HeartBeat Signal: HeartBeat Signal
is a service used in Australia only. If
you are using a HeartBeat Signal
connection, check with your ISP for
setup information.
EWhen you have finished
entering your Internet
connection settings, click the
Save Settings button to save
your changes.
FTo configure the Router for your
wireless network, select the
Wireless Tab’s Basic Wireless
Settings screen.
GSelect the Wireless Network
Mode:
Mixed: If your network has
Wireless-G and Wireless-B
devices, then keep the default
setting, Mixed.
G-Only: If your network only has
Wireless-G devices, select
G-Only.
B-Only: If your network only has
Wireless-B devices, select
B-Only.
Disable: If you want to disable
wireless networking, select
Disable.
DFor the Internet Connection
Type setting, five connection
types are offered through the
drop-down menu. Each Setup
screen and available features
will differ depending on which
connection type you select.
Internet Configuration Type
Automatic Configuration - DHCP: If
you are connecting through DHCP
or a dynamic IP address from your
ISP, keep this default setting.
Static IP: If your ISP assigns you a
static IP address, select Static IP
from the drop-down menu.
Complete the Internet IP Address,
Subnet Mask, Gateway, and DNS
fields. You need to enter at least
one DNS address.
PPPoE: If you are connecting
through PPPoE, select PPPoE from
the drop-down menu. Complete
the User Name and Password
fields.
PPTP: PPTP is a service used in
Europe only. If you are using a PPTP
connection, check with your ISP for
setup information.
G
4
Configure the Router
LPower your cable or DSL
modem off and back on
again.
MRestart your computer.
NTest the setup by opening your
web browser and entering
http://www.linksys.com/registration.
Congratulations! The installation of
the Wireless-G Broadband Router
with SpeedBooster is complete.
HWireless Network Name (SSID).
The SSID is the network name
shared among all devices in a
wireless network. The SSID must
be identical for all devices in
the wireless network. It is case-
sensitive and must not exceed
32 characters (use any
keyboard character). For
added security, you should
change the default SSID
(linksys) to a unique name.
IWireless Channel. Select the
appropriate channel from the
list provided to correspond with
your network settings. All
devices in your wireless network
must broadcast on the same
channel in order to function
correctly.
JWireless SSID Broadcast. When
wireless clients survey the local
area for wireless networks to
associate with, they will detect
the SSID broadcast by the
Router. To broadcast the
Router's SSID, keep the default
setting, Enable. If you do not
want to broadcast the Router's
SSID, then select Disable.
KChange these settings as
described here and click the
Save Settings button to apply
your changes.
WRT54GS-QI-40220NC KL
For additional information or troubleshooting
help, refer to the User Guide on the Setup CD-
ROM. You can also call or e-mail for further
support.
24-hour Technical Support
800-326-7114
(toll-free from US or Canada)
E-mail Support
Website
http://www.linksys.com or
http://support.linksys.com
RMA (Return Merchandise Authorization)
http://www.linksys.com/support
FTP Site
ftp://ftp.linksys.com
Sales Information
800-546-5797 (800-LINKSYS)
Linksys is a registered trademark or trademark of
Cisco Systems, Inc. and/or its affiliates in the U.S.
and certain other countries. Copyright © 2004
Cisco Systems, Inc. All rights reserved.
3
NOTE: For more advanced set-
tings and security options, refer
to the User Guide on the Setup
CD-ROM.
