Single Phase Online UPS

Liebert Adapt BX

User Manual –6k –10kVA

Table of Contents

1. Safety and EMC instructions......................................................................1

1-1. Transportation and Storage.....................................................................1

1-2. Preparation..............................................................................................1

1-3. Installation...............................................................................................1

1-4. Operation................................................................................................1

1-5. Standards................................................................................................2

2. Installation and Operation ..........................................................................3

2-1. Unpacking and Inspection.......................................................................3

2-2. Rear Panel View......................................................................................3

2-3. Single UPS Installation............................................................................4

2-4. UPS Installation for Parallel System........................................................6

2-5. Software Installation................................................................................6

3. Operations ...................................................................................................7

3-1. Button Operation.....................................................................................7

3-2. LED Indicators and LCD Panel................................................................7

3-3. Audible Alarm..........................................................................................9

3-4. Single UPS Operation...........................................................................10

3-5. Parallel Operation .................................................................................12

3-6. Abbreviation Meaning in LCD Display ...................................................14

3-7. LCD Setting...........................................................................................14

3-8. Operating Mode/Status Description.......................................................19

3-9. Fault Code.............................................................................................20

3-10. Warning Indicator................................................................................21

4. Trouble Shooting.......................................................................................22

5. Storage and Maintenance .........................................................................23

5-1. Storage..................................................................................................23

5-2. Maintenance..........................................................................................23

6. Specifications............................................................................................24

1. Safety and EMC instructions

Please read carefully the following user manual and the safety instructions before installing the unit or using the

unit!

1-1. Transportation and Storage

Please transport the UPS system only in the original package to protect against shock and impact.

The UPS must be stored in the room where it is ventilated and dry.

1-2. Preparation

Condensation may occur if the UPS system is moved directly from cold to warm environment. The

UPS system must be absolutely dry before being installed. Please allow at least two hours for the

UPS system to acclimate the environment.

Do not install the UPS system near water or in moist environments.

Do not install the UPS system where it would be exposed to direct sunlight or nearby heater.

Do not block ventilation holes in the UPS housing.

1-3. Installation

Do not connect appliances or devices which would overload the UPS (e.g. big motor-type

equipment)) to the UPS output sockets or terminal.

Place cables in such a way that no one can step on or trip over them.

Do not block air vents in the housing of UPS. The UPS must be installed in a location with good

ventilation. Ensure enough space on each side for ventilation.

UPS has provided earthed terminal, in the final installed system configuration, equipotential earth

bonding to the external UPS battery cabinets.

The UPS can be installed only by qualified maintenance personnel.

An appropriate disconnect device as short-circuit backup protection should be provided in the

building wiring installation.

An integral single emergency switching device which prevents further supply to the load by the UPS

in any mode of operation should be provided in the building wiring installation.

Connect the earth before connecting to the building wiring terminal.

Installation and Wiring must be performed in accordance with the local electrical laws and

regulations.

1-4. Operation

Do not disconnect the earth conductor cable on the UPS or the building wiring terminals in any time

since this would cancel the protective earth of the UPS system and of all connected loads.

The UPS system features its own, internal current source (batteries). The UPS output sockets or

output terminal blocks may be electrically live even if the UPS system is not connected to the

building wiring outlet.

In order to fully disconnect the UPS system, first press the “OFF” button and then disconnect the

mains.

Ensure that no liquid or other foreign objects can enter into the UPS system.

The UPS can be operated by any individuals with no previous experience.

1-5. Standards

* Safety

IEC/EN 62040-1-1

* EMI

Conducted Emission...............................:IEC/EN 62040-2

Category C3

Radiated Emission..................................:IEC/EN 62040-2

Category C3

*EMS

ESD.........................................................:IEC/EN 61000-4-2

Level 4

RS........................................................ ...:IEC/EN 61000-4-3

Level 3

EFT......................................................... :IEC/EN 61000-4-4

Level 4

SURGE................................................... :IEC/EN 61000-4-5

Level 4

CS........................................................... :IEC/EN 61000-4-6

Level 3

Power-frequency Magnetic field.............. :IEC/EN 61000-4-8

Level 3

Low Frequency Signals............................:IEC/EN 61000-2-2

Warning: This is a product for commercial and industrial application in the

second environment-installation restrictions or additional measures may be

needed to prevent disturbances.

2. Installation and Operation

There are two different types of online UPS: standard and long-run models. Please refer to the following model

table.

