Lightolier Lytespan 6320 Manuel utilisateur

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lytespan®Track Lighting System 6320

Page 1 of 2 Universal Lytespot®

Lightolier is a Philips group brand

Features

1. Lytespan Attachment Fitting: die-cast zinc alloy.

2. Pivot Mounting: tensioned with built-in stop, provides 90° vertical

adjustment.

3. Movable Brass Contact: extends for connection to 2nd circuit in Advent

Lytespan Track.

4. Lever: energizes unit.

5. Polarity Keyway

6. Thumbscrew: for lampholder adjustment.

Electrical

Porcelain socket, medium base, nickel plated screw shell.

No. 18 braided SF-1 leads.

Finish

All painted finishes baked enamel.

Labels

UL, I.B.E.W.

Ordering Information

Catalog No. Description of Lamps Finish Mountings

6320 Housing Only = 75W R20; 75W-100W R30; 250W PAR38; Matte White All Lytespan Track Systems

6322 150W PAR38 Cool Beam; 75W PAR16, 50W PAR20, 75W PAR30 Matte Black

Job Information Type:

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Lytespan®Track Lighting System 6320

Page 1 of 2 Universal Lytespot®

Lightolier is a Philips group brand

3.200 2,500

75W PAR30

NFL(Halogen) 30ϒ

Lighting Data 030 , 45 or 60 Vertical

LAMP0ϒAIMING ANGLE A=30ϒAIMING ANGLE A=45ϒAIMING ANGLE A=60ϒAIMING ANGLE

LBeam length

WBeam Width

CDistance to center beam

DDistance

AAiming angle

FC Footcandles

Land Ware the outer points where

the candle power drops to 50% of

the maximum. FC are the intial foot-

candles at the center of the beam.

6' 89 3.2' 3.2'

8' 50 4.3' 4.3'

10' 32 5.4' 5.4'

12' 22 6.4' 6.4'

5' 2.9' 83 3.7' 3.1'

7' 4.0' 42 5.1' 4.3'

9' 5.2' 26 6.6' 5.6'

11' 6.4' 17 8.1' 6.8'

3' 3.0' 126 3.5' 2.3'

5' 5.0' 45 5.8' 3.8'

7' 7.0' 23 8.1' 5.3'

9' 9.0' 114 10.4' 6.8'

2' 3.5' 100 5.5' 2.1'

3' 5.2' 44 8.2' 3.2'

4' 6.9' 25 10.9' 4.3'

5' 8.7' 16 13.7' 5.4'

8' 219 1.3' 1.3'

12' 97 1.9' 1.9'

16' 55 2.5' 2.5'

20' 35 3.1' 3.1'

7' 4.0' 186 1.5' 1.3'

10' 5.8' 91 2.1' 1.8'

13' 7.5' 54 2.7' 2.4'

16' 9.2' 36 3.4' 2.9'

5' 5.0' 198 1.6' 1.1'

7' 7.0' 101 2.2' 1.6'

9' 9.0' 61 2.9' 2.0'

11' 11.0' 41 3.5' 2.4'

3' 5.2' 194 1.9' 0.9'

4' 6.9' 109 2.6' 1.3'

5' 8.7' 70 3.2' 1.6'

6' 10.4' 49 3.8' 1.9'

14,000 2,500

75W PAR30

NSP (Halogen) 9ϒ

10' 195 1.6' 1.6'

15' 87 2.4' 2.4'

20' 49 3.1' 3.1'

25' 31 3.9' 3.9'

8' 4.6' 198 1.7' 1.5'

12' 6.9' 88 2.5' 2.2'

16' 9.2' 49 3.4' 2.9'

20' 11.5' 32 4.2' 3.8'

6' 6.0' 192 1.9' 1.3'

9' 9.0' 85 2.9' 2.0'

12' 12.0' 48 3.8' 2.7'

15' 15.0' 31 4.8' 3.3'

4' 6.9' 152 2.6' 1.3'

