DEMO MANUAL DC1371B

Description

FMC High-Speed Data

Acquisition Board

Demonstrationcircuit1371,along with PScope™ software,

provides a USB based, Windows PC hosted digital data

acquisition system supporting high speed data converter

products from Linear Technology. The DC1371 must be

powered with the 5V power supply that is supplied with

the demo board. The PScope evaluation software auto-

matically detects the DC1371 and the demonstration cir-

cuit board connected to it. This system provides for fast

and easy performance evaluation of high speed ADCs.

DC1371 collects samples from high speed demonstra-

tion circuits and the PScope software performs various

analyses on the data including calculating SNR, SINAD,

THD, SFDR and ENOB. The digitized input, an FFT of the

L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks and PScope

is a trademark of Linear Technology Corporation. All other trademarks are the property of their

respective owners.

collected data, the primitive wave of the sample set or an

IFFT of modified frequency domain data is plotted to a

display window to facilitate analyzing noise and distortion

products and their sources. Figure 1 shows a picture of

the DC1371. The DC1371 is connected to the ADC dem-

onstration circuit via a 400 pin FMC connector and to the

PC by a mini-USB cable.

Design files for this circuit board are available at

http://www.linear.com/demo/DC1371B

Figure 1. DC1371B Data Collection Board

To provided 5V

adaptor

USB connection

to PC

Demo Board will be shipped

connected to the DC1371 board

dc1371bf

DEMO MANUAL DC1371B

screenshot

Figure 2. Typical PScope Screen

dc1371bf

DEMO MANUAL DC1371B

Information furnished by Linear Technology Corporation is believed to be accurate and reliable.

However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa-

tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.

Quick start proceDure

To prevent damage to the DC1371, it is important to follow

the equipment setup procedure outlined below:

1. Do not plug the DC1371 into the PC USB port before

running the PScope installation program.

2. Download the PScope installation program from http://

www.linear.com/designtools/software/

3. Run the PScope installation program and follow the on

screen instructions.

NOTE: The PScope evaluation software requires a PC

running Windows XP or newer, with an available USB

port.

4. Connect the DC1371 to a USB port and supply external

power to the DC1371. Only use the provided 5V power

supply.

5. The DC1371 should be provided with an ADC demo

board attached. This demo board should not be re-

moved. The DC1371 does not supply power to the ADC

demonstration circuit.

6. EachADCdemonstrationboardalsocomeswithademo

manual similar to this one and should be referred to

for specific usage details relevant to the demonstration

circuit being evaluated. Please refer to it for proper

jumper settings, input power requirements and input

signal levels and frequency ranges.

7. Apply an appropriate conversion clock and analog input

signal to the ADC demonstration board.

8. The PScope software will automatically find and con-

figure the DC1371 and the connected demo board.

dc1371bf

DEMO MANUAL DC1371B

Linear Technology Corporation

1630 McCarthy Blvd., Milpitas, CA 95035-7417

(408) 432-1900 ●FAX: (408) 434-0507 ●www.linear.com

 LINEAR TECHNOLOGY CORPORATION 2015

LT 0815 • PRINTED IN USA
