Lytespan®Track Li htin System 8235WH

Pa e 1 of 2 PAR-TechTMCone 30 Shade

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Li htolier a Genlyte Thomas Company www.li htolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the ri ht to chan e details of desi n, materials and ﬁnish.

Features

1. Shade Attachment: Zinc plated and painted C.R. steel. Bayonet ﬁttin .

2. Shade: Sin le piece die-cast aluminum.

3. Mountin Groove: For accessories holder.

5. Perimeter Ventin

4. Color Accent Rin : Silicone rubber. (Removable)

Finish

All painted ﬁnishes baked enamel.

Options & Accessories

3 1/2” Beam Smoother, Beam Elon ator and Louver. All require Accessory

Holder 8583. See Li htolier Speciﬁcation Sheets AF2LF, AF2AS.

Labels

UL; I.B.E.W.

8235WH

8235BK

Catalo No. Finishes Mountin Lamps

8235WH Matte White All Lytespan Track Systems PAR30, 75W Max. (Tun sten-Halo en)

8235BK Matte Black

Orderin Information

Lytespan®Track Li htin System 8235WH

Pa e 2 of 2 PAR-TechTMCone 30 Shade

Li htolier a Genlyte Thomas Company www.li htolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the ri ht to chan e details of desi n, materials and ﬁnish.

Job Information Type:

Li htin Data

17,000 3,000

50W P AR30 NSP

(Halogen-IR) 8°

8' 266 1.1' 1.1'

12' 118 1.7' 1.7'

16' 66 2.2' 2.2'

20' 43 2.8' 2.8'

7' 4.0' 225 1.3' 1.1'

10' 5.8' 110 1.9' 1.6'

13' 7.5' 65 2.4' 2.1'

16' 9.2' 43 3.0' 2.6'

5' 5.0' 240 1.4' 1.0'

7' 7.0' 123 2.0' 1.4'

9' 9.0' 74 2.5' 1.8'

11' 11.0' 50 3.1' 2.2'

3' 5.2' 236 1.7' 0.8'

4' 6.9' 133 2.3' 1.1'

5' 8.7' 85 2.8' 1.4'

6' 10.4' 59 3.4' 1.7'

7' 188 1.0' 1.0'

10' 92 1.4' 1.4'

13' 54 1.8' 1.8'

16' 36 2.2' 2.2'

6' 3.5' 156 1.1' 1.0'

9' 5.2' 74 1.7' 1.5'

12' 6.9' 41 2.2' 1.9'

15' 8.7' 27 2.8' 2.4'

4' 4.0' 203 1.1' 0.8'

6' 6.0' 90 1.7' 1.2'

8' 8.0' 51 2.2' 1.6'

10' 10.0' 33 2.8' 2.0'

2' 3.5' 288 1.1' 0.6'

3' 5.2' 128 1.7' 0.8'

4' 6.9' 72 2.3' 1.1'

5' 8.7' 46 2.8' 1.4'

9,200 2,000

50W PAR30

NSP (Halogen) 8°

4' 125 1.8' 1.8'

6' 58 2.7' 2.7'

8' 31 3.5' 3.5'

10' 20 4.4' 4.4'

3' 1.7' 144 1.8' 1.5'

5' 2.9' 52 3.0' 2.6'

7' 4.0' 27 4.2' 3.6'

9' 5.2' 16 5.4' 4.5'

3' 3.0' 79 2.8' 1.9'

4' 4.0' 44 3.7' 2.5'

5' 5.0' 28 4.7' 3.1'

6' 6.0' 20 5.6' 3.8'

1' 1.7' 250 2.1' 0.9'

2' 3.5' 63 4.2' 1.8'

3' 5.2' 28 6.2' 2.7'

4' 6.9' 16 8.3' 3.5'

2,000 2,000

50W PAR30

NFL (Halogen) 25°

DFC L W DC FC L W DC FC L W DC FC L W

Beam Spread Beam Center Rated

50% Max. CP C.P. Candelas Life-Hrs

1,400 2,500

50 PAR30

FL (Halogen) 35°

3' 158 1.9' 1.9'

5' 56 3.2' 3.2'

7' 29 4.4' 4.4'

9' 17 5.7' 5.7'

3' 1.7' 101 2.6' 2.2'

5' 2.9' 36 4.3' 3.6'

7' 4.0' 19 6.1' 5.1'

9' 5.2' 11 7.8' 6.6'

2' 2.0' 124 2.8' 1.8'

3' 3.0' 55 4.2' 2.7'

4' 4.0' 31 5.6' 3.8'

5' 5.0' 20 7.0' 4.5'

1' 1.7' 175 3.6' 1.3'

2' 3.5' 44 7.2' 2.5'

3' 5.2' 19 10.8' 3.8'

