LINSHANG LS132 Manuel utilisateur
Shenzhen Linshang Technology Co., Ltd.
4-19-2021 Page 1 of 8
LS132
UV Energy Meter
User Manual V2.01
Please read this manual carefully before using and reserve it for reference.
Shenzhen Linshang Technology Co., Ltd.
4-19-2021 Page 2 of 8
I. Product Introduction
UV energy meter can measure UV energy, UV intensity and temperature at the same time. It is suitable
for UV energy, UV intensity and temperature detection of UV curing machines, UV dryers, mobile phone
UV coating machines, exposure machines, printing machines and other equipment. This meter is suitable
for measuring the UV intensity and UV energy of ultraviolet light in high-pressure mercury lamps, halogen
lamps and other light sources.
II. Parameters
1. Spectral range: 315nm ~ 400nm, λp = 365nm
2. Irradiance measuring range: 0 ~ 2000mW/cm2
3. Irradiance resolution: 0.1mW/cm2
4. Energy measuring range: 0 ~ 999999mJ/cm2
5. Energy measuring accuracy: ±10%, ±5% (typical)
6. Sampling speed: 2048 times/second
7. Recording period: 32 minutes
8. Temperature measuring range: -55°C ~ +125°C
9. Power supply: Rechargeable lithium batteries 3.7V@400mAh
10. Display: 128*64 Dot matrix OLED
11. Dimension: 95mm*44 mm*7.6 mm（L*W*H）
12. Weight: 57g
Shenzhen Linshang Technology Co., Ltd.
4-19-2021 Page 3 of 8
III. Spectral response curve
IV. Characteristics
1. Adopt ultra-small size design, the thickness is 7.6mm and the width is 44mm.
2. High-precision and quick-response temperature detector, dynamically measuring the actual
temperature in the UV curing machine.
3. Built-in timer, the meter can accurately record and display the UV curing time.
4. Metal shell, high temperature resistant design, the meter can run in an environment of 100℃for a
long time.
5. The stored data will not be lost when the power is off and the last test data will be displayed
automatically after power on.
6. High accuracy, the meter can pass the inspection of China Institute of Metrology.
V. Operation
1. Parameter setting
In OFF mode, long press the “POWER” button for 3s and enter the parameter setting mode:
A. Trigger mode: Auto/Manual
Short press the “SELECT” button and select Auto/Manual
Select Auto, the automatic trigger mode, when the power value is greater than the selected trigger
Shenzhen Linshang Technology Co., Ltd.
4-19-2021 Page 4 of 8
value, the measurement is automatically started.
Select Manual, short press the “POWER” button start a measurement and end a measurement.
Short press the “POWER” button to confirm and start another setting. Choose “Auto”, the meter enters
the trigger power valuesetting interface; SelectManual, themeter entersthe smooth setting interface.
Note: For the recording time is only 32 minutes, if the production line is very long and need a long
time to reach the UV Lamp position, the “AUTO” mode must be selected.
B. Trigger power: 0.1-5.0mW/cm²can be set
Short press the “SELECT” button to set the trigger power value and you can long press the button for
quick setting.
Short press the “POWER” button to confirm the setting and the meter enters the smooth interface.
C. Smooth: 50HZ/60HZ
If the UV light source uses AC power supply, the frequency of the AC power will affect the accuracy
of the power measurement. Short press the "SELECT" button to select the power frequency of the
light source (select 50HZ for DC power supply).
50HZ: 50HZ AC.
60HZ: 60HZ AC.
Short press the "POWER" button to confirm the setting and enter the “STOP” interface.
D. Factory default settings
Trigger mode: Manual
Smooth: 50HZ
2. ON/OFF
In POWER OFF state, short press “POWER” button to power on the meter. After turning on the meter,
the meter displays the calibration coefficient, version number, serial number, etc. and then enters the
Shenzhen Linshang Technology Co., Ltd.
4-19-2021 Page 5 of 8
last measurement interface (STOP interface).As shown below:
In the “STOP” interface, long press the “POWER” button to power off the meter.
