Lightolier Calculite C3MRD Manuel utilisateur

Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Calculite®Evolution Open Reflector Downlight C3MRD

Page 1 of 2 3" Aperture, MR16 (12V)

Spec. Sheet

C3MRD

"ICON"

5" (127mm)

12 5/8"

(321mm)

14 3/8"

(365mm)

9 5/8"

(245mm)

5" (127mm)

14 3/8"

(365mm)

10 1/8"

(257mm)

9" (229mm)

11 3/16"

(284mm)

22 3/8"

(568mm)

14 5/8"

(372mm)

Spec. Sheet

C3MRD

"FRAMING"

Ceiling Cutout: 3 1/2" (130mm) Dia.

For Complete Fixture Order: Trim Kit + Frame-In Kit. Each Sold Separately.

Trim Kit Frame-In Kit Lamp*

Cone Finish White Flange Polished Flange Flangeless

Clear C3MRD CLW C3MRD CLP C3MRD CLFT

Comfort Clear Diffuse C3MRD CCDW C3MRD CCDP C3MRD CCDFT

Champagne Bronze C3MRD CCZW C3MRD CCZP C3MRD CCZFT

Gold C3MRD GDW C3MRD GDP C3MRD GDFT

Matte White C3MRD WHW N/A C3MRD WHFT

Specular Black C3MRD BKW C3MRD BKP C3MRD BKFT

IC AirSeal Frame:

C3AICLV

C3ALCLVE1

Features

1. Trim Kit Aperture Cone: Low brightness; 0.040" aluminum, anodized;

50° visual cut-off to lamp and lamp image. Hinged, and snaps on for easy

tool-less installation. Self-flange in painted white or aperture matching

polished flange. Flangeless trim used with Plaster Trim Ring accessory.

Interchangeable with other 3" Evolution trims.

2. Lamp Support: Die-form aluminum with knurled surface for easy gripping

during relamping. Spring tension clips hold lamp and lens and allow fast

snap-in, snap-out relamping. Matte black finish. Accepts up to two 2" diam-

eter accessories.

3. Cover Glass: High temperature, soft focus lens.

4. Thick Ceiling Ready Brackets: Die-form steel, matte black finish. Adjust

trim kit vertically to accommodate up to 2" thick ceiling, lockable.

5. Lampholder: Procelain bi-pin socket. Pre-wired with No.18 AWG Teflon

leads.

6. Horizontal Adjustment Mechanism: Built-in ready for adjustable trim,

matte black finish.

7. Frame Vertical Adjustment Mechanism (C3LV): Accommodates mount-

ing to virtually any ceiling system using pre-installed mounting bars, or 1/2"

EMT tubing (by others). Single locking features secures all adjustments.

Alignment holes and markings allow fixture to be pre-set prior to installation.

Final adjustment can be made from below inside fixture.

8. Mounting Bars (C3LV): Galvanized steel, 0.048"; pre-installed telescoping

bars extend from 20" to 30" long and lock securely into position. Built-in lock-

ing tabs provide positive attachment to common T-bar systems. Self-center-

ing feature simplified installation in 24"O.C. grid systems. Attaches to steel

or wood joists without accessories.

9. Transformer: Replaceable from below. Magnetic: 120V/277V 60 Hz. dual-

voltage, core & coil. Note: Magnetic not recommended for residential or

noise sensitive areas. Electronic: 120V or 277V 50/60 Hz., regulated lamp

voltage, HPF, EMI and circuit protections, thermal auto-reset, quiet operation.

10. Frame-In Kit: See Frame-In Kit specification sheets for more information.

Non-IC and Non-IC AirSeal - Insulation must be kept 3"away from any parts

of the luminaire and must not be placed above luminaire in a manner which

will entrap heat. IC AirSeal - Luminaire may be in direct contact with thermal

insulation.

Options and Accessories

2" dia. Color Filters/Specialty filters: See ADF2/AF2 specification sheets

2" Dia. Louver: AL2HC

Plaster Trim Ring (use with flangeless trim): CA3FMR

Chicago Plenum: Consult Factory

Labels

U.L. (Suitable For Damp Locations), I.B.E.W.

*Lamp wattage restriction for Non-IC: 65W for up to 1" thick ceiling, 50W for

ceiling thickness greater than 1" (up to 2").