4' 6.9' 11 14.4' 5.0'

6' 83 2.7' 2.7'

8' 47 3.5' 3.5'

10' 30 4.4' 4.4'

12' 21 5.3' 5.3'

5' 2.9' 78 3.0' 2.6'

7' 4.0' 40 4.2' 3.6'

9' 5.2' 24 5.4' 4.6'

11' 6.4' 16 6.6' 5.6'

3' 3.0' 118 2.8' 1.9'

5' 5.0' 42 4.7' 3.1'

7' 7.0' 22 6.5' 4.4'

9' 9.0' 12 8.4' 5.6'

2' 3.5' 94 4.2' 1.8'

3' 5.2' 42 6.2' 2.7'

4' 6.9' 23 8.3' 3.5'

5' 8.7' 15 10.4' 4.4'

3,000 3,000

50W PAR30

NFL (Halogen-IR) 2 5°

3' 178 2.0' 2.0'

5' 64 3.3' 3.3'

7' 33 4.7' 4.7'

9' 20 6.0' 6.0'

3' 1.7' 115 2.8' 2.3'

5' 2.9' 42 4.6' 3.9'

7' 4.0' 21 6.5' 5.4'

9' 5.2' 13 8.3' 7.0'

2' 2.0' 141 3.0' 1.9'

3' 3.0' 63 4.5' 2.8'

4' 4.0' 35 6.0' 3.8'

5' 5.0' 23 7.5' 4.7'

1' 1.7 200 4.0' 1.3'

2' 3.5' 50 8.1' 2.7'

3' 5.2' 22 12.1' 4.0'

4' 6.9' 13 18.1' 5.4'

1,600 3,000

50W PAR30

FL (Halogen-IR) 37°

3,200 2,500

75W PAR30

NFL (Halogen) 30°

6' 89 3.2' 3.2'

8' 50 4.3' 4.3'

10' 32 5.4' 5.4'

12' 22 6.4' 6.4'

5' 2.9' 83 3.7' 3.1'

7' 4.0' 42 5.1' 4.3'

9' 5.2' 26 6.6' 5.6'

11' 6.4' 17 8.1' 6.8'

3' 3.0' 126 3.5' 2.3'

5' 5.0' 45 5.8' 3.8'

7' 7.0' 23 8.1' 5.3'

9' 9.0' 14 10.4' 6.8'

2' 3.5' 100 5.5' 2.1'

3' 5.2' 44 8.2' 3.2'

4' 6.9' 25 10.9' 4.3'

5' 8.7' 16 13.7' 5.4'

8' 219 1.3' 1.3'

12' 97 1.9' 1.9'

16' 55 2.5' 2.5'

20' 35 3.1' 3.1'

7' 4.0' 186 1.5' 1.3'

10' 5.8' 91 2.1' 1.8'

13' 7.5' 54 2.7' 2.4'

16' 9.2' 36 3.4' 2.9'

5' 5.0' 198 1.6' 1.1'

7' 7.0' 101 2.2' 1.6'

9' 9.0' 61 2.9' 2.0'

11' 11.0' 41 3.5' 2.4'

3' 5.2' 184 1.9' 0.9'

4' 6.8' 109 2.6' 1.3'

5' 8.7' 70 3.2' 1.6'

6' 10.4' 49 3.8' 1.9'

14,000 2,500

75W PAR30

NSP (Halogen) 9°

4' 125 2.9' 2.9'

6' 56 4.4' 4.4'

8' 31 5.8' 5.8'

10' 20 7.3' 7.3'

3' 1.7' 144 3.0' 2.5'

5' 2.9' 52 5.1' 4.2'

7' 4.0' 27 7.1' 5.9'

9' 5.2' 16 9.1' 7.6'

3' 3.0' 79 5.0' 3.1'

4' 4.0' 44 6.7' 4.1'

5' 5.0' 28 8.4' 5.1'

6' 6.0' 20 10.1' 6.1'

1' 1.7' 250 4.8' 1.5'

2' 3.5' 63 9.7' 2.9'

3' 5.2' 28 14.5' 4.4'

4' 6.9' 16 19.3' 5.8'

2,000 2,500

75W PAR30

FL (Halogen) 40°

DFCL

LAMP 0˚ AIMING ANGLE A=30˚ AIMING ANGLE A=45˚ AIMING ANGLE A=60˚ AIMING ANGLE

Aimin An le 0˚ 30˚, 45˚ or 60˚ Horizontal 30˚, 45˚ or 60˚ Vertical

LBeam Length

WBeam Width

CDistance to center beam

DDistance

AAiming Angle

FC Footcandles

Land Ware the outer points where the candle

power drops to 50% of the maximum. FC are the

initial footcandles at the center of the beam.