In the “STOP” interface, the meter will automatically power off in 3 minutes without any operation.
In the automatic trigger measurement “Ready” state, the longest waiting time is 50 minutes. If the
measurement cannot be triggered within 50 minutes, it will automatically turn off.
3. Measurement
In the measurement mode, three operation states exist:
READY: Ready state; in the auto trigger mode, this means the meter is waiting for triggering to begin a
measurement.
RUN: Measuring state; this means the meter is measuring data.
STOP: Measurement is over.
In measurement interface:
M: Manual measurement mode
A: Auto measurement mode
1) Manual measurement mode: in the STOPinterface. Short pressthe "POWER" button and then short
press the "SELECT" button to confirm the new measurement, clear the historical data (display "-----"),
automatically enter the measurement interface (RUN state) after 1s. The interface dynamically
displays energy E, real-time power value P, real-time temperature value T, measurement time. Short
press the "POWER" button or after 32 minutes, the measurement is over and enter the STOPinterface.
The interface displays the measurement result energy E, maximum power value PMAX, maximum
temperature value TMAX and measurement time.
2) Automatic mode: After pressing the button to confirm the new measurement, the meter enter the
READY state to clear the historical data and wait for the trigger condition (Trigger power) to be met,
the energy display "----" and flashing. When the power value is greater than the set trigger power, the
Shenzhen Linshang Technology Co., Ltd.
4-19-2021 Page 6 of 8
trigger condition is met, enter the measurement interface (RUN state). The interface dynamically
displays energy E, real-time power value P, real-time temperature value T and measurement time.
When the recording time reaches 32 minutes or the power value is less than the set trigger power, the
measurement is automatically ended and enters the STOP interface. The interface displays the
measurement result energy E, maximum power value PMAX, maximum temperature value TMAX and
measurement time.
In the stop status, long press the "SELECT" key to clear the current test data.
4. Charging
This meter has a built-in lithium rechargeable battery. Please charge it in time when the battery symbol on
the screen is empty during use. After plugging in the charger, the energy bar in the battery symbol
increases, indicating that it is charging. Charging can be done in the following ways:
1. Use an USB data cable, plug it directly into the USB port of the computer.
2. Use the matching 5V switching power supply.
3. The mobile power supply for smart phones.
VI. Measurement and Notes
1. The sensor must face the UV light source.
2. When not in use, please long press the “POWER” button turn off the meter.
3. Avoid contact with corrosive materials and keep away from high humidity.
4. Please put it in the specialized package after power-off and keep properly.
5. The suggested calibrating period is one year and our company has the standard light source and
provides calibration service. (The previous calibration time “Calibration: year/month/day” will be
displayed on the boot screen.)
6. For the UV sensor is very sensitive to humidity, the storage environment is very important. For a long
time storage, please be sure to keep the meter in dry environment.
VII. Heat Shield
Equipped with heat shield to avoid damage to the screen caused by high-power UV lamps irradiating the
instrument at close range.
Shenzhen Linshang Technology Co., Ltd.
4-19-2021 Page 7 of 8
No Heat Shield Using Heat Shield
VIII. Packing details
No.
Description
Quantity
Unit
1
UV Energy Meter
1
pcs
2
USB data cable
1
pcs
3
DC5V Power adapter
1
pcs
4
User Manual
1
pcs
5
Certificate/Warranty card
1
pcs
6
Plastic Case
1
pcs
7
Heat Shield
1
pcs
IX. Service
1. The meter has one-year warranty. If the meter works abnormally, please send the whole meter to the
company for maintenance.
2. Provide users with spare parts and lifelong maintenance services.
3. Provide the users with the meter inspection service for free.
Shenzhen Linshang Technology Co., Ltd.
4-19-2021 Page 8 of 8
4. Free technical support for long term.
Manufacturer: Shenzhen Linshang Technology Co., Ltd.
Website: www.linshangtech.com
Service hotline: 086-755-86263411
Email: sales21@linshangtech.com
