LinMot EM01-48 Manuel utilisateur

NTI AG / LinMot Dok-Nr. 0185-0173-E_1V1_IG_Linear_Guides_EM01-48

Installation Guide

Linear Modules

ENG

EM01-48

Installation Guide Linear Modules ENG
Page 2 / 36 EM01-48 NTI AG / LinMot
Content
1General Information ................................................................................................................................. 4
1 Introduction........................................................................................................................................ 4
2 Explanation of Symbols..................................................................................................................... 4
3 Qualified Personnel ........................................................................................................................... 4
4 Liability............................................................................................................................................... 4
5 Copyright............................................................................................................................................ 4
2Safety Instructions ................................................................................................................................... 5
3Intended Use............................................................................................................................................. 7
1 Designation Code.............................................................................................................................. 7
2 EM01 Linear Module.......................................................................................................................... 7
3 Option External Sensor...................................................................................................................... 8
4 Technical Data Carriage Kits............................................................................................................. 8
4Installation Instructions........................................................................................................................... 9
1 Installation Options ............................................................................................................................ 9
1.1Installation Examples..................................................................................................................... 9
2 Installation of the Load..................................................................................................................... 10
5Electrical Connection............................................................................................................................. 11
1 Motor Cable ..................................................................................................................................... 11
2 C-Connector Wiring......................................................................................................................... 11
6Start-up.................................................................................................................................................... 12
1 LinMot Drive Setup.......................................................................................................................... 12
2 Setting the Parameters.................................................................................................................... 12
2.1 Defining Payload.......................................................................................................................... 12
2.2 PID Controller .............................................................................................................................. 12
2.3 Achieving Full Stroke Length....................................................................................................... 12
3 Master-Slave Configuration............................................................................................................. 12
7Accessories ............................................................................................................................................ 13
1 Trailing Chain Kits............................................................................................................................ 13
1.1 Dimensions.................................................................................................................................. 13
1.2 Overview Trailing Chain Kit ......................................................................................................... 14
1.3 Assembling Instructions............................................................................................................... 15
2 Motor Cables ................................................................................................................................... 17
2.1 Motor Cables for Direct Wiring..................................................................................................... 17
2.2 Motor Cables for indirect Wiring with fixed Extension Cable....................................................... 18
3 External Sensor ............................................................................................................................... 19
3.1 Overview Incremental External Sensor Kit.................................................................................. 19
3.2 Dimensions.................................................................................................................................. 20
3.3 Magnetic Strips for Incremental External Sensor........................................................................ 20
3.4 Extender Incremental Sensor Cable............................................................................................ 21
4 Absolute External Sensor Kit........................................................................................................... 21
4.1 Overview Absolute External Sensor Kit....................................................................................... 22
4.2 Dimensions.................................................................................................................................. 22

Installation Guide Linear Modules ENG
NTI AG / LinMot EM01-48 Page 3 / 36
4.3 Magnetic Strips for Absolute External Sensor............................................................................. 23
4.4 Absolute External Sensor Cables................................................................................................ 24
8Maintenance............................................................................................................................................ 25
1 Maintenance Cycles ........................................................................................................................ 25
1.1 Carriage Rails Maintenance Cycles ............................................................................................ 25
1.2 Linear motor (Stator and Slider) Maintenance Cycles................................................................. 25
2 Inspection......................................................................................................................................... 25
3 Cleaning and Lubrication................................................................................................................. 25
3.1 Carriage Rails and Carriages Cleaning and Lubrication ............................................................. 25
3.2 Linear Motor (Stator and Slider) Cleaning and Lubrication......................................................... 26
9Storage, Transport, Installation Altitude.............................................................................................. 26
Dimensions & Weights...................................................................................................................... 27
1 EM01-48-xxx_xxx_1CE48x150G-HP .............................................................................................. 27
2 EM01-48-xxx_xxx_1CE48x240F-HP............................................................................................... 28
3 End Plates........................................................................................................................................ 29
4 Mounting Plate EM01-48-xxx_xxx_1CE48x150G-HP..................................................................... 30
5 Mounting Plate EM01-48-xxx_xxx_1CE48x240F-HP...................................................................... 31
International Certificates................................................................................................................... 32
EU Declaration of Conformity CE-Marking ..................................................................................... 34
UK Declaration of Conformity UKCA-Marking................................................................................ 35