C3LV Non-IC Magnetic 120/277V 42W-65W MR16 (12V)

C3LVE1 Non-IC Electronic 120V 20W-65W MR16 (12V)

C3LVE2 Non-IC Electronic 277V 20W-65W MR16 (12V)

C3ALV Non-IC AirSeal®Magnetic 120/277V 42W-65W MR16 (12V)

C3ALVE1 Non-IC AirSeal®Electronic 120V 20W-65W MR16 (12V)

C3ALVE2 Non-IC AirSeal® Electronic 277V 20W-65W MR16 (12V)

C3AICLV IC AirSeal®Magnetic 120V 20W-50W MR16 (12V)

C3AICLVE1 IC AirSeal®Electronic 120V 20W-50W MR16 (12V)

Note: Magnetic not recommended for residential or noise sensitive areas.

5 1/2"

(140mm)

(127mm)

Plus Ceiling

Thk.

1/2"

(13mm)

2" (59mm) Max.

Ceiling Thk.

3" (76mm) Dia.

4" (102mm) Dia.

Flangeless Trim with

Plaster Ring Accessory

C3LV

9 1/2"

(242mm)

(229mm)

1/2" (13mm) C3AICLV

Vertical Adjustment

1" (25mm) to

2 3/4" (70mm)

3 3/8" (86mm) Dia.

10 4

23 67985

Non-IC Frame:

C3LV

C3LVE1

C3LVE2

Non-IC AirSeal Frame:

C3ALV

C3ALVE1

C3ALVE2

Job Information Type:

Calculite®Evolution Open Reflector Downlight C3MRD

Page 2 of 2 3" Aperture, MR16 (12V)

Spec. Sheet

C3MRD

"ICON"

Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Zonal Cavity Method - Effective Floor Cavity Reflectance = 20%

ANGLE MEAN CP

LUMENS

0 2084

5 1685 159

10 1228

15 839 245

20 543

25 280 140

30 107

35 40 31

40 10

45 0 2

50 0

55 0 0

60 0

65 0 0

70 0

75 0 0

80 0

85 0 0

90 0

37W MR16 IR - 40° FLOOD SYLVANIA HALOGEN LAMP, LUMEN RATING = 840 LMS, 120V ELECTRONIC TRANSFORMER

LUMINANCE SUMMARY CD. / SQ.

ANGLE MEAN CD/SQ M

45 0

55 0

65 0

75 0

85 0

** EFFICIENCY = 68.7% ** CERTIFIED TEST REPORT NO. 2741FR DATE: SEPT 24, 2004

COMPUTED BY LSI PROGRAM **TEST-LITE**

CANDLEPOWER DISTRIBUTION

CEILING 80% 70% 50% 30%

WALL 70 50 30 10 50 10 50 10 50 10 0

RCR

0 .82 .82 .82 .82 .80 .80 .76 .76 .73 .73 .69

1 .80 .78 .77 .76 .77 .75 .74 .73 .72 .71 .67

2 .77 .75 .74 .72 .74 .71 .72 .70 .70 .68 .66

3 .75 .73 .71 .69 .72 .69 .70 .68 .69 .66 .65

4 .74 .71 .68 .67 .70 .66 .69 .65 .67 .65 .63

5 .72 .68 .66 .64 .68 .64 .67 .63 .66 .63 .62

6 .70 .67 .64 .63 .66 .62 .65 .62 .64 .61 .61

7 .68 .65 .62 .61 .64 .60 .64 .60 .63 .60 .59

8 .67 .63 .61 .59 .62 .59 .62 .59 .61 .58 .58

9 .65 .61 .59 .57 .61 .57 .61 .57 .60 .57 .56

10 .64 .60 .58 .56 .60 .56 .59 .56 .59 .56 .55

LUMINAIRE INPUT WATTS = 38

Coefficients of Utilization

SC = .4

ZONAL LUMENS AND PERCENTAGES

ZONE LUMENS % LAMP %LUMINAIRE

0-30 543 64.75 94.30

0-40 574 68.44 99.67

0-60 576 68.67 100.00

0-90 576 68.67 100.00

40-90 1 0.23 0.33

60-90 0 0.00 0.00

90-180 0 0.00 0.00

0-180 576 68.67 100.00

Zonal Cavity Method - Effective Floor Cavity Reflectance = 20%

ANGLE MEAN CP

LUMENS

0 1985

5 1605 152

10 1170

15 799 233

20 518

25 266 133

30 102

35 38 30

40 9

45 0 2

50 0

55 0 0

60 0

65 0 0

70 0

75 0 0

80 0

85 0 0

90 0

50W MR16 IR - 40° FLOOD GE HALOGEN LAMP, LUMEN RATING = 800 LMS, 120V ELECTRONIC TRANSFORMER

500

1000

1500

2000

30˚

60˚

90˚

LUMINANCE SUMMARY CD. / SQ.

