Logitech FabricSkin Manuel utilisateur
FabricSkin Keyboard Folio
FPO
Setup Guide|Guide d’installation
English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Português . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Logitech FabricSkin Keyboard Folio
2 English
Know your product
1. iPad® holder
2. Protective cover
3. Function keys
4. Bluetooth® and battery status light
5. Keyboard
6. Bluetooth connect button
7. Micro-USB charging port
8. Micro-USB cable
Set up your folio
Open the folio and insert your iPad in the frame
Move the frame into the typing position
The Keyboard Folio automatically powers on and the status light
blinks green for two seconds. The status light turns blue to indicate
the folio is ready for pairing.
Note: The status light briefly flashes red if your batteries are low. See “Charge
the batteries.”
Set up Bluetooth
On your iPad, turn on Bluetooth in Settings > General.
Open the devices menu and tap the Logitech Folio icon. If a PIN in
is required, enter it on the folio keyboard.
The status light on the folio turns solid blue to indicate a successful
Bluetooth connection.
Connecting to another iPad
You can easily use the Keyboard Folio with another iPad. Insert the
iPad into the folio frame, rotate the frame into the typing position,
and follow the instructions in “Set up Bluetooth.”
Charge the batteries
Charge your folio batteries if the status light blinks red after
power-on.
Lift the power port cap and plug the Micro-USB cable into the
charging port.
Plug the other end of the cable into a USB port on your laptop.
The status light blinks green as the folio charges, then turns solid
green at full charge.
When fully charged, the battery powers your folio for about 3
months (assuming an average of two hours of use per day).
The folio enters sleep mode if powered on but not in use. Press any
key to wake.
8
7
6
5
2
3
4
1
USB
Logitech FabricSkin Keyboard Folio
English 3
Using the folio with your iPad
Powering your iPad on/o
Opening the Keyboard Folio powers on your iPad. Closing the folio
powers off your iPad.
Two viewing angles
The folio frame provides two viewing positions—one for typing
and another for browsing. Moving your folio frame into the typing
position automatically powers on the keyboard. Placing the frame in
browsing position automatically powers off the keyboard.
Function keys
Key Description Key Description
Display Home Back
Lock/unlock
screen Play/pause
Start Siri Forward
Start iPad search Mute
Switch languages Volume down
Show/hide
keyboard Volume up
Slideshow
Status-light indicators
Light Description
Blinking green Battery is charging
Green The battery is charged
Red Bluetooth connection established; battery
power is low (less than 20% charge). Recharge
the Keyboard Folio.
Blinking blue The Keyboard Folio is attempting to make a
Bluetooth connection to the iPad; the battery
is charged.
Solid blue Bluetooth pairing is successful
Product Central
Visit Product Central, your online destination for world-class
support. www.logitech.com/support/fabricskinkeyboardfolio
Find tutorials, troubleshooting tips, and guidelines for using your
new folio. Product Central is also home to lively forums that connect
you to a global community of knowledgeable users.
Troubleshooting
Keyboard Folio not working?
•Move the iPad holder into typing position. The Keyboard Folio
does not work if the iPad holder is incorrectly placed.
•Press any key to wake the Keyboard Folio from sleep mode.
•Recharge the folio batteries. For more information, see “Charge
the batteries.”
•Re-establish the Bluetooth connection between the Keyboard
Folio and iPad:
Verify that iPad’s Bluetooth feature is turned on.
Choose “Logitech Keyboard Folio XX” from the Devices menu on
your iPad. The status light briefly turns blue after the Bluetooth
connection is made.
What do you think?
Please take a minute to tell us.
Thank you for purchasing our product.
www.logitech.com/ithink
Typing position Browsing position
www.logitech.com/support/fabricskinkeyboardfolio
Argentina +00800-555-3284
Brasil +0 800-891-4173
Canada +1 866-934-5644
Chile 1230 020 5484
Colombia 01-800-913-6668
Latin America +1 800-578-9619
Mexico 01.800.800.4500
United States +1 646-454-3200
© 2013 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may be registered. Apple and iPad mini are trademarks of Apple Inc.,
registered in the U.S. and other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc. All other trademarks are the property of their respective owners. Logitech assumes no
responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice.
© 2013 Logitech. Tous droits réservés. Logitech, le logo Logitech et les autres marques Logitech sont la propriété de Logitech et sont susceptibles d’être déposés. Apple et iPad mini sont
des marques déposées d’Apple Inc., enregistrées aux Etats-Unis et dans d’autres pays. Bluetooth est une marque déposée de Bluetooth SIG, Inc. Toutes les autres marques commerciales
sont la propriété de leurs détenteurs respectifs. Logitech décline toute responsabilité en cas d’erreurs dans ce manuel. Les informations énoncées dans ce document peuvent faire l’objet de
modifications sans avis préalable.
620-004904.002
www.logitech.com
