Listen LT-82 Guide de référence

LT-82 Quick Reference Card

Input Level Indicators: Shows audio Input 1 and Input 2 levels.

Input 1 and 2:

Adjust audio input

levels of Input 1 and

Input 2 here.

Power: ON/OFF

Test Tone: Activates a tone

to aid system setup.

Transmit Level Indicator: Shows mixed audio level.

Process LED: Indicates audio processing mode is active.

Stereo LED: Indicates stereo mode is active.

LCD Display:

See LCD Display below.

Monitor Jack:

Plug in a headset to monitor audio.

Transmit Level: Adjusts mixed

audio levels.

Channel Select Up

and Down: Use to

select channel.

Buttons also used

for programming

functions.

Contour: Equalization ad-

justment; boosts or cuts

high frequencies.

RF Output Indicator:

Indicates transmitter is

outputting RF.

Channel Display: Displays what channel the LT-82 is

currently on.

Lock Icon: Indicates the unit is locked on current

channel.

Program Mode: Indicates the unit is in program

mode.

LT-82 Quick Reference Card

For further details regarding your Listen products please visit our website at

www.listentech.com Resources/Support/Manuals.

Power Input: Connect power

supply here (included).

Power Outputs: Can be used to

power up to two radiators.

Audio Outputs: Input 1 and Input 2

mixed audio outputs.

Input 2: Audio inputs;

stereo or mono.

Input 2 Level Switch: Set switch

to match the level of your Input

2 source.

RF Input:

Input additional RF signal

here for multi-channel

systems.

RF Outputs: Output RF

signal to radiator(s) and/or

additional LT-82.

Input 1: Balanced input

for connection of a line

level or microphone;

accepts either a XLR or

¼” phono plug.

Input 1 Level Switch: Set

switch for line or mic

level. Phantom power

available in Mic-PH

Power position.
