User Manual of Product 1:

Logitech YR0073 MX Keys Advanced Wireless Illuminated

Keyboard for Mac, Backlit LED Keys, Bluetooth, USB-C,

MacBook Pro, Macbook Air, iMac, iPad Compatible, Metal

Build, Silver

User Manual of Product 2:

Logitech MX Master 2S Wireless Mouse with Flow

Cross-Computer Control and File Sharing for PC and Mac, Grey

Getting Started - MX Keys for Mac

QUICK SETUP

Go to the interactive setup guide for quick interactive setup instructions.

If you want more in-depth information, go to the ‘Detailed Setup’ below.

DETAILED SETUP

1. Make sure the keyboard is turned on.

The number 1 LED on the keyboard should blink quickly.

NOTE: If the LED is not blinking quickly, perform a long press (three seconds).

2. Choose how you want to connect.

Important

FileVault is an encryption system available on some Mac computers. When enabled, it

might prevent Bluetooth® devices from connecting with your computer if you have not

yet logged in. If you have FileVault enabled, we recommend using a Logitech USB

receiver to use your mouse. If you need more information, click here.

oUse the included wireless receiver:

Plug the receiver into a USB port on your computer. If you are working on a

desktop, we recommend using the USB receiver.

oConnect using Bluetooth:

Open the Bluetooth settings on your computer to complete the pairing.

Click here for more details on how to do this on your computer. If you

experience issues with Bluetooth, click here for Bluetooth troubleshooting.

3. Install Logi Options+ Software

Download Logi Options+ to use all the possibilities this keyboard has to offer. To

download and learn more, go to logitech.com/optionsplus.

PAIR TO A SECOND COMPUTER WITH EASY-SWITCH

Your keyboard can be paired with up to three different computers using the Easy-Switch button

to change the channel.

1. Select the channel you want and press and hold the Easy-Switch button for three

seconds. This will put the keyboard in discoverable mode so that it can be seen by your

computer. The LED will start blinking quickly.

2. To connect your keyboard to your computer:

oBluetooth: Open the Bluetooth settings on your computer to complete the

pairing. You can find more details here.

oUSB receiver: Plug the receiver to a USB port, open Logitech Options, and select:

Add devices > Setup Unifying device, and follow the instructions.

3. Once paired, a short press on the Easy-Switch button will allow you to switch channels.

INSTALL SOFTWARE

Download Logi Options+ to use all the possibilities this keyboard has to offer. To download and

learn more about the possibilities go to logitech.com/optionsplus.

Click here for the list of supported OS versions for Options+.

LEARN MORE ABOUT YOUR PRODUCT

Product Overview

1 - Mac layout

2 - Easy-Switch keys

3 - ON/OFF switch

4 - Battery status LED and ambient light sensor

Battery Status Notification

Your keyboard will let you know when it is running low. From 100% to 11% your LED will be

green. From 10% and below, the LED will be red. You can continue typing for more than 500

hours without backlighting when the battery is low.

Plug the USB-C cable at the top right corner of your keyboard. You can continue typing while it

is charging.

Smart backlighting

Your keyboard has an embedded ambient light sensor that reads and adapts the level of

backlighting accordingly.

Room brightness

Backlight level

Low light - under 100 lux

L2 - 25%

Mid light - between 100 and 200 lux

L4 - 50%

High light - over 200 lux

L0 - no backlight*

Backlight is turned OFF.

There are eight backlight levels.

You can change the backlight levels at any time, with two exceptions: the backlight cannot be

turned ON when:

•The room brightness is high (above 200 lux)

•The keyboard battery is low (below 10%)

Software notifications

Install Logitech Options+ software to get the most out of your keyboard. Click

logitech.com/optionsplus for more information.

1. Backlight level notifications

Change the backlight level and to know in real-time what level you have.

2. Backlighting disabled

There are two factors that will disable backlighting:

When your keyboard has only 10% of battery left when you try to enable backlighting,

this message will appear. If you want backlight back, plug your keyboard to charge.

When the environment around you is too bright, your keyboard will automatically

disable backlighting to avoid using it when not needed. This will also allow you to use it

longer with backlight in low light conditions. You will see this notification when you try

to turn backlighting ON.

3. Low battery

When your keyboard reaches 10% of battery left, backlighting turns OFF and you get a

battery notification on the screen.

4. F-Keys switch

Press Fn + Esc to swap between Media keys and F-Keys. We’ve added a notification to

let you know you’ve swapped.

NOTE: By default, the keyboard has direct access to Media Keys.

Logitech Flow

You can work on multiple computers with your MX Keys keyboard. With a Flow-enabled

Logitech mouse, such as MX Master 3, you can work and type on multiple computers with the

same mouse and keyboard using Logitech Flow technology.

You can use the mouse cursor to move from one computer to the next. The MX Keys keyboard

will follow the mouse and switch computers at the same time. You can even copy and paste

between computers. You will need to install Logi Options+ software on both computers and

follow these instructions.

You can check which other mice are Flow enabled here.

Eject key functions

Does nothing on its own

Dialog box for sleep, restart, and

shutdown

Sleep

Restart

Turn off

Puts display to sleep but Mac is

awake

GETTING STARTED

Questions about your MX MASTER 2S? We've got the answers, videos, downloads and information you

need. Search for articles or select a topic below to get started.

Step-1

Download Logitech Options to use all the possibilities this mouse has to offer. To download and

learn more about the possibilities go to logitech.com/options.

Step-2

Turn your mouse on.

Step-3

This mouse allows you to use it with up to three different computers. Just use the Easy-Switch™

button to change the channel. Select the channel you want and go to the next step.

Step-4

To connect your mouse to your computer press the Easy-Switch™ button for 3 seconds. When it

blinks fast it means it's in discoverable mode.

Step-5

Choose if you want to pair with Bluetooth or with the provided Unifying receiver.

Product Overview:

MX MASTER 2S AT A GLANCE

1 –Speed-adaptive scroll wheel

6 –Darkfield high precision sensor

2 –Manual shift button

7 –Easy-Switch & connect button

3 –Gesture button

8 –Battery status LED

4 –Micro USB port

9 –Thumb wheel

5 –On/Off button

10 –Back/forward buttons

Features:

Speed adaptive scroll-wheel

If SmartShift™ is enabled, the speed-adaptive scroll wheel shifts between two scrolling modes

automatically, in response to your touch.

•Click-to-click (ratchet) mode —ideal for precise navigation of items and lists.

•Hyper-fast (freespin) mode —near-frictionless spinning, letting you fly through long documents and

web pages.
