Logitech G903 Manuel utilisateur

G903

LIGHTSPEED Wireless Gaming Mouse

Souris gaming sans l LIGHTSPEED

SETUP GUIDE |GUIDE D’INSTALLATION

Important Safety, Compliance and

Warranty Information

Informations importantes

concernant la sécurité,

la mise en conformité et la garantie

ENGLISH . . . . . . . . . . . . . . . . . . . . . . . . .3

FRANÇAIS . . . . . . . . . . . . . . . . . . . . . . . 10

ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . . 17

PORTUGUÊS . . . . . . . . . . . . . . . . . . . . . . 24

3ENGLISH

SETUP INSTRUCTIONS

1 Remove the protective lm on the bottom side of the mouse

before use. This lm is designed to protect the sensor from

dust during transport, and your mouse may not function

unless this is removed.

2 A wireless receiver, USB adapter, and optional 10g weight can

be found in theaccessory box. Plug one end of the cable into

your PC, andtheother end into the USB adapter and receiver.

–The receiver can also be used plugged directly into

yourPC. However, using the cable and adapter when

in wireless mode is recommended and allows for better

connectivity and easy access to the cable for recharging.

3 Turn mouse on via the switch on the bottom of the mouse.

10g

4ENGLISH

4 To charge, disconnect the cable from the adapter and

plug into the front of the mouse. Your mouse will operate

in data-over-cable mode whenever it is plugged in directly

toaPC. Full charge from empty requires approximately

twohours plugged in to a PC USB port.

Tips:

–Keep the mouse and receiver 2 m+ away from wireless

routersor other 2.4GHz wireless devices to minimize

environmental noise.

–G903 has a wireless range of up to 10 meters. Toensure

optimal performance in noisy wireless environments,

andtokeep the charging cable easily accessible,

itisrecommended to keep the receiver within 20 cm

ofthemouse.

2 m+

20 cm-

5ENGLISH

BUTTON CONFIGURATIONS

G903 comes with replaceable buttons and button caps,

whichare held onto the mouse magnetically. These should be

stored in box when not in use. These replaceable buttons support

conversion to the following congurations:

1 Left handed

2 Right handed

3 No buttons

4 Full buttons

1 2

3 4

6ENGLISH

11 FULLY PROGRAMMABLE BUTTONS

1 Left (Button 1)

2 Right (Button 2)

3 Wheel click (Button 3)

4 Back (Button 4)

5 Forward (Button 5)

6 Back (Button 6)

7 Forward (Button 7)

8 Scroll left (wheel tilt left)

9 Wheel mode shift (not programmable)

10 DPI Down (Button -)

11 Scroll right (wheel tilt right)

12 DPI Up (Button +)

13 On/O switch (bottom of mouse, not programmable)

14 Prole Select (bottom of mouse, not programmable)

15 Weight door

7ENGLISH

WIRELESS BATTERY LIFE

G903 has a rechargeable 720mAH LiPol battery which provides

it with up to 32 hours non-stop gaming at 1ms report rate

withlights o, or 24 hours non-stop gaming at 1ms report rate

with RGB color cycling on.*

–Charge level can be checked when the mouse is poweredon

orusing Logitech Gaming Software to assign a button

tocheck charge level.

–Charge level is displayed for seven seconds at mouse

power-onusing the color and number of bars illuminated

onthe DPI indicator:

–3 green bars = 50–100%

–2 orange bars = 30–50%

–1 red bar = 15–30%

–1 ashing red bar = <15%

Tip: You can program a button to show charge level

usingLGS.

–The left DPI LED will ash red when battery is at 15% or less.

When this happens, plug in your mouse to charge.

–Charge level, power draw, and estimated remaining battery

life can be checked in Logitech Gaming Software

*Battery life and capacity may vary with age and use. Rechargeable batteries have a limited

number of charge cycles.

8ENGLISH

CHARGING/DATA OVER CABLE

Plug your mouse in via the provided USB charging cable when

the battery is low. G903 is also compatible with the Logitech G

POWERPLAY wireless charging system, sold separately.

RGB PROGRAMMABLE LIGHTING

G903 has two lighting zones

1 DPI indicators

2 G logo

These colors can be customized using Logitech Gaming Software

to a variety of breathing, color cycling, or solid color modes.

Lighting patterns can also be synchronized with other supported

Logitech G devices using this software.

9ENGLISH

LOGITECH GAMING SOFTWARE

You can customize the 5 onboard proles of the G903 using

the Logitech Gaming Software. These settings include surface

tuning, button programming, lighting color, lighting eects,

report rate, and tracking behavior. G903 allows up to 5 DPI

settings per prole.

By default, G903 has 1 active onboard prole with

thefollowingsettings:

–DPI: 400/800/1600/3200/6400

–RGB lighting: color cycle

–Report rate: 1ms

DPI/ONBOARD PROFILE INDICATORS

DPI/Onboard proles are shown using three LEDs under

the-/+ buttons. The image below shows which values are being

indicated by the LED panel.

DPI/Prole 1DPI/Prole 2

DPI/Prole 4DPI/Prole 5

DPI/Prole 3

HYPERFAST SCROLL WHEEL

G903 features Logitech’s exclusive dual-mode Hyperfast scroll

wheel. Click the button right below the wheel to switch between

the two modes.

Wheel mode shift

QUESTIONS

http://support.logitech.com/product/g903

10 FRANÇAIS

INSTRUCTIONS D'INSTALLATION

1 Retirez le lm protecteur sous la souris avant utilisation.

Celm est conçu pour protéger le capteur de la poussière

durant le transport et pourrait empêcher votre souris

defonctionner.

2 Vous trouverez un récepteur sans l, un adaptateur USB

etunpoids de 10g en option dans la boîte des accessoires.

Branchez l'une des extrémités du câble à votre ordinateur

etl'autre à l'adaptateur et récepteur USB.

–Vous pouvez également brancher directement

lerécepteursur votre PC. Cependant, il est recommandé

d'utiliser lecâble et l'adaptateur en mode sans l,

carilspermettent d'améliorer la connectivité et l'accès

aucâble pour la recharge.

3 Mettez la souris sous tension à l'aide du commutateur situé

sous la souris.

10g