ANGLE MEAN CD/SQ M

45 0

55 0

65 0

75 0

85 0

** EFFICIENCY = 68.7% ** CERTIFIED TEST REPORT NO. 2817FR DATE: NOV 12, 2004

COMPUTED BY LSI PROGRAM **TEST-LITE**

CANDLEPOWER DISTRIBUTION

CEILING 80% 70% 50% 30%

WALL 70 50 30 10 50 10 50 10 50 10 0

RCR

0 .82 .82 .82 .82 .80 .80 .76 .76 .73 .73 .69

1 .80 .78 .77 .76 .77 .75 .74 .73 .72 .71 .67

2 .77 .75 .74 .72 .74 .71 .72 .70 .70 .68 .66

3 .75 .73 .71 .69 .72 .69 .70 .68 .69 .66 .65

4 .74 .71 .68 .67 .70 .66 .69 .65 .67 .65 .63

5 .72 .68 .66 .64 .68 .64 .67 .63 .66 .63 .62

6 .70 .67 .64 .63 .66 .62 .65 .62 .64 .61 .61

7 .68 .65 .62 .61 .64 .60 .64 .60 .63 .60 .59

8 .67 .63 .61 .59 .62 .59 .62 .59 .61 .58 .58

9 .65 .61 .59 .57 .61 .57 .61 .57 .60 .57 .56

10 .64 .60 .58 .56 .60 .56 .59 .56 .59 .56 .55

LUMINAIRE INPUT WATTS = 51

Coefficients of Utilization

SC = .4

ZONAL LUMENS AND PERCENTAGES

ZONE LUMENS % LAMP %LUMINAIRE

0-30 518 64.75 94.30

0-40 547 68.44 99.67

0-60 549 68.67 100.00

0-90 549 68.67 100.00

40-90 1 0.23 0.33

60-90 0 0.00 0.00

90-180 0 0.00 0.00

0-180 549 68.67 100.00

Zonal Cavity Method - Effective Floor Cavity Reflectance = 20%

ANGLE MEAN CP

LUMENS

0 2792

5 2258 214

10 1646

15 1125 328

20 729

25 375 188

30 144

35 55 42

40 14

45 0 3

50 0

55 0 0

60 0

65 0 0

70 0

75 0 0

80 0

85 0 0

90 0

50W MR16 IR - 40° FLOOD SYLVANIA HALOGEN LAMP, LUMEN RATING = 1125 LMS, 120V ELECTRONIC TRANSFORMER

LUMINANCE SUMMARY CD. / SQ.

