Lytecaster®Recessed Downlighting 1052LV

Page 1 of 2 5” Aperture Low Voltage Pinhole Reflector Trim

35˚

Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

1052LV/1000LV

Standard MR16

6 5/8”

Features

1. Housing: Hydroformed aluminum, .040” thick (18 ga.); matte white trim

flange.

2. Aperture Plate: Die-formed, 20 ga. steel, matte white finish. Inner shield

welded to aperture plate; matte black finish; cuts off glare at normal viewing

angles.

3. Support Ring Assembly: Provides 358° horizontal rotation and 0° to 35°

vertical adjustment. Matte white finish.

4. Frame-In Kit: (1000LV standard frame shown) Other frames listed above and

shown on the right. See Frame-In Kit specification sheets for more details.

Options & Accessories

Retaining Clips: 1955 - For Installing in Existing Ceiling

Extra Wide Trim Flange: 1957 - 7" Outside diameter.

MR16 Replacement socket: 1975B

Labels

UL (Suitable for Damp Locations), I.B.E.W.

6 5/8”

1052LV/1000LVNT

MR16 Remote Transformer

6 5/8”

1052LV/1004ICV/N

0™AirSeal®Insulated Ceiling

7 1/4”

1052LV/1000LVR

Remodeler/Non-IC

Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.

Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets

1052LV

Matte White

Low Voltage

Frame-In Kit Installation Type Lamping Height

1000LV

1000LVE1

1000LVE2

1000LVRE1

Non-IC 42W - 65W MR16 6 5/8"

1000LVR Non-IC Remodeler 42W - 65W MR16 6 5/8”

1000LVNT Non-IC Remote Trans 20W - 65W MR16 6 5/8”

1004ICV/N AirSeal®IC 20W - 37W MR16 6 5/8”

1000ICV IC 20W - 35W MR16 7 5/16”

1920LV Conversion Kit 20W - 50W MR16 6 5/8”

Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Lytecaster®Recessed Downlighting 1052LV

Page 2 of 2 5” Aperture Low Voltage Pinhole Reflector Trim

35˚

F 2011

D FC L W D C FC L W D C FC L W

0° AIMING ANGLE 30° AIMING ANGLE 30° AIMING ANGLE

MR16 LOW VOLTAGE HALOGEN BI-PIN LAMPS

Lamps Beam Spread CBCP Rated

(To 50% CBCP) Life (Hrs.)

ACCENT LIGHTING PERFORMANCE DATA UL

(FC) is initial footcandles at center of beam.

Beam length (L) and beam width (W) are to

where the candlepower is reduced to 50% of

center beam candlepower.

CBCP is center beam candlepower.

Lamp data shown is typical, and is based on

bare lamp photometrics. Contact lamp

manufacturers for availability and performance.

7’ 167 0.9’ 0.9’

10’ 82 1.2’ 1.2’

13’ 49 1.6’ 1.6’

16’ 32 2.0’ 2.0’

6’ 3.5’ 148 1.0’ 0.8’

9’ 5.2’ 66 1.5’ 1.3’

12’ 6.9’ 37 2.0’ 1.7’

15’ 8.7’ 24 2.3’ 2.1’

2’ 3.5 256 1.0’ 0.5’

3’ 5.2’ 114 1.5’ 0.7’

4’ 6.9’ 64 2.0’ 1.0’

5’ 8.7’ 41 2.5’ 1.2’

8200 3000

20W MR16

VNSP (EZX) 7˚

6’ 100 1.4’ 1.4’

8’ 56 1.8’ 1.8’

10’ 36 2.3’ 2.3’

12’ 25 2.7’ 2.7’

5’ 2.9’ 94 1.5’ 1.3’

7’ 4.0’ 48 2.1’ 1.8’

9’ 5.2’ 29 2.7’ 2.4’

11’ 6.4’ 19 3.4’ 2.9’

2’ 3.5’ 113 1.9’ 0.9’

3’ 5.2’ 50 2.8’ 1.4’

4’ 6.9’ 28 3.8’ 1.8’

5’ 8.7’ 18 4.7’ 2.3’

3600 3000

20W MR16

NSP (ESX) 13˚

7’ 178 1.5’ 1.5’