Model

Type

Model

Type

Adapt BX 6K

Standard model

Adapt BX 6KL

Long-run model

Adapt BX 10K

Adapt BX 10KL

2-1. Unpacking and Inspection

Unpack the package and check the package contents. The shipping package contains:

● One UPS

●One user manual

● One monitoring software CD

●One RS-232 cable (option)

●One USB cable

●One EPO plug

●One parallel cable (only available for parallel model)

●One share current cable (only available for parallel model)

NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged during

transportation. Do not turn on the unit and notify the carrier and dealer immediately if there is any damage or

lacking of some parts. Please keep the original package in a safe place for future use.

2-2. Rear Panel View

Diagram 1: 6K(L)/10K(L) Rear Panel Diagram 2: 6K(L)/10K(L) Input/Output Terminal

Diagram 3: 6K/10K Battery Bank Rear

1. RS-232 communication port

2. USB communication port

3. Emergency power off function connector (EPO connector)

4. Share current port (only available for parallel model)

5. Parallel port (only available for parallel model)

6. Intelligent slot

7. Power stage fan

8. External maintenance bypass switch port

9. Input circuit breaker

10. Input/Output terminal(Refer to Diagram 2 for the details)

11. External battery connector

12. Output terminal: connect to mission-critical loads

13. Grounding terminal

14. Utility input terminal

15. Battery bank output circuit breaker

2-3. Single UPS Installation

Installation and wiring must be performed in accordance with the local electric laws/regulations and execute the

following instructions by professional personnel.

1) Make sure the mains wire and breakers in the building are enough for the rated capacity of UPS to avoid

the hazards of electric shock or fire.

NOTE: Do not use the wall receptacle as the input power source for the UPS, as its rated current is less than

the UPS’s maximum input current. Otherwise the receptacle may be burned and destroyed.

2) Switch off the mains switch in the building before installation.

3) Turn off all the connected devices before connecting to the UPS.

4) Prepare wires based on the following table:

Model

Wiring spec (AWG)

Input

Output

Battery

Ground

6KL

10K

10KL

NOTE 1: The cable for 6K/6KL should be able to withstand over 40A current. It is recommended to use

10AWG or thicker wire for safety and efficiency.

NOTE 2: The cable for 10K/10KL should be able to withstand over 63A current. It is recommended to use

8AWG or thicker wire for safety and efficiency.

NOTE 3: The selections for color of wires should be followed by the local electrical laws and regulations.

5) Remove the terminal block cover on the rear panel of UPS. Then connect the wires according to the

following terminal block diagrams: (Connect the earth wire first when making wire connection. Disconnect the

earth wire last when making wire disconnection!)

Terminal Block wiring diagram

NOTE 1: Make sure that the wires are connected tightly with the terminals.

NOTE 2: There are two kinds of outputs for 6K(L)/10K(L): output terminal/outlets and programmable terminal.

Please connect non-critical devices to the programmable terminal and critical devices to the output

terminal/outlets. During power failure, you may extend the backup time to critical devices by setting shorter

backup time for non-critical devices.

NOTE 3: Please install the output breaker between the output terminal and the load, and the breaker should be

qualified with leakage current protective function if necessary.

6) Insert the EPO plug into the EPO slot on the rear panel.

7) Put the terminal block cover back to the rear panel of the UPS.

Warning: (Only for standard model)

● Make sure the UPS is not turned on before installation. The UPS should not be turned on during wiring

connection.

● Do not try to modify the standard model to the long-run model. Particularly, do not try to connect the

standard internal battery to the external battery. The battery type and voltage may be different. If you

connect them together, it maybe causes the hazard of electric shock or fire!

Warning: (Only for long-run model)

● Make sure a DC breaker or other protection device between UPS and external battery pack is installed. If

not, please install it carefully. Switch off the battery breaker before installation.

Warning:

● For standard battery pack, there are one DC breaker to disconnect the battery pack and the UPS. But for

other external battery pack, make sure a DC breaker or other protection device between UPS and external

battery pack is installed. If not, please install it carefully. Switch off the battery breaker before installation.

NOTE: Set the battery pack breaker in “OFF” position and then install the battery pack.

● Pay highly attention to the rated battery voltage marked on the rear panel. If you want to change the

numbers of the battery pack, please make sure you modify the setting simultaneously. The connection with

wrong battery voltage may cause permanent damage of the UPS. Make sure the voltage of the battery

pack is correct.

● Pay highly attention to the polarity marking on external battery terminal block, and make sure the correct

Input Neutral

Input Line

Ground

Output Line

Output Neutral

battery polarity is connected. Wrong connection may cause permanent damage of the UPS.

● Make sure the protective earth ground wiring is correct. The wire current spec, color, position, connection

and conductance reliability should be checked carefully.

● Make sure the utility input & output wiring is correct. The wire current spec, color, position, connection and

conductance reliability should be checked carefully. Make sure the L/N site is correct, not reverse and

short-circuited.