ANGLE MEAN CD/SQ M

45 0

55 0

65 0

75 0

85 0

** EFFICIENCY = 68.8% ** CERTIFIED TEST REPORT NO. 2629FR DATE: MAY 12, 2004

COMPUTED BY LSI PROGRAM **TEST-LITE**

CANDLEPOWER DISTRIBUTION

CEILING 80% 70% 50% 30%

WALL 70 50 30 10 50 10 50 10 50 10 0

RCR

0 .82 .82 .82 .82 .80 .80 .76 .76 .73 .73 .69

1 .80 .78 .77 .76 .77 .75 .74 .73 .72 .71 .67

2 .77 .75 .74 .72 .74 .71 .72 .70 .70 .68 .66

3 .75 .73 .71 .69 .72 .69 .70 .68 .69 .66 .65

4 .74 .71 .68 .67 .70 .66 .69 .65 .67 .65 .63

5 .72 .68 .66 .64 .68 .64 .67 .63 .66 .63 .62

6 .70 .67 .64 .63 .66 .62 .65 .62 .64 .61 .61

7 .68 .65 .62 .61 .64 .60 .64 .60 .63 .60 .59

8 .67 .63 .61 .59 .62 .59 .62 .59 .61 .58 .58

9 .65 .61 .59 .57 .61 .57 .61 .57 .60 .57 .56

10 .64 .60 .58 .56 .60 .56 .59 .56 .59 .56 .55

LUMINAIRE INPUT WATTS = 51

Coefficients of Utilization

SC = .4

ZONAL LUMENS AND PERCENTAGES

ZONE LUMENS % LAMP %LUMINAIRE

0-30 729 64.82 94.21

0-40 771 68.56 99.65

0-60 774 68.80 100.00

0-90 774 68.80 100.00

40-90 2 0.24 0.35

60-90 0 0.00 0.00

90-180 0 0.00 0.00

0-180 774 68.80 100.00

30˚

60˚

500˚

1000˚

1500˚

2000˚

30˚

60˚

550˚

1100˚

1650˚

2200˚

30˚

60˚

750˚

1500˚

2250˚

3000˚

Reflector

Finish

Reflector

Finish

Autres manuels Lightolier Luminaire

Lightolier

Lightolier 4F35 Manuel utilisateur

Lightolier

Lightolier Lytespan 8171WH Manuel utilisateur

Lightolier

Lightolier Calculite ProSpec PB3H3070 Manuel utilisateur

Lightolier

Lightolier QVL2GPFSS2FT Manuel utilisateur

Lightolier

Lightolier CTS3-18 Manuel utilisateur

Lightolier

Lightolier Calculite C6T6VN Manuel utilisateur

Lightolier

Lightolier Lytespan 8227WH Manuel utilisateur

Lightolier

Lightolier Lytespan 8292WECY Manuel utilisateur

Lightolier

Lightolier PowerArc Modular spot reflector Mode d’emploi

Lightolier

Lightolier AGO Manuel utilisateur

Lightolier

Lightolier Lytecaster 1004ICR Manuel utilisateur

Lightolier

Lightolier Coffaire II CFA2GPF217 Manuel utilisateur

Lightolier

Lightolier Calculite 7790QD Manuel utilisateur

Lightolier

Lightolier Calculite ProSpec PA1M1675 Manuel utilisateur

Lightolier

Lightolier Calculite C6T6A-MHT6RS Manuel utilisateur

Lightolier

Lightolier ProSpec DRP16 Manuel utilisateur

Lightolier

Lightolier Calculite C4X4MRA Manuel utilisateur

Lightolier

Lightolier ProSpec 37224 Manuel utilisateur

Lightolier

Lightolier SS 2 LAMP Manuel utilisateur

Lightolier

Lightolier SV T5 STRIP Manuel utilisateur

Lightolier

Lightolier Tangent FXG9P Manuel utilisateur

Lightolier

Lightolier ProSpec 26800 Manuel utilisateur

Lightolier

Lightolier Calculite GW Manuel utilisateur

Lightolier

Lightolier Lytespan 9170 Manuel utilisateur

Manuels Luminaire populaires d'autres marques

Emos

Emos CLASSIC ZY1431T Manuel utilisateur

Westinghouse

Westinghouse Outdoor Lighting Fixture Manuel utilisateur

Hedler

Hedler C 12 silent Manuel utilisateur

Blizzard Lighting

Blizzard Lighting Puck: CSI Manuel utilisateur

Energetic Lighting

Energetic Lighting ELYSL-5004 Series Manuel utilisateur

Lightmaxx

Lightmaxx Shaft 5R Manuel utilisateur

Triarch

Triarch 31083 Manuel utilisateur

Philips

Philips 32614 Series Manuel utilisateur

IKEA

IKEA TIVED Manuel utilisateur

Chauvet Professional

Chauvet Professional ROGUE R1 BEAM WASH Manuel utilisateur

Martin

Martin MAC 250 Krypton Manuel utilisateur

Cooper Lighting

Cooper Lighting Halo L3232E Manuel utilisateur

Stageline

Stageline ODW-2410RGBW Manuel utilisateur

Light Sky

Light Sky Tornado Series Manuel utilisateur

ArtFox

ArtFox Beam 15R extreme Manuel utilisateur

GLG

GLG multispot 330 Manuel utilisateur

Home Accents Holiday

Home Accents Holiday TY052-1924-1 Manuel utilisateur

SELF Electronics

SELF Electronics FLEX Manuel utilisateur