10’ 87 2.1’ 2.1’

13’ 51 2.7’ 2.7’

16’ 34 3.4’ 3.4’

6’ 3.5’ 157 1.7’ 1.5’

9’ 5.2’ 70 2.5’ 2.2’

12’ 6.9’ 39 3.4’ 2.9’

15’ 8.7’ 25 4.2’ 3.6’

2’ 3.5’ 272 1.7’ 0.8’

3’ 5.2’ 121 2.6’ 1.3’

4’ 6.9’ 68 3.5’ 1.7’

5’ 6.7’ 44 4.3’ 2.1’

8700 4000

35W MR16

NSP (FRB) 12˚

8’ 205 1.3’ 1.3’

12’ 91 1.9’ 1.9’

16’ 51 2.5’ 2.5’

20’ 33 3.1’ 3.1’

7’ 4.0 174 1.5’ 1.3’

10’ 5.8’ 85 2.1’ 1.8’

13’ 7.5’ 50 2.7’ 2.4’

16’ 9.2’ 33 3.4’ 2.9’

3’ 5.2’ 182 1.9’ 0.9’

4’ 6.9’ 102 2.6’ 1.3’

5’ 8.7’ 66 3.2’ 1.6’

6’ 10.4 45 3.8’ 1.9’

13,100 3500

42W MR16

VNSP (EZY) 9˚

8’ 159 2.0’ 2.0’

12’ 71 2.9’ 2.9’

16’ 40 3.8’ 3.9’

20’ 26 4.9’ 4.9’

7’ 4.0’ 135 2.3’ 2.0’

10’ 5.8’ 66 3.3’ 2.8’

13’ 7.5’ 39 4.3’ 3.7’

15’ 9.2’ 28 5.3’ 4.5’

3’ 5.2’ 142 3.1’ 1.5’

4’ 6.9’ 80 4.1’ 2.0’

5’ 8.7’ 51 5.1’ 2.5’

6’ 10.4’ 35 6.2’ 2.9’

10,200 4000

50W MR16

NSP (EXT) 14˚

2’ 131 1.5’ 1.5’

3’ 58 2.2’ 2.2’

4’ 33 2.9’ 2.9’

5’ 21 3.6’ 3.6’

2’ 1.2’ 85 2.0’ 1.7’

3’ 1.7’ 38 3.0’ 2.5’

4’ 2.3’ 21 4.1’ 3.4’

5’ 2.9’ 14 5.1’ 4.2’

1’ 1.7’ 66 4.8’ 1.5’

2’ 3.5’ 16 9.7’ 2.9’

3’ 5.2’ 7 14.5’ 4.4’

4’ 6.9’ 4 19.3’ 5.8’

525 4000

20W MR16

FL (BAB) 40˚

4’ 100 2.9’ 2.9’

6’ 44 4.4’ 4.4’

8’ 25 5.8’ 5.8’

10’ 16 7.3’ 7.3’

3’ 1.7’ 115 3.0’ 2.5’

5’ 2.9’ 42 5.1’ 4.2’

7’ 4.0’ 21 7.1’ 5.8’

9’ 5.2’ 13 9.1’ 7.6’

1’ 1.7’ 200 4.8’ 1.5’

2’ 3.5’ 50 9.7’ 2.9’

3’ 5.2’ 22 14.5’ 4.4’

4’ 6.9’ 13 19.3’ 5.8’

1600 4000

35W MR16

FL (FMW) 40˚

4’ 116 2.9’ 2.9’

6’ 51 4.4’ 4.4’

8’ 29 5.8’ 5.8’

10’ 19 7.3’ 7.3’

3’ 1.7’ 134 3.0’ 2.5’

5’ 2.9 48 5.1’ 4.2’

7’ 4.0’ 25 7.1’ 5.9’

9’ 5.2’ 15 9.1’ 7.6’

1’ 1.7’ 231 4.8’ 1.5’

2’ 3.5’ 58 9.7’ 2.9’

3’ 5.2’ 26 14.5’ 4.4’

4’ 6.9’ 14 19.3’ 5.8’

1850 4000

50W MR16

FL (EXN) 40˚

3’ 128 3.1’ 3.1’

