Performance Recessed CFL Downlighting 1101FRD

Page 1 of 2 6 ¾" Aperture, 1 Light, Compact Fluorescent, Non-IC, Dimming, Remodeler, Frame-In Kit

Complete Fixture consists of Frame-In Kit and Reflector Trim. Select each separately.

Uniframe™

Frame-In Kit

Uniframe™Compact Fluorescent Performance Series Reflector Trims

Vertical Open Vertical Wall

Wash - Single

Vertical Wall

Wash - Double

Horizontal

Open

Horizontal Wall

Wash - Single

Horizontal Wet Location

Lensed / Diffused

Horizontal

Cross Blade

1101FR264MX1

(Advance Mark X- 120V)

26W Quad/ Triple, GX24q-3

120V- 0.26amp max

32W Triple, GX24q-3

120V- 0.32amp max

42W Triple, GX24q-4

120V- 0.41amp max

1101FR264MX2

(Advance Mark X- 277V)

26W Quad/ Triple, GX24q-3

120V- 0.11amp max

32W Triple, GX24q-3

120V- 0.14amp max

42W Triple, GX24q-3

120V- 0.18amp max

1101CL

1101CD

1101WH

1101CLSW

1101CDSW

1101WHSW

1101CLDW

1101CDDW

1101WHDW

1101HCL

1101HCD

1101HWH

1101HCLSW

1101HCDSW

1101HWHSW

Clear Lens Fresnel

1101HCLC 1101HCLF

1101HCDC 1101HCDF

1101HWHC 1101HWHF

Opal Lens

1101HCLO

1101HCDO

1101HWHO

1101HACB

1101HWHCB

Universal Series Reflector Trims (Reference Trim Spec Sheet for Recommended Lamping)

Performance Cone Cone Satin Cone Bafe Wall Wash Wet Location

1113CFL

1113CDCFL

1112*

1113*

1113BK*

1113WH

1113CD*

1145

1146

1146CD

1143

1144

1144CD

1108*

1110*

1105*

1105BNM

1105WH

1176

1176WH

1135

1135WH

1195

1196

1196CD

1121

1124

1134

1177SH

1178SH

*Add NM sufx to catalog number for Natural Metal ange and nish.

3/4"

FOR O.A HEIGHT SEE

TRIM SPECIFICATION 3 3/4"

5 INSIDE

13 9/32"

7 1/8"

CEILING

CUTOUT

Labels cULus Listed. Suitable for Damp Locations.Features

1. Uniframe™Mounting Ring: .032" (#22ga.) thick Galvanized Steel.

Accommodates existing ceilings up to 2" thick. Attaches securely to any type

of ceiling material without tools using (3) mounting straps provided. Includes

adhesive backed aperture template.

2. Trim Clips: “Push In / Twist Out” clips hold reflector flush to ceiling.

3. Junction Box: 2" x 4" x 3-1/2" (22cu.in.) .032" (#22ga.) galvanized steel. UL

Listed for 90˚ C supply wire. Attaches to mounting ring without tools.

4. Ballast: 120V or 277V UL listed Electronic Dimming Ballast, 100% to 5% full

range continuous dimming. End of lamp life protection, class "P" thermally

protected, class "A" sound rating.

5. Socket: Four-pin base, molded thermoplastic socket, prewired with No. 18

AWM leads to ballast.

6. Socket Housing: .036" (#20ga.) Galvanized Steel housing attaches to

reflector trim by spring clip for precise optic alignment.