6' 10.4' 68 3.8' 1.9'

8' 13.9' 38 5.1' 2.5'

10' 17.3' 24 8.4' 3.1'

19.500 2,500

90W PAR38

NSP (Halogen)9ϒ

DFCLWDC FC LW DC FC LW DC FC LW

Beam Spread Beam Center Rated

50% Max. CP C.P. Candelas Life-Hrs

4,500 2,500

90W PAR38

FL (Halogen) 28ϒ

6' 125 3.0' 3.0'

8' 70 4.0' 4.0'

10' 45 5.0' 5.0'

12' 31 6.0' 6.0'

5' 2.9' 117 3.4' 2.9'

7' 4.0' 60 4.8' 4.0'

9' 5.2' 36 6.1' 5.2'

11' 6.4' 24 7.5' 6.3'

3' 3.0' 177 3.2' 2.1'

5' 5.0' 64 5.3' 3.5'

7' 7.0' 32 7.4' 4.9'

9' 9.0' 20 9.6' 8.3'

2' 3.5' 141 4.9' 2.0'

3' 5.2' 63 7.4' 3.0'

4' 6.9' 35 9.8' 4.0'

5' 8.7' 23 12.3' 5.0'

8' 227 1.7' 1.7'

12' 101 2.5' 2.5'

16' 57 3.4' 3.4'

20' 36 4.2' 4.2'

7' 4.0' 192 2.0' 1.7'

10' 5.8' 94 2.8' 2.4'

13' 7.5' 56 3.7' 3.2'

16' 9.2' 37 4.5' 3.9'

5' 5.0' 205 2.1' 1.5'

7' 7.0' 105 3.0' 2.1'

9' 9.0' 63 3.8' 2.7'

11' 11.0' 42 4.7' 3.3'

3' 5.2' 201 2.6' 1.3'

4' 6.9' 113 3.5' 1.7'

5' 8.7' 73 4.3' 2.1'

6' 10.4' 50 5.2' 2.5'

14.500 2,500

90W PAR38

SP (Halogen) 12ϒ

10' 290 1.7' 1.7'

15' 120 2.6' 2.6'

20' 73 3.5' 3.5'

25' 46 4.4' 4.4'

8' 4.6' 294 1.9' 1.6'

12' 6.9' 131 2.8' 2.4'

16' 9.2' 74 3.7' 3.2'

20' 11.5' 47 4.7' 4.0'

6' 6.0' 285 2.1' 1.5'

9' 9.0' 127 3.2' 2.2'

12' 12.0' 71 4.2' 3.0'

15' 15.0' 46 5.3' 3.7'

4' 6.9 227 2.9' 1.4'

6' 10.4' 101 4.3' 2.1'

8' 13.9' 57 5.7' 2.8'

10' 17.3' 36 7.2' 3.5'

29,000 3,000

100W PAR38

SP (Halogen)10ϒ

3,400 3,000

100W PAR38

FL (HIR)40ϒ

6' 94 4.4' 4.4'

8' 53 5.8' 5.8'

10' 34 7.3' 7.3'

12' 24 8.7' 8.7'

5' 2.9' 88 5.1' 4.2'

7' 4.0' 45 7.1' 5.9'

9' 5.2' 27 9.1' 7.6'

11' 6.4' 18 11.2' 9.2'

3' 3.0' 134 5.0' 3.1'

5' 5.0' 48 8.4' 5.1'

7' 7.0' 25 11.7' 7.2'

9' 9.0' 15 15.1' 8.3'

2' 3.5' 106 9.7' 2.9'

3' 5.2' 47 14.5' 4.4'

4' 6.9' 27 19.3' 5.8'

5' 8.7' 17 24.2' 7.3'

7' 153 3.4' 3.4'

10' 75 4.8' 4.8'

13' 44 8.2' 6.2'

16' 29 7.7' 7.7'

6' 3.5' 135 3.9' 3.3'

9' 5.2' 60 5.9' 5.0'

