Linksys SRW224 - 10/100 - Gigabit Switch Manuel utilisateur

WIRED

Product Data

Model No.

10/100 and Gigabit Switching with Fiber Expansion

and Browser Configurability

24 autosensing

10/100 full duplex,

auto MDI/MDI-X ports

26 VLANs, 7 port trunking

groups, console port,

802.1p QoS support

Two Gigabit

(10/100/1000BaseTX)

MDI/MDI-X ports, and

a mini GBIC

expansion port

WebView remote

monitoring and

configuration via

web browser

configure the switch. The non-blocking, wire-speed

switching forwards packets as fast as your network

can deliver them. Also included are Address

Learning and Aging to prevent data transfer errors

and Data Flow Control to help prevent packet

collisions. Two Quality of Service queues per port

let you prioritize traffic via 802.1p. The switch

provides broadcast storm suppression, has

hardware MAC address learning, and supports

packet filtering and port security.

All ports have automatic MDI/MDI-X crossover

detection, so you don't have to worry about the

cable type. Each port independently and

automatically negotiates for best speed and

whether to run in half- or full-duplex mode. Head-

of-line blocking prevention keeps your high-speed

clients from bogging down in lower-speed traffic

and fast store-and-forward switching prevents

damaged packets from being passed on into the

network.

No matter how intensive your network demands,

the Linksys 24-Port 10/100 + 2-Port Gigabit Switch

with WebView has speed, flexibility, and reliability

that you can count on.

24-Port 10/100 + 2-Port Gigabit Switch

with WebView

SRW224

This new Linksys rackmount switch delivers non-

blocking, wire speed switching for your 10, and 100

megabit network clients, plus multiple options for

connecting to your network backbone. Twenty-four

10/100 ports wire up your workstations, while the two

integrated 10/100/1000BaseTX ports connect to

other switches and the backbone at Gigabit

speeds. And the mini GBIC port allows future

expansion to alternate transmission media like

optical fiber.

It features WebView monitoring and configuration

via your web browser, making it easy to manage

the 26 VLANs and up to 7 trunking groups. Or if you

prefer, you can use the integrated console port to

Product Data

Model No.

Features

• 24 - 10/100 Switched RJ-45 ports

deliver up to 200Mbps of

throughput per port

• 2 - 10/100/1000 Switched RJ-45

Gigabit Uplink Ports

• 1 - MiniGBIC port for copper or

fiber 1000Mbps uplinking to other

switches

• WebView monitoring allows

administrators to view the current

status and configuration using

their favorite web browser

• Port based and 802.1q based

VLANs support up to 26 VLANs

• Port Trunking for up to 7 groups

allows you to increase your

bandwidth for each uplink or

Server connection

• Port configuration settings for Link,

Speed, Auto MDI/MDIX, Flow

Control, and more

• Fully rack-mountable using the

included rack-mounting

hardware

• Auto MDI/MDIX per port allows for

automatic Cable detection

• MAC Address table supports up

to 4,000 MAC Addresses

SRW224

with WebView

24-Port 10/100 + 2-Port Gigabit Switch

Specifications

Model SRW224 - 24-port 10/100 + 2-Port Gigabit Switch

with WebView

Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab,

IEEE 802.1q, IEEE 802.1p

Ports 24 - 10/100, 2 - 10/100/1000, 1 - MiniGBIC,

1- Console

Cabling Type CAT5e or better

LEDs System, Link/Act, Gigabit, Gigabit 1,

Gigabit 2/miniGBIC

Environmental

Dimensions 17.01" x 1.77" x 13.74"

(W x H x D) (432 mm x 45 mm x 349 mm)

Weight 8.60 lb. (3.9 kg)

Power Voltage Range 100 ~ 240VAC,

Frequency Range 50 – 60Hz, 50W max

Certification FCC, CE

Operating Temp. 0ºC to 40ºC (32ºF to 104ºF)

Storage Temp. -20ºC to 70ºC (-4ºF to 158ºF)

Operating Humidity 10% to 90% Relative Humidity, Non-Condensing

Storage Humidity 10% to 95% Non-Condensing

Warranty 5-year Warranty

SRW224-DS-61220A JL

Package Contents

• One SRW224 Switch

•OnePowerCord

• One Rack Mounting Kit

• One CD with User Guide in PDF Format

• One Registration Card
