into an outlet on a circuit different from that to which

other devices may be connected.

• Consult the dealer or an experienced radio or television technician for help.

SAFETY INSTRUCTIONS

IMPORTANT SAFEGUARDS

All the safety and operating instructions should be read before the

Appliance is operated and retained for future reference.

1. HEED WARNINGS - All warnings on the appliance and in the operating

instructions should be adhered to.

2. FOLLOW INSTRUCTIONS - All operating instructions should be

followed.

3. WATER AND MOISTURE - Do not use this video product near water –

for example, a bath tub, wash bowl, kitchen sink, laundry tub or

swimming pool, or in a wet basement.

4. POWER SOURCES - This product should be operated only from the type

of power source indicated on the marking label.

5. OVERLOADING - Do not overload outlets and extension cords, which

can result in a risk of fire or electric shock.

6. SERVICING - Do not attempt to service this product yourself. Opening or

removing covers may expose you to dangerous voltage or other hazards.

Refer all servicing or repairs to qualified service personnel.

7. DAMAGE REQUIRING SERVICE - Unplug this product from the wall

outlet and refer servicing or repairs to qualified service personnel under

the following conditions:

a. When the power supply cord or plug is damaged.

b. If liquid has been spilled or objects have fallen into the product.

c. If the product has been exposed to rain or water.

d. If the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the

operating instructions.

e. If the product has been dropped or the cabinet has been damaged.

f. When the product exhibits a distinct change in performance.

8. REPLACEMENT PARTS - When replacement parts are required, be

sure the service technician has used replacement parts that are

specified by the manufacturer or have the same characteristics as the

original part. Unauthorized substitutions may result in fire, electric

shock, or other hazards.

9. SAFETY CHECK - Upon completion of any service or repairs to this

video product, ask the service technician to perform safety checks to

determine if the video product is in proper operating condition.

10. An appliance and cart combination should be moved with care.

Do not place this equipment on an unstable cart, stand, or table.The

equipment may fall, causing serious injury to a child or adult, and

serious damage to the equipment. Wall or shelf mounting should

follow the manufacturer's instructions and should be done with

a mounting kit approved by the manufacturer.

TABLE OF CONTENTS PAGE

iii

INTRODUCTION & FEATURES………………………………………

SYSTEM INCLUDES…………………………………………………..

CONTROLS AND FUNCTIONS

Monitor …....................................….……………………..……...

Camera ...….……………..............................……….……...……

INSTALLATION

Camera ......................................................……………….…....

Monitor .....................................................................………......

SYSTEM OPERATION

Additional camera connection…………………………………….

Auto Scanning………………………………………………………

Auto & Manual Viewing Options………………………………….

Selectable Dwell Settings…………………………………………

Connecting The Monitor To A VCR ……...………………..…….

OPTIONAL ACCESSORIES ..........................................................

TROUBLE SHOOTING ..............................................………..…...

TECHNICAL SPECIFICATIONS ....................................................

CARE & MAINTENANCE……………………………..……………….

INTRODUCTION:

Thank you for purchasing the 2.4 GHz Wireless B&W Video System. This is an

ideal solution for monitoring your business or home, or for safeguarding your

valuables. The package contains a 5.5” B&W Monitor, and 1 wireless B&W

camera.

The system allows you to automatically scan between locations with the

convenience of connecting up to 4 cameras (additional cameras sold separately).

Use the Listen-in Audio feature to pick up sound within a specific location. Avoiding

the hassle of running wires, this system is easy to install and operate for your

immediate security applications.

The RCA audio/video outputs also allow you to connect a time lapse VCR or

standard VCR for recording purposes.

To learn more about this 2.4GHz Wireless B&W Video System and our complete

range of accessory products, please visit our website at:

www.lorexcctv.com

FEATURES:

• Auto Scanning – Up to 4 cameras

• Wireless range of up to 300 ft (open space, no obstacles)

• Sequential or Full Screen Viewing options

• Listen-in Audio

• Built-in Speaker with volume control

• Audio/Video outputs allow user to record picture to any standard VCR

• LED indicator lights show system status

• Weather Resistant camera rated IP44* for Indoor and Outdoor use.

• Monitor with battery option (10 “C” batteries, not included)

• Bonus clip-on stand included for quick mounting application

• Automatic IR illumination in low light conditions**

* IP44 rated for Indoor and Outdoor use. Not recommended for direct exposure to water, rain or

snow

** IR illumination range of 6ft. under ideal conditions. Objects at or beyond this range may be

partially or completely obscured, depending on the camera application.

SYSTEM INCLUDES:

5.5” – 2.4 GHz B&W Monitor 1 - 2.4 GHz B&W Wireless Camera

Also includes:

1 – 9V DC Adapter (Camera)

1 – 13.8V DC 1000mA Adapter (Monitor)

with battery option (10 “C”, not included)

1 – RCA Audio/Video Cables

Window decals

Owner’s Manual 1 - Clip-on Stand1 - Wall Mounting

Bracket

MONITOR CONTROLS – FRONT & BACK PANEL

MONITOR BACK VIEWMONITOR FRONT VIEW

Location of Receiver Monitor controls

1. 2.4GHz Antenna - High gain dipole patch antenna receives audio

and video signal from the camera.