Installation Guide Linear Modules ENG

Page 4 / 36 EM01-48 NTI AG / LinMot

1 General Information

1.1 Introduction

This manual includes instructions for the assembly, installation, maintenance, transport, and storage of linear

guides / linear modules. The document is intended for electricians, mechanics, service technicians, and

warehouse staff.

Read this manual before using the product and observe the general safety instructions and those in the

relevant section at all times.

Keep these operating instructions in an accessible place and make them available to the personnel

assigned.

1.2 Explanation of Symbols

Triangular warning signs warn of danger.

Round command symbols tell what to do.

1.3 Qualified Personnel

All work such as installation, commissioning, operation and service of the product may only be carried out by

qualified personnel.

The personnel must have the necessary qualifications for the corresponding activity and be familiar with the

installation, commissioning, operation and service of the product. The manual and in particular the safety

instructions must be carefully read, understood and observed.

1.4 Liability

NTI AG (as manufacturer of LinMot and MagSpring products) excludes all liability for damages and

expenses caused by incorrect use of the products. This also applies to false applications, which are caused

by NTI AG's own data and notes, for example in the course of sales, support or application activities. It is the

responsibility of the user to check the data and information provided by NTI AG for correct applicability in

terms of safety. In addition, the entire responsibility for safety-related product functionality lies exclusively

with the user.Product warranties are void if products are used with stators, sliders, servo drives or cables not

manufactured by NTI AG unless such use was specifically approved by NTI AG.

NTI AG’s warranty is limited to repair or replacement as stated in our standard warranty policy as described

in our "terms and conditions" previously supplied to the purchaser of our equipment (please request copy of

same if not otherwise available). Further reference is made to our general terms and conditions.

1.5 Copyright

This work is protected by copyright.

Under the copyright laws, this publication may not be reproduced or transmitted in any form, electronic or

mechanical, including photocopying, recording, microfilm, storing in an information retrieval system, not even

for training purposes, or translating, in whole or in part, without the prior written consent of NTI AG.

LinMot® and MagSpring® are registered trademarks of NTI AG.

Installation Guide Linear Modules ENG

NTI AG / LinMot EM01-48 Page 5 / 36

2 Safety Instructions

Contusions

Sliders contain neodynium magnets and have a strong attractive force.

Careless handling could cause fingers or skin to become pinched between two sliders.

This may lead to contusions, bruises, and bone fractures.

When handling sliders, wear thick protective gloves and keep a minimum distance between

sliders. Refer to the "Minimum distance from slider" section for minimum distance.

To reduce the risk of injury, never more than one slider should be held or transported by the

same person without packaging.

Pacemaker / Implanted Heart Defibrillator

Sliders could affect the functioning of pacemakers and implanted heart defibrillators. For the

duration of a strong approach to a magnetic field, these devices switch into test mode and

will not function properly.

•If you wear one of those devices keep the following minimum distances between the

pacemaker / defibrillator and slider:

- Min. 250 mm (10ʺ) for slider Ø 27 mm and 28 mm (PL01-27 / 28 / PL10-28)

- Min. 150 mm (6ʺ) for slider Ø 19 mm and 20 mm (PL01-19 / 20)

- Min. 100 mm (4ʺ) for slider Ø 12 mm (PL01-12)

•Inform others who wear these devices to comply with these minimum distances!

Caution - Risk of Electric Shock !

Before working, make sure that there are no high voltages.

Fast-moving Machine Parts

The sliders of LinMot linear motors are fast-moving machine parts. All necessary

precautions must be taken to prevent persons approaching the moving elements during

operation (provide covers, guards, etc.).