5’ 46 5.2’ 5.2’

7’ 23 7.3’ 7.3’

9’ 14 9.4’ 9.4’

3’ 1.7’ 83 4.6’ 3.6’

5’ 2.9’ 30 7.6’ 6.0’

7’ 4.0’ 15 10.7’ 8.4’

9’ 5.2’ 9 13.7’ 10.8’

1’ 1.7’ 144 22.3’ 2.1’

2’ 3.5’ 36 44.5’ 4.2’

3’ 5.2’ 16 66.8’ 6.2’

4’ 6.9’ 9 89.1’ 8.3’

1150 4000

50W MR16

WFL (FNV) 55˚

6’ 108 2.1’ 2.1’

8’ 61 2.8’ 2.8’

10’ 39 3.5’ 3.5’

12’ 27 4.2’ 4.2’

5’ 2.9 101 2.4’ 2.0’

7’ 4.0’ 52 3.3’ 2.9’

9’ 5.2’ 31 4.3’ 3.7’

11’ 6.4’ 21 5.2’ 4.5’

2’ 3.5’ 122 3.1’ 1.4’

3’ 5.2’ 54 4.7’ 2.1’

4’ 6.9’ 30 6.2’ 2.8’

5’ 8.7’ 20 7.8’ 3.5’

3900 4000

35W MR16

SP (FRA) 20˚

6’ 180 1.4’ 1.4’

12’ 80 2.1’ 2.1’

16’ 45 2.8’ 2.8’

20’ 29 3.5’ 3.5’

7’ 4.0’ 152 1.6’ 1.4’

10’ 5.8’ 75 2.3’ 2.0’

13’ 7.5’ 44 3.0’ 2.8’

16’ 9.2’ 29 3.7’ 3.2’

3’ 5.2’ 160 2.1’ 1.0’

4’ 6.9’ 90 2.9’ 1.4’

5’ 8.7’ 58 3.6’ 1.7’

6’ 10.4’ 40 4.3’ 2.1’

11,500 4000

37W MR16 IR

NSP 10˚

6’ 94 2.9’ 2.9’

8’ 53 3.8’ 3.8’

10’ 34 4.8’ 4.8’

12’ 24 5.8’ 5.8’

5’ 2.9’ 88 3.3’ 2.8’

7’ 4.0’ 45 4.6’ 3.9’

9’ 5.2’ 27 5.9’ 5.0’

11’ 6.4’ 18 7.2’ 6.1’

2’ 3.5’ 106 4.6’ 1.9’

3’ 5.2’ 47 7.0’ 2.9’

4’ 6.9’ 27 9.3’ 3.6’

5’ 8.7’ 17 11.6’ 4.8’

3400 4000

50W MR16

NFL (EXZ) 27˚

6’ 97 2.7’ 2.7’

8’ 55 3.5’ 3.5’

10’ 35 4.4’ 4.4’

12’ 24 5.3’ 5.3’

5’ 2.9’ 91 3.0’ 2.6’

7’ 4.0’ 46 4.2’ 3.6’

9’ 5.2’ 28 5.4’ 4.6’

11’ 6.4’ 19 6.6’ 5.6’

2’ 3.5’ 109 4.2’ 1.8’

3’ 5.2’ 49 6.2’ 2.7’

4’ 6.9’ 27 8.3’ 3.5’

5’ 8.7’ 18’ 10.4’ 4.4’

3,500 4000

37W MR16 IR

NFL 25˚

4’ 128 2.9’ 2.9’

6’ 57 4.4’ 4.4’

8’ 32 5.8’ 5.8’

10’ 21 7.3’ 7.3’

3’ 1.7’ 148 3.0’ 2.5’

5’ 2.9’ 53 5.1’ 4.2’

7’ 4.0’ 27 7.1’ 5.9’

9’ 5.2’ 16 9.1’ 7.6’

1’ 1.7’ 258 4.8’ 1.5’

2’ 3.5’ 64 9.7’ 2.9’

3’ 5.2’ 28 14.5’ 4.4’

4’ 6.9’ 16 19.3 5.8’

2,050 4000

37W MR16 IR

FL 40˚
