Linksys SVIEW04 - ProConnect CPU Switch KVM Manuel utilisateur

ProConnect KVM

Switches

ake control of your PCs with the

ProConnect KVM Switches. Ready to

run out of the box, the ProConnect KVM

Switch lets you connect multiple PCs to a single

keyboard, monitor, and mouse. Switch between

PCs with the press of a key, or use the switch’s

cycling feature to rotate between each PC’s

progress automatically at programmed intervals.

Got a notebook PC? Plug it into the KVM

Switch and control it from your desktop’s full-

sized keyboard, monitor, and mouse - just like a

docking station!

Built to last, the ProConnect 2-Port or 8-Port

KVM Switch virtually eliminates cable swapping,

while you save hundreds of dollars in storage

space and hardware costs. You connection can be

simple and inexpensive with the Linksys

ProConnect KVM Switch - it’s the perfect choice

for any file server fleet, Internet, or testing site

where you need to manage multiple PCs effi-

ciently and easily.

•Switch Instantly Among Multiple PCs

with the Touch of a Button

•Serves as a Convenient Docking Station

for Notebook PCs

•Reduces Floor Space By Up to 50%

•Cycling Feature Switches Among PCs

Automatically

•Fully Expandable - Cascade KVM

Switches Together

•Runs with Virtually All Software and

Operating Systems

•Compatible with All Standard PS/2,

AT/Serial, and Windows 95 Keyboards

•Sturdy Metal Chassis and Quality

Connectors

•Free 24-Hour Technical Support

•1-Year Warranty

•Switch Instantly Among Multiple PCs

with the Touch of a Button

• Save Hundreds of Dollars in Equipment,

Space, and Power Costs

•Serves as a Convenient Docking Station for

Notebook PCs

• Reduces Storage Space By Up To 50%

•Free Technical Support

•1-Year Warranty

PPrrooCCoonnnneecctt22--PPoorrttKKVVMMSSwwiittcchh((SSVVIIEEWW0022))

PPrrooccoonnnneecctt44--PPoorrttKKVVMMSSwwiittcchh((SSVVIIEEWW0044))

AT/Serial KVM Switch Cabling Kit (SVAT06)

PS/2 KVM Switch Cabling Kit (SVPS06)

PPrrooCCoonnnneecctt88--PPoorrttKKVVMMSSwwiittcchh((SSVVIIEEWW0088))

At/Serial KVM Switch Cabling Kit (SVPAT10)

PS/2 KVM Switch Cabling Kit (SVPPS10)

Control Multiple PCs with Just One Console

Features

Benefits

Specifications

Model Numbers SVIEW02, SVIEW04, SVIEW08

Cabling Kits* SVPS06, SVAT06, SVPPS10, SVPAT10

Scan Intervals 3, 10, 20, 40 Seconds

Monitors Supported SVGA, VGA, and MultiSync

Maximum Resolution 1600 x 1200 SVGA

DIP Switches 4 DIP switches, for Controlling Scan

Timeouts and Cascading

Environmental

Dimensions 8.75 x 6.0 x 1.75” (SVIEW02)

10.25 x 7.0 x 3.0” (SVIEW04)

14.5” x 9.75” x 1.75” (SVIEW08)

Weight 4 lbs. 2 oz. (SVIEW02)

5 lbs. 1 oz. (SVIEW04)

7 lbs. 8 oz. (SVIEW08)

Power Input External AC Power Supply

Certifications FCC, CE Mark Commercial, UL Listed

Operating Temp. 41° F to 104° F (5° C to 40° C)

Storage Temp. 14° F to 140° F (-10° C to 60° C)

Operating Humidity 10% to 85%, Non-condensing

Storage Humidity 5% to 90%, Non-condensing

Package Contents

Sales (800) 546-5797

Support (800) 326-7114

Fax (949) 261-8868

Email [email protected]

Web www.linksys.com

•One ProConnect KVM Switch

• One AC Power Adapter

•One User Guide and Registration Card

Model Numbers: SVIEW02, SVIEW04, SVIEW08

*Cabling Kit Model Numbers:

For SVIEW02 & SVIEW04: SVPS06

SVAT06

For SVIEW08 only: SVPPS10

SVPAT10

* Cables for connecting PCs to the KVM switch are sold separately

under the above listed model numbers. If you are unsure which

cabling kits to purchase, please contact Linksys for assistance.