Automatic Restart

The motors can start automatically under certain cricumstances!

If necessary, a corresponding warning symbol must be provided and protection against

entering the hazardous area or a suitable safe electronic disconnection must be provided!

Risk of Injury due to a Defect or Fault

For areas where a defect or fault can result in substantial property damage or even serious

personal injury, additional external precautions must be taken or devices must be installed

to ensure safe operation even if a defect or fault occurs (eg. suitable safe electronic

disconnection, mechanical interlocks, barriers, etc.).

Magnetic Field

Magnets integrated in the sliders produce a strong magnetic field. They could damage TVs,

laptops, computer hard drives, credit and ATM cards, data storage media, mechanical

watches, hearing aids, and speakers.

•Keep magnets away from devices and objects that could be damaged by strong

magnetic fields.

•For the above mentioned objects, keep a minimum distance as described in the

"Pacemaker / implanted defibrillator" section.

•For non-anti-magnetic watches, keep the double minimum distance.

Installation Guide Linear Modules ENG

Page 6 / 36 EM01-48 NTI AG / LinMot

Combustibility

When machining magnets, the drilling dust could easily ignite.

Machining the sliders and the magnets they contain is not permitted.

Burn Hazard

During operation the slider can become hotter than 100 °C, which can cause burns if

touched. All necessary precautions (e.g. covers, casing, etc.) must be taken to prevent

contact with persons in the vicinity of the slider during operation.

Grounding

All metal parts that are exposed to contact during any user operation or servicing and likely

to become energized shall be reliably connected to the means for grounding.

Mechanical Handling

Neodymium magnets are brittle and heat-sensitive.

Machining the sliders and the magnets they contain is not permitted.

•Colliding magnets could crack. Sharp splinters could be catapulted for several meters

and cause eye injury.

•By machining the sliders, heat would result which demagnetizes the magnets.

2S Stators

Series 2S stators correspond mechanically to the respective standard stators and are to be

handled in exactly the same way in terms of assembly.

For special features, please refer to the safety manual (Item-No. 0185-1174).

Slider

Linear motor sliders consist of a high-precision, thin-walled stainless steel tube in which the

neodymium magnets are housed. The LinMot sliders should be handled with care.

Avoid contact with other sliders or iron parts as this can damage the magnets and the slider

surface. Do not grip the sliders with pliers, as this can also damage the surface. Do not use

sliders which are already damaged on the surface (scratches, deformation, etc.). This can

cause further damage to the stator.

Effects on People

According to the current level of knowledge, magnetic fields of permanent magnets do not

have a measurable positive or negative effect on people. It is unlikely that permanent

magnets constitute a health risk, but it cannot be ruled out entirely.

•For your own safety, avoid constant contact with magnets.

•Store large magnets at least one meter away from your body.

Temperature Resistance

Keep slider away from unshielded flame or heat.

Temperature above 120°C will cause demagnetization.

Installation Guide Linear Modules ENG

NTI AG / LinMot EM01-48 Page 7 / 36

3 Intended Use

3.1 Designation Code

EM01-48-1200_1015_1C48x150G-HP-BE02-MD02-C

Connector type

Mechanical design

Bearing type

Carrier type

Number of carriers

Carrier stroke

Overall length

Module type

3.2 EM01 Linear Module

LinMot EM01 linear modules are moving stator applications with tubular linear motors for use in industrial

and commercial installations. The mechanical design is based on a special aluminium profile on which up to

two high-precision profile rail guides are attached. Use of ball bearings in the carriages guarantee a reliable

and smooth operation, support of external forces, torques and bending moments. These products offer high

Guide profile

Rail guide

Carriage with

mounting plate

Option: Trailing Chain Kit

(with mounting brackets)

Stator

Option: External Sensor

(Sensor Kit, Stripe)

End plate

Cable connector

Installation Guide Linear Modules ENG

Page 8 / 36 EM01-48 NTI AG / LinMot

guidance accuracy, facilitate dynamic and precise positioning of load. EM01 modules can be mounted

together into a gantry or semi gantry designs without any additional adapters. It is also possible to run

multiple stators on the same guide. Direct mechanical compatibility with other LinMot linear modules for the

vertical axis, linear rotary motors and other products, combined with the wide range of stroke availabilities for

all axes, the moving stator guides offer a powerful toolbox for any automation task.