12' 6.9' 34 7.8' 6.7'

15' 8.7' 22 9.8' 8.3'

4' 4.0' 168 4.1' 2.7'

6' 6.0' 74 6.1' 4.1'

8' 8.0' 41 8.2' 5.4'

10' 10.0' 27 10.2' 6.8'

2' 3.5' 234 4.8' 1.9'

3' 5.2' 104 7.4' 2.9'

4' 6.9' 59 9.3' 3.8'

5' 8.7' 38 11.6' 4.8'

7,500 3,000

100W PAR38

NFL (Halogen)27ϒ

10' 250 1.7' 1.7'

15' 111 2.6' 2.6'

20' 63 3.5' 3.5'

25' 40 4.4' 4.4'

8' 4.6' 254 1.9' 1.6'

12' 6.9' 113 2.8' 2.4'

16' 9.2' 63 37' 3.2'

20' 11.5' 41 4.7' 4.0'

6' 6.0' 246 2.1' 1.5'

9' 9.0' 109 3.2' 2.2'

12' 12.0' 61 4.2' 3.0'

15' 15.0' 39 5.3' 3.7'

4' 6.9' 195 2.9' 1.4'

6' 10.4' 87 4.3' 2.1'

8' 13.9' 49 5,7' 2.8'

10' 17.3' 31 7.2' 3.5'

25,000 3.000

120W PAR38

NSP (Halogen) 10ϒ

40,000 4,200

250W PAR38

SP (Halogen) 11ϒ

15' 178 2.9' 2.9'

20' 100 3.9' 3.9'

25' 64 4.8' 4.8'

30' 44 5.8' 5.8'

10' 5.8' 260 2.6' 2.2'

15' 8.7' 115 3.9' 3.3'

20' 11.5' 65 5.2' 4.4'

25' 14.4' 42 6.4' 5.6'

8' 8.0' 221 3.1' 2.2'

12' 12.0' 98 4.7' 3.3'

18' 18.0' 55 6.2' 4.4'

20' 20.0' 35 7.8' 5.4'

5' 8.7' 200 4.0' 1.9'

8' 13.9' 78 6.3' 3.1'

11' 19.1' 41 8.7' 4.2'

14' 24.2' 26 11.1' 5.4'

6' 139 3.2' 3.2'

8' 78 4.3' 4.3'

10' 50 5.4' 5.4'

12' 35 6.4' 6.4'

5' 2.9' 130 3.7' 3.1'

7' 4.0' 66 5.1' 4.3'

9' 5.2' 40 6.8' 5.6'

11' 6.4' 27 8.1' 6.8'

3' 3.0' 196 3.5' 2.3'

5' 5.0' 71 5.8' 3.8'

7' 7.0' 36 8.1' 5.3'

9' 9.0' 22 10.4' 6.8'

2' 3.5' 156 5.5' 2.1'

3' 5.2' 69 8.2' 3.2'

4' 6.9' 39 10.9' 4.3'

5' 8.7' 25 13.7' 5.4'

5,000 3,000

120W PAR38

FL (Halogen) 30ϒ

7' 163 4.0' 4.0'

10' 80 5.7' 5.7'

13' 47 7.5' 7.5'

16' 31 9.2' 9.2'

6' 3.5' 144 4.7' 4.0'

9' 5.2' 64 7.1' 6.0'

12' 6.9' 36 9.4' 7.9'

15' 8.7' 23 11.8' 9.9'

4' 4.0' 177 5.0' 3.2'

6' 6.0' 79 7.5' 4.9'

8' 8.0' 44 10.0' 6.5'

10' 10.0' 28 12.5' 9.1'

2' 3.5' 250 6.1' 2.3'

3' 5.2' 111 9.1' 3.4'

4' 6.9' 63 12.2' 4.6'

5' 8.7' 40 15.2' 5.7'

8,000 4,200

250W PAR38

FL (Halogen) 32ϒ

30 , 45 or 60 Horizontal
