Fax Guide

You can send a fax from the printer by typing the fax number, using a shortcut number, or using the address book.

Sending a fax using the printer control panel

1Load an original document faceup, short edge first into the ADF tray or facedown on the scanner glass.

Notes:

•Do not load postcards, photos, small items, transparencies, photo paper, or thin media (such as magazine clippings)

into the ADF tray. Place these items on the scanner glass.

•The ADF indicator light comes on when the paper is loaded properly.

2If you are loading a document into the ADF tray, then adjust the paper guides.

3From the home screen, touch Fax.

4Enter the fax number or a shortcut.

Note: To add recipients, touch Next number, and then enter the recipient's telephone number or shortcut number, or

search the address book.

5Touch Fax It.

Sending a fax using a shortcut number

Fax shortcuts are like the speed dial numbers on a telephone or fax machine. A shortcut number (1–99999) can contain a single

recipient or multiple recipients.

1Load an original document faceup, short edge first into the ADF tray or facedown on the scanner glass.

Notes:

•Do not load postcards, photos, small items, transparencies, photo paper, or thin media (such as magazine clippings)

into the ADF tray. Place these items on the scanner glass.

•The ADF indicator light comes on when the paper is loaded properly.

2If you are loading a document into the ADF tray, then adjust the paper guides.

3From the printer control panel, press #, and then enter the shortcut number using the keypad.

4Touch Fax It.

Sending a fax using the address book

The address book lets you search for bookmarks and network directory servers. For more information on enabling the address

book feature, contact your system support person.

1Load an original document faceup, short edge first into the ADF tray or facedown on the scanner glass.

Notes:

•Do not load postcards, photos, small items, transparencies, photo paper, or thin media (such as magazine clippings)

into the ADF tray. Place these items on the scanner glass.

•The ADF indicator light comes on when the paper is loaded properly.

2If you are loading a document into the ADF tray, then adjust the paper guides.

Fax Guide

Page 1 of 3

3From the home screen, navigate to:

Fax > > type the name of the recipient > Search

Note: You can search only for one name at a time.

4Touch the name of the recipient, and then touch Fax It.

Understanding the fax options

Content

This option lets you specify the content type and source of the original document.

Select from the following content types:

•Graphics—The original document is mostly business‑type graphics, such as pie charts, bar charts, and animations.

•Photo—The original document is mostly a photo or an image.

•Text—The content of the original document is mostly text or line art.

•Text/Photo—The original document is a mixture of text, graphics, and photos.

Select from the following content sources:

•Black/White Laser—The original document was printed using a mono laser printer.

•Color Laser—The original document was printed using a color laser printer.

•Inkjet—The original document was printed using an inkjet printer.

•Magazine—The original document is from a magazine.

•Newspaper—The original document is from a newspaper.

•Other—The original document was printed using an alternate or unknown printer.

•Photo/Film—The original document is a photo from film.

•Press—The original document was printed using a printing press.

Resolution

This option lets you adjust the quality of the fax output. Increasing the image resolution increases the file size and the time

needed to scan your original document. Decreasing the image resolution reduces the file size.

Select one of the following:

•Standard—Use this when faxing most documents.

•Fine 200 dpi—Use this when faxing documents with small prints.

•Super fine 300 dpi—Use this when faxing documents with fine details.

•Ultra fine 600 dpi—Use this when faxing documents with pictures or photos.

Darkness

This option lets you adjust how light or dark the faxes are in relation to the original document.

Delayed Send

This option lets you send a fax at a later time or date.

Fax Guide

Page 2 of 3

Page Setup

This option lets you change the following settings:

•Sides (Duplex)—This specifies if the original document is printed on one side or on both sides of the page (duplex). This also

identifies what needs to be scanned for inclusion in the fax.

•Orientation—This specifies the orientation of theoriginal document, and then changes the Sides (Duplex) and Binding settings

to match the orientation.

•Binding—This specifies if the original document is bound on the long‑edge or short‑edge side.

Scan Preview

This option lets you view the first page of the image before it is included in the fax. When the first page is scanned, the scanning

is paused and a preview image appears.

Note: This option appears only when a working printer hard disk is installed.

Using the advanced options

Select from the following settings:

•Advanced Imaging—This adjusts the Background Removal, Color Balance, Color Dropout, Contrast, Mirror Image, Negative

Image, Scan Edge to Edge, Shadow Detail, Sharpness, and Temperature settings before you fax the document.

•Custom Job—This combines multiple scanning jobs into a single job.

•Edge Erase—This removes smudges or marks around the edges of a document. You can choose to remove an equal area

around all four sides of the paper, or pick a particular edge. Edge Erase erases whatever is within the area selected, leaving

nothing on that portion of the scan.

•Transmission Log—This prints the transmission log or transmission error log.

•Multifeed Sensor—This detects when the ADF picks more than one sheet of paper at a time, and then shows an error message.

Note: This option is supported only in select printer models.

Fax Guide

Page 3 of 3
