Lighting Systems ALETTA AL2T5

Page 1 of 2 LouverShield,2T5LampsperFixture,GridMounted

D1007

Features

1. Housing: 23gaugepre-paintedsteel.20gaugeavailable,consultfactory.

2. Lamp: TwoT5,T5HO.(byothers)

3. Faux Housing: ExtrudedFrostyacrylic.

4. Louver:HighpuritySemi-Specular,2-3/4"(6.99cm)openingx1-3/8"(3.49cm)

deepon2"(5.08cm)ctrswithmicro-prismaticsideoverlays.Elongatedlens

openingsare22"(55.88cm)windows.

5. Performance Kick Reflector:.020"(0.05cm)95%-98%reflective,UV

resistant polypropylene.

6. Trim:Extrudedaluminumtrim,paintedwhite,interfaceswithceilinggridor

plasterframebyothers.

Electrical

Ballastsareelectronicandhighpowerfactor.Dimmingballastsareavailableon

manylamptypes,pleaseconsultfactoryregardingspecificapplications.1325

maxlumenbatterypackisstandard.Seeapplicationtableonpage2foroutput

with specific lamp types. Continuous luminaires utilize 12 gauge through wires.

Factoryinstalledballastdisconnectallowstheballasttobedisconnectedfromand

reconnected to incoming power under load without turning the entire circuit off.

Mounting

Housingissuspendedbyhangerwiresandlaidintostandardorslot-Tgridceiling.

Mountingaccessoryavailablefordrywallinstallations(seepage2).

Labels

UL,cULandI.B.E.W.

Ordering Instructions

Individual Fixtures:

1. OrderquantityofIndividualUnitsrequired.

Continuous Runs:

1. OrderoneStarterandoneEnderfixtureperrun.

2. OrderappropriatequantityofJoinerfixtures.

Continuousrunsonly-PriortoinstallingAlettainagridceiling,theinstalling

contractormustensurethatthexturewillsetintotwomainrunners,spaced2'

(60.96cm)oncenter.Nogridcrossmembersarerequiredexceptatthebeginning

and end of the run.

7.00”

(17.78cm)

23.00”

(58.42cm)

2.00”

(5.08cm)

2.75”

(6.99cm)

24.00” (60.96cm)

5.28”

(13.41cm)

7.00”

(17.78cm)

Louver w/ Elongated

Lens Detail

* For dimming, use "D" option. If "D" is not selected, ballast will be static.

Ordering Information

Family Shielding Length Lamps Lamp Type Ballast Factor Voltage Housing Option

Aletta LE=Louverw/

Elongated Lens

2=2'(60.96cm)

4=4'(121.92cm)

2 = 2 Lamps T5 =T5Standard

Output

HO =T5High

Output

10 =*1.0T5,

HODimming

and Static

11 =1.15T5

1 = 120v

2 = 277v

3 =347v

U =IndividualUnit

S = Starter

J =Joiner

E = Ender

D = Dimming

E =EMPack

2 = 2 Circuit

4 =4ThroughWire

5 =5ThroughWire

Job Information Type:

631AirportRoad,FallRiver,MA02720•(508)679-8131•Fax(508)674-4710

We reserve the right to change details of design, materials and finish.

www.lightolier.com©2010PhilipsGroup•

Lighting Systems ALETTA AL2T5

Page 2 of 2 LouverShield,2T5LampsperFixture,GridMounted

D1007

Performance

COEFFICIENTS OF UTILIZATOIN

% EFFECTIVE CEILING CAVITY REFLECTANCEE

CANDLEPOWER CURVE

80 70 50

WALLREFLECTANCE

70 50 30 70 50 30 50 30 10

0 78 78 78 76 76 76 73 73 73

1 72 69 66 70 68 65 65 63 61

2 66 61 57 64 60 56 58 54 52

3 61 54 50 59 53 49 52 48 45

4 56 49 44 55 48 43 47 42 39

5 52 44 39 51 44 39 42 38 34

6 48 40 35 47 40 35 39 34 31

7 45 37 32 44 37 31 36 31 28

8 42 34 29 41 34 29 33 28 25

9 40 32 27 39 31 26 30 26 23

10 37 29 25 37 29 24 28 24 21

20% FLOOR CAVITY REFLECTANCE

ROOM CAVITY RATIO

ZoneLumens%Lamp % Luminaire

0-90 6538 65.4 100

0-180 6538 65.4 100

DISTRIBUTION

REPORT NO.: ALE42T5.IES

LAMPS: 2 FP54/835/HO

LUMENS: 4450

EFFICIENCY: 65.4%

* 25˚C Rating

Lamp

Length

Lamp

Type

Lamp Rated

Output

Lamp

Wattage

Battery

Lumen Output

T5HO

Mounting Accessory

Drywall Conversion Kit

For Individual Units only

FK92X2

FK92X4

4450* 54 1250*

T5 2600* 28 1325*

T8 2950 32 1100

T5HO 1750* 24 725*

T5 1200* 14 750*

T8 1350 17 650

* 25˚C Rating

EM Pack Output Table

CANDLEPOWER

ZONE 0 22 45 67 90

DEG.

CANDELAS

90 0 0 0 0 0

85 51 77 73 72 70

75 235 273 389 476 484

65 484 496 550 686 742

55 959 844 822 859 891

45 1797 1565 1187 1111 1122

35 2405 2262 1953 1657 1578

25 2889 2819 2647 2543 2493

15 3238 3235 3167 3101 3060

5 3450 3450 3438 3425 3418

0 3460 3460 3460 3460 3460

– Conversion Kit for 2’ (60.96cm) Unit

– Conversion Kit for 4’ (121.92cm) Unit

4’

(121.92cm)

4’

(121.92cm)

4’

(121.92cm)

2’

(60.96cm)

2’

(60.96cm)

2’

(60.96cm)
