LG 32SM5DJ Manuel utilisateur

OWNER’S MANUAL

LG Digital Signage

(MONITOR SIGNAGE)

32SM5DJ

www.lg.com

Please read the user manual before using this product to ensure safe and convenient

use.

ENGLISH

TABLE OF CONTENTS

BASIC .............................................3

- Checking the Accessories ............................................3

- Checking the Optional Accessories.........................4

- Learning the Buttons......................................................5

GETTING READY ...........................6

- Connecting the IR Sensors..........................................6

- Mounting and Removing the LG Logo Bracket 7

- Assembling the Memory Cover.................................8

- Kensington Lock Device ................................................9

CHECKING BEFORE

INSTALLATION ........................... 10

- Installation Orientation ..............................................10

- Installation Location.....................................................11

- Wall Mount Holder .......................................................12

PRECAUTIONS FOR USE............ 13

- Dust.......................................................................................13

- Afterimage ........................................................................13

PRODUCT SPECIFICATIONS...... 15

LICENCE...................................... 18

ENGLISH

WARNING - This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may

cause radio interference.

BASIC

NOTE

•The accessories provided with your product may vary depending on the model or region.

•Product specifications or contents in this manual may be changed without prior notice due to upgrade of product

functions.

•SuperSign Software & Manual

- Visit http://partner.lge.com to download the latest SuperSign software and manual.

Checking the Accessories

x1

(M3xL6)

RGB RS-232C/D-Sub RS-232CRS-232C

Depending on country

ENGLISH

Checking the Optional Accessories

In order to improve product performance, optional accessories are subject to change without prior notice.

The illustrations in this manual may differ from the actual product and its accessories.

Refer to the product manual for the components of the optional accessories.

ST-322T

ENGLISH

Learning the Buttons

The illustrations may differ depending on the model.

Screen Button

•: Changes the input signal.

• : Opens the main menu or saves the input selection and exits the menu.

•: Adjusts up and down.

•: Moves left or right.

•: Shows the signal and mode information currently set and allows the user to select a menu.

•: Turns the power on and off.

ENGLISH

GETTING READY

Connecting the IR Sensors

Connecting the cable to the product allows it to receive signals from the remote control.

Rotate the IR sensor according to horizontal or vertical use.

- The illustrations may differ depending on the model.

Default Mount - Horizontal Use

(Front) (Back)

Vertical Use

(Front) (Back)

ENGLISH

Mounting and Removing the LG Logo Bracket

- Applies only to some models.

- The illustrations may differ depending on the model.

Removing the LG Logo Bracket

Place a clean cloth on the floor, and remove one screw from the LG logo bracket on the lower back of the monitor with

a screwdriver.

LG Logo Bracket

Mounting the LG Logo Bracket on the Right

Screw the LG logo bracket into the hole on the right.

LG Logo Bracket

ENGLISH

Assembling the Memory Cover

After attaching the USB memory, use a screw to assemble the cover, as shown in the illustration, to prevent theft.

(M3 x L6)

ENGLISH

Kensington Lock Device

(This feature applies only to some models.)

The Kensington lock device connector is located on the back of the monitor. For more information on installation and

use, refer to the user manual provided with the locking device.

Connect the Kensington security system cable between the monitor and a table.

NOTE

•The Kensington lock device is an optional specification.

•This is a general illustration of installation and may look different from the product held by the customer.

ENGLISH

CHECKING BEFORE INSTALLATION

We are not responsible for product damage caused by failure to follow the guide.

Installation Orientation

Using Vertically

When installing vertically, rotate the monitor 90 degrees anti-clockwise while facing the front of the screen.

Tilt Angle

40 mm

15˚

Ceiling, Floor Orientation