2. CRT - 5.5” Diagonal Screen

3. Brightness Control – Allows you to adjust the brightness of the picture

4. Channel Selector - Switches between channel 1-4 / AUTO selection.

5. Auto/Manual Button - Allows you to switch from AUTO mode to the

MANUAL mode

6. Audio Mute Button – Push this button to mute the sound on the monitor

7. Volume Control – Turn this dial to adjust the volume on the monitor

8. ON/OFF Switch – Used to switch the power on the monitor ON or OFF

9. Battery Compartment (not shown) – Requires 10 “C” Batteries (not

included).

10. Speaker - Emits sound from the camera location

11. DC Input Jack – Connect to the supplied 13.8V DC 1.0A AC adapter.

12. Audio Output Jack - RCA jack for Audio output connection

13. Video Output Jack - RCA jack for Video output connection

14. Contrast Control – Allows you to adjust the contrast of the picture

11 12 13 14

45678

CAMERA CONTROLS

1. Microphone – Built-in condenser microphone provides listen-in audio

capability from camera to monitor

2. Lens – B&W CMOS Image Sensor

3. 6 Infrared LED’s – Enhances the picture quality in low light conditions*

4. Channel Selector/Power Button – Selects channels 1-4. Holding this button

for 3 seconds turns the Power ON/OFF (by default the camera is ON).

5. Bracket – Plastic bracket connects to camera for mounting to walls,

ceilings or table

6. DC IN Jack – Connects to the 9V DC adapter.

7. Sunshade Visor – Protects camera from the elements and blocks the camera

from the direct glare of the sun.

8. LED Channel Indicator – Shows the channel (1-4) that the camera is set to.

Front/Side View

* IR illumination range of 6ft. under ideal conditions. Objects at or beyond this range may be

partially or completely obscured, depending on the camera application.

CAMERA INSTALLATION

1. Attach the stand base to the wall or ceiling where you want to install the

camera. Locate a wall stud or ceiling, and secure the bracket using the

three supplied screws.

2. Secure the camera to the bracket by sliding the camera socket over the stand,

and fasten it in place with the supplied screw.

3. Connect the supplied 9V DC adapter to the DC IN jack at the rear

of the camera, and plug it into an electrical outlet. Make sure the adapter

connected to the camera is labeled camera. You can turn the camera ON/OFF by

pressing and holding the Channel button for 3 seconds (camera ON by default).

Camera mounted

To 9V Power

Adapter

Wall

OPTION #1 – Permanent Wall Mount

OPTION #2 – Temporary Mounting

1. Connect the clip-on stand

onto any object.

1. Connect the supplied 13.8V AC adapter to the DC INPUT JACK at the rear of

the receiver monitor and plug it into an electrical outlet. Make sure the adapter

connected to the monitor is labeled monitor.

BATTERY CASE & COMPARTMENT

Remove the battery case by unscrewing the bolt at the bottom of the

monitor and sliding the battery case out. This system requires 10 ‘C’ sized

batteries (not included)

Plug

Warning : To prevent damage to the unit, ensure that the batteries are

aligned properly and battery types are not mixed.

Your wireless monitor has both AC or battery option. When using the

AC option with rechargeable batteries, your monitor will automatically

switch to back up battery feature during a power outage providing you with

uninterrupted power to the monitor. The battery option also provides you

the flexibility to move the monitor from room to room. Battery life is

approximately 2 –3 hours

DC INPUT Jack

13.8V 1.0 A

AC Adapter

MONITOR INSTALLATION

Table des matières

Autres manuels Lorex Système de sécurité

Lorex

Lorex WA-410 Manuel utilisateur

Lorex

Lorex L15LD400 series Manuel utilisateur

Lorex

Lorex LHWF1000 Series Manuel utilisateur

Lorex

Lorex SG21CD7484UQ-A80 Manuel utilisateur

Lorex

Lorex LW2902 Manuel utilisateur

Lorex

Lorex L20WD800 Series Manuel utilisateur

Lorex

Lorex SHS-4WLS Manuel utilisateur

Lorex

Lorex SHS-4QM Series Manuel utilisateur

Lorex

Lorex LW2960 SERIES Manuel utilisateur

Lorex

Lorex LW2770 SERIES Manuel utilisateur

Lorex

Lorex LH316501C8 Manuel utilisateur

Lorex

Lorex SG19LD804-161 Guide d'installation

Lorex

Lorex LW2002 Series Manuel utilisateur

Lorex

Lorex LW2311 Manuel utilisateur

Lorex

Lorex LW2002B Series Manuel utilisateur

Lorex

Lorex LW2300 SERIES Manuel utilisateur

Lorex

Lorex LWB3800 Series Mode d’emploi

Lorex

Lorex LW2700 SERIES Manuel utilisateur

Lorex

Lorex SG850 Manuel utilisateur

Lorex

Lorex SG17LD800 Guide d'installation

Lorex

Lorex SG6352 Manuel utilisateur

Lorex

Lorex D881 Series Manuel utilisateur

Lorex

Lorex SHS-2S6183W Manuel utilisateur

Lorex

Lorex SHS-4SM Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