2-4. UPS Installation for Parallel System

If the UPS is only available for single operation, you may skip this section to the next.

1) Install and wires the UPSs according to the section 2-3.

2) Connect the output wires of each UPS to an output breaker.

3) Connect all output breakers to a major output breaker. Then this major output breaker will directly connect

to the loads.

4) Each UPS is connected to an independent battery pack.

5) Remove the cover of parallel share current cable port on the UPS, connect each UPS one by one with the

parallel cable and share current cable, and then screw the cover back again.

NOTE: The parallel system can not use one battery pack. Otherwise, it will cause system permanent failure.

6) Refer to the following wiring diagram:

Power cable connection

Wiring diagram of parallel system

2-5. Software Installation

For optimal computer system protection, install UPS monitoring software to fully configure UPS shutdown.

Parallel communication port

connection

Share current cable connection

3. Operations

3-1. Button Operation

Button

Function

ON/Enter Button

Turn on the UPS: Press and hold the button more than 0.5s to turn on the UPS.

Enter Key: Press this button to confirm the selection in setting menu.

OFF/ESC Button

Turn off the UPS: Press and hold the button more than 0.5s to turn off the UPS.

Esc key: Press this button to return to last menu in setting menu.

Test/Up Button

Battery test: Press and hold the button more than 0.5s to test the battery while in

AC mode, or CVCF mode.

UP key: Press this button to display next selection in setting menu.

Mute/Down Button

Mute the alarm: Press and hold the button more than 0.5s to mute the buzzer.

Please refer to section 3-4-9 for details.

Down key: Press this button to display previous selection in setting menu.

Test/Up +

Mute/Down Button

Press and hold the two buttons simultaneous more than 1s to enter/escape the

setting menu.

* CVCF mode means converter mode.

3-2. LED Indicators and LCD Panel

LED Indicators:

There are 4 LEDs on front panel to show the UPS working status:

Mode LED

Bypass

Line

Battery

Fault

UPS Startup

●

Bypass mode

●

○

AC mode

○

●

○

Battery mode

○

●

○

CVCF mode

○

●

○

Battery Test

●

○

ECO mode

●

○

Fault

○

●

Note: ●means LED is lighting, and ○means LED is faded.

LCD panel

LED indicators

LCD Panel:

Display

Function

Backup time information

Indicates the backup time in pie chart.

Indicates the backup time in numbers.

H: hours, M: minutes, S: seconds

Fault information

Indicates that the warning and fault occurs.

Indicates the fault codes, and the codes are listed in details in section 3-9.

Mute operation

Indicates that the UPS alarm is disabled.

Output & Battery voltage information

Indicates the output voltage, frequency or battery voltage.

Vac: output voltage, Vdc: battery voltage, Hz: frequency

Load information

Indicates the load level by 0-25%, 26-50%, 51-75%, and 76-100%.

Indicates overload.

Indicates the load or the output is short.

Programmable output information

Indicates that the programmable outputs are working.

Mode operation information

Indicates the UPS connects to the mains.

Indicates the battery is working.

Indicates the bypass circuit is working.

Indicates the ECO mode is enabled.

Indicates the Inverter circuit is working.

Table des matières

Autres manuels Liebert UPS

Liebert

Liebert GXT3-240TBATTCE Manuel utilisateur

Liebert

Liebert 2700VA Manuel utilisateur

Liebert

Liebert UPStation S VCR232C Guide rapide

Liebert

Liebert PST4 Manuel utilisateur

Liebert

Liebert GXT4 Manuel utilisateur

Liebert

Liebert itON 600 (India Version) Manuel utilisateur

Liebert

Liebert 115V Manuel utilisateur

Liebert

Liebert Series 300 Manuel utilisateur

Liebert

Liebert Series 600T Manuel utilisateur

Liebert

Liebert GXT2 - 3X1 Manuel utilisateur

Liebert

Liebert NXL Manuel utilisateur

Liebert

Liebert UPStation GXT 2U Manuel utilisateur

Liebert

Liebert Series 300 Manuel utilisateur

Liebert

Liebert Nfinity 208 V / 240 V 60Hz Manuel utilisateur

Liebert

Liebert GXT3 Manuel utilisateur

Liebert

Liebert UPStation GX Manuel utilisateur

Liebert

Liebert NX series Manuel

Liebert

Liebert NfinityTM Manuel utilisateur

Liebert

Liebert GXT3 5000RT208 Manuel utilisateur

Liebert

Liebert PowerSure Personal Manuel utilisateur

Liebert

Liebert APM 150 Manuel utilisateur

Liebert

Liebert Nfinity Extended Battery Cabinet Manuel utilisateur

Liebert

Liebert itON BX Manuel utilisateur

Liebert

Liebert Hinet 10kVA Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
