Logitech ZONE VIBE 100 Manuel utilisateur

ZONE VIBE 100

Setup Guide

KNOW YOUR PRODUCT

Front view:

Back view:

Microphone boom

Music controlbutton

(play/ pause/

nexttrack)

Call button

(answer / end / reject calls)

Volume up / down

3English

Bottom view:

3-position switch

(power / Bluetooth®

pairing)

Mute button

USB-C port

LED light

4English

USB-C USB-C

BOX CONTENT

1. Zone Vibe 100 wireless headphones

2. Charging cable

3. Travel bag

4. User documentation

POWER ON / OFF

1. Slide the switch in the arrow’s direction

tothemiddle to power on the headphones.

2. Once powered on, the LED light will slightly

turnwhite.

3. There will be a voice prompt that tells you

thebattery status.

5English

LOGI Zone Vibe 100

2 sec.

CONNECT YOUR HEADPHONES

Connect via BLUETOOTH®

1. Slide the switch to the bottom in the arrow’s

direction for 2 seconds to initiate pairing.

2. The LED light will ash white rapidly.

3. Open Bluetooth®settings on your device.

4. Select Logi Zone Vibe 100 in discoverable devices.

5. Once successfully paired, the LED light will turn

solid white.

ADJUSTING HEADPHONES

1. Adjust the headphones by sliding earcups up

anddown the extended part of the headband.

2. It may be easier to adjust the headphones on

your head. Slide the earcups up and down

theheadband until they sit comfortably on

yourears.

6English

HEADPHONES CONTROLS

Note:

- Media control functionality depends on the type of application.

- Call activities are always the rst priority. When two Bluetooth®devices are connected,

the last active device will override the other.

Tip: Music EQ controls available on Logi Tune.

For UC controls:

Usage Button Action

Call controls

Answer / End call

Call button

Short press

Reject call 2 sec. press

Music controls

Play / Pause

Music control button

Short press

Track forward Double press

Volume

Volume up "+"

Short press

Volume down "-"

Connectivity Bluetooth®pairing Power button 2 sec. press

L L L

Voice notications indicate

when the microphone is on /

o mute.

Mute

"Mute on"

"Mute o"

MUTE

There are 2 ways to mute your microphone.

Press the button to mute. Flip up or down the mic

boom to mute or unmute.

7English

HEADPHONES LIGHT INDICATOR

Note:

- User-triggered behaviors, such as Bluetooth®pairing, will be prioritized then revert back to its previous status once the

behavior is completed.

Category Status Light

White

Power

Power ON Turn solid white and then dim

Battery charging Breathing

Battery fully charged Solid and then o

Connectivity

Bluetooth®pairing Fast blinking

Bluetooth®connected Turn solid white and then dim

Calls

Active call Solid

Incoming call Slow blinking

Red

Calls Mute Solid

Power Low battery (< 10%) Slow blinking

Factory reset Fast blink from red to white for

three times then LED turn o

CHARGING

To conserve battery life, headphones

automatically power o aer 30 minutes

without usage.

Sleep timer could be adjusted in Logi Tune.

The LED light on the headphones will blink slowly

in RED when the battery is low.

Charging via USB cable

1. Plug one end of the cable to the USB-C port

onthebottom of the earcup and the other end

into the USB-C charging port on your computer.

2. The LED light will start breathing white when

charging.

3. The LED light will turn solid white when

fullycharged.

– 2 hours will fully charge the battery.

– 5 minutes will give you 1 hour of playback.

4. The headphones can be used with Bluetooth®

paired while charging.

8English

LOGI TUNE

Logi Tune helps boost your headphones performance

withperiodic soware and rmware updates.

It is recommended to update your headphones.

Todoso, download Logi Tune from

www.logitech.com/tune

Logi Tune

ADJUSTING SIDETONE

Sidetone lets you hear your own voice during

conversations so you are aware of how loud

youaretalking. In Logi Tune, select the sidetone

feature, andadjust the dial accordingly.

 A higher number means you hear more

externalsound.

 A lower number means you hear less

externalsound.

AUTO SLEEP TIMER

By default, your headphones will automatically

power o when not in use for 30 minutes.

Adjustthe sleep timer in Logi Tune. To wake up

yourheadphones, try sliding o/on the power

switch again.

RESET YOUR HEADPHONES

1. Power the headphones on.

2. Press and hold the call button and volume ’–’

button for 5 seconds.

3. The LED light will quickly blink from red

towhite for 3 times and then turns o when

yourheadphones are successfully reset.

4. The headphones will turn o aer reset.

9English

Headphones:

Height x Width x Depth: 183.03 x 169.68 x 73 mm

Weight: 0.185 Kg

Earpad:

Height x Width x Depth: 98.6 x 75.44 x 19.3 mm

DIMENSIONS

Works with common calling applications across almost all platforms

andoperatingsystems.

Works with Windows, Mac, or Chrome-based computers via Bluetooth®and iOS

orAndroid Bluetooth-enabled devices.

SYSTEM REQUIREMENTS

Microphone Type: Dual omni-directional MEMS mics with directional beamforming

and DSP

Frequency response (Speaker): 20-20kHz (music mode), 100-8kHz (talk mode)

Frequency response (Microphone): 100-8kHz

Talk time up to 18 hrs

Listen time up to 20 hrs

Bluetooth®version: 5.2

Wireless range: Up to 30 m / 100  (open eld line of sight)

Cable length (USB-C charging cable): 4.9  (1.5 m)

TECHNICAL SPECIFICATIONS

www.logitech.com/support/zonevibe100

LogitechEurope S.A. and/or its aliates in the U.S. and other countries. The Bluetooth®word mark andlogos

are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Logitech is under license.

Windows, Mac, Chrome, iOS, Android and other trademarks are the property of their respectiveowners.

Logitech assumes no responsibility for any errors that may appear in this manual. Information contained

herein is subject to change without notice.