3.3 Option External Sensor

Next to the LinMot linear stator’s own integrated position sensors, both incremental and absolute external

encoders are available as an option for the E01 Guides. Together with a magnetic band, the external

sensors provide a high-resolution linear measurement system.

3.4 Technical Data Carriage Kits

The values for mass and friction are important for the configuration assistant of the LinMot-Talk software.

1Prevented by second carriage.

EM01-…

…48x150G…

…48x240F…

Static Load Rating (per carriage)

15400 N

(3462.1 lbs)

15400 N

(3462.1 lbs)

Dynamic Load Rating (per carriage)

8400 N

(1888.4 lbs)

8400 N

(1888.4 lbs)

Static Moment Load Mx0

cannot occur1

Static Moment Load My0/z0

cannot occur1

Dynamic Moment Loads Mx

cannot occur1

Dynamic Moment Loads My/z

cannot occur1

Friction (estimated)

18 N

(2.25 lbs)

25 N

(4.27 lbs)

Moving mass

5280 g

(5.60 lb)

7730 g

(6.30 lb)

Number of Carriages

Distance between Carriages

122 mm

210 mm

Distance between Rails

153 mm

Installation Guide Linear Modules ENG

NTI AG / LinMot EM01-48 Page 9 / 36

4 Installation Instructions

4.1 Installation Options

There are several options available for mounting the EM01 Linear Modules.

The end plates are equipped with fits for parallel pins, bores and counterbores. Parallel pins may only be used

to align the Guide and are not intended for mounting. Mounting is done by using bores or counterbores.

Additional brackets or adapters shown in examples may be required. These must be provided by the customer.

Following rules apply for installation:

•EM-Module profile should be pressed to the reference surface to get the best accuracy and alignment.

•EM-Module profile is equipped with T-Slots on the bottom and back side through its entire length. These

can be used to mount the guide. Depending on the length of a guide and application, a sufficient amount

of T-Nuts must be used.

•Installation “on the back” is allowed only for lengths up to 1200 mm.

The following sketches show examples of different installation options. The detailed dimensions can be found

in the "Dimensions" chapter.

4.1.1 Installation Examples

Example 1: Installation with “slider on the top” using end plates and brackets.

Example 2: Installation with “slider on the top” using T-Nuts from the bottom of the profile.

Example 3: Installation “on the back” using end plates (lengths up to 1200 mm).

Installation Guide Linear Modules ENG

Page 10 / 36 EM01-48 NTI AG / LinMot

Ordering information

Item

Description

Item-No.

Nut N8/M4

Nut for 8 mm T-slots with M4 thread

0150-2189

Nut N8/M6

Nut for 8 mm T-slots with M6 thread

0150-2558

4.2 Installation of the Load

The mounting plate of the EM01 linear module is used for installation of the load. The mounting plate is

equipped with multiple bores and fittings for parallel pins. The centre of gravity of the load mass should be

centred and as close as possible to the mounting plate to ensure even distribution of the mass between

carriages.

For example, 24 x M6 thru bores indexes with “0” that can be used for installation of the load. You can find

complete dimensions in the dimensions chapter.

Before performing installation of the load, all necessary precautions must be taken to prevent

operation of this device, e. g. the device must be disconnected from the power supply.

Table des matières

Autres manuels LinMot Unité de contrôle

LinMot

LinMot E1100 Series Manuel utilisateur

LinMot

LinMot 1031 Manuel utilisateur

LinMot

LinMot CF48x150-HP-BE02-MD01-C Manuel utilisateur

LinMot

LinMot FM01-48 Manuel utilisateur

LinMot

LinMot DM01-23 Series Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
