LG 47TS30MF Manuel utilisateur

www.lg.com

OWNER’S MANUAL

MONITOR SIGNAGE

26TS30MF

47TS30MF

Please read this manual carefully before operating the your set and

retain it for future reference.

MONITOR SIGNAGE MODELS

ENG

ENGLISH

ENG

ENGLISH

CONTENTS

3 INSTALLATIONPREPARATION

3 Accessories

4 MountingHoles

6 UnpackingandCabling

8 PortraitLayout(Onlysupportedfor47TS30MF)

9 StorageMethodforPanelProtection

9 - CorrectMethod

9 - IncorrectMethod

10 PRODUCTINSTALLATION

10 Lightinginstallation

11 InstallationinEnclosure

12 Precaution

12 - CorrectMethod

12 - IncorrectMethod

13 TROUBLESHOOTING

14 SPECIFICATIONS

14 26TS30MF

15 47TS30MF

16 LVDSPINMAPGUIDE

16 26TS30MF

17 47TS30MF

ENG

ENGLISH

INSTALLATIONPREPARATION

Accessories

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

 Donotuseanyunapprovedorcounterfeitpartsoraccessoriestoensurethesafetyandproductlife

span.

 Anydamagesorinjuriesbyusingunapproveditemsarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CD(Owner'sManual)/

Card/EasySetupGuide

CAUTION

NOTE

ENG

ENGLISH

INSTALLATIONPREPARATION

MountingHoles

UseM3x4mmscrewstomountthemonitor.Thereare16screwholesontherearsideoftheproduct.

26TS30MF

<Frontsideoftheproduct>

<Rearsideoftheproduct>

ENG

ENGLISH

INSTALLATIONPREPARATION

UseM3x4mmscrewstomountthemonitor.Thereare20screwholesontherearsideoftheproduct.

47TS30MF

<Frontsideoftheproduct>

<Rearsideoftheproduct>

 Thisproducthasthefrontandbacksides.Makesuretheproductisinstalledwiththefrontsidefacing

forward.

 Imageisdisplayedreverselyonthebackside.

CAUTION

ENG

ENGLISH

INSTALLATIONPREPARATION

UnpackingandCabling

1 Liftupthecoverofthebox. 2 Removethetoppackaging.

3 Holdbothsidesoftheproductandliftitup.

5 Placeasoftclothonthetableandputthe

productdownwiththescreenfacingdownward.

4 Removethepolybag.

6 ConnecttheLVDScable(Additionalassembly

isrequired).AscalerboardorLVDScableis

optionalandnotprovidedwiththeproduct.

26TS30MF

ENG

ENGLISH

INSTALLATIONPREPARATION

1 Liftupthecoverofthebox. 2 Removethetoppackaging.

3 Holdbothsidesoftheproductandliftitup.

5 Placeasoftclothonthetableandputthe

productdownwiththescreenfacingdownward.

4 Removethepolybag.

6 ConnecttheLVDScable(Additionalassembly

isrequired).AscalerboardorLVDScableis

optionalandnotprovidedwiththeproduct.

47TS30MF

 Pleasereferto"LVDSPinMapGuide"onpages16to18fortheLVDScableassembly.

NOTE

ENG

ENGLISH

INSTALLATIONPREPARATION

PortraitLayout(Onlysupportedfor47TS30MF)

Toinstallinportraitmode,rotatethesetclockwise90degreeswhenlookingatfromthefront.

Theportraitmodeisonlyavailableonthescalerboard.(Thescalerboardshouldsupportportraitmode.)

 The26TS30MFmodelcannotberotated.

 Thescalerboardisoptionalanditisnotpartoftheproduct.

CAUTION

ENG

ENGLISH

INSTALLATIONPREPARATION

CorrectMethod IncorrectMethod

StorageMethodforPanelProtection

Panel

Cushion

Whenlayingdowntheproduct,placeacushionor

asoftclothonaflatfloor.Puttheproductdown

withthepaneloftheproductfacingdown.

Ifthereisnoacushionorasoftclothavailable,

ensurethefloorisclean.Thenlaytheproduct

downcarefullywiththepanelfacingeitherupward

ordownward.Atthistime,makesurethatno

objectfallsonthepanel.

Panel

Iftheproductistiltedontothebezel,thebottomof

thepanelmaybedamaged.

Iftheproductistiltedontotheedgeofthepanel,

thepanelmaybedamaged.

ENG

ENGLISH

PRODUCTINSTALLATION

Lightinginstallation

Thisproductmustbeinstalledwithlighting.

Lightingmustbeinstalledbehindtheproductsothatthedisplaycanbeseenclearly.

Installingacertainobjectbehindthescreenmayrequireadditionallighting.

Lighting 600luxormore

Additionallighting

Object
