Lexmark X945E Manuel

Lexmark X945e

Product Specifications

Part Number 21Z0221

Product Class Departmental Colour Laser MFP

Speed Black: Up to 45 ppm; Colour: Up to 40 ppm

Time to First Page Black: As fast as 5.2 seconds; Colour: As fast as 10 seconds

Resolution 2400 Image Quality

Processor 1.25GHz

Memory (std./max.) 512MB/1024MB

Connectivity

Standard

Optional Gigabit Ethernet, USB, USB Direct Interface, 1 Internal Solutions Port

Wireless, Fiber Optic, Parallel, Serial

Printer Languages PostScript 3 and PCL 6 emulations, PPDS Migration Tool

Direct Print Formats PDF v1.6 emulation, HTML Direct Image Space, .jpg, .tif, .gif, .bmp, .png, .pcx, .dcx

Fonts PCL 6: 89 scalable, includes OCR-A, OCR-B and Code 3 of 9 bar codes; 2 bitmapped; PostScript: 158 scalable;

PPDS: 39 scalable, 5 bitmapped

Operating Systems Windows, Linux, UNIX, Mac, NetWare and OS/400

Copy Reduce/enlarge (25-400%), paper saver (2-up and 4-up), collation, darkness adjustment, original size to output

size selection, copy select 1-999, date/time stamp, single-pass duplex, message overlay, priority copy (job interrupt

copy countdown

Fax Speed: 33.6 bps max.; transmission speed: approximately 3 seconds per page; resolution: 200 x 100 dpi, 200 x

200 dpi, 300 x 300 dpi, 400 x 400 dpi; fax redirect, group fax, manual fax, fax from PC, up to 512-character

shortcuts, fax preservation, LDAP lookup, Caller ID, speed dials, block junk faxes

Scan Output resolutions: up to 600 x 600 dpi black, up to 300 x 300 dpi color; scan destinations: Network TWAIN, USB

Direct Interface, e-mail, FTP, LDSS, Scan-to-PC; File Formats: TIFF, JPG, PDF; legal-size from flatbed; duplex scanning

Acoustics Printing: 52 dBA; Copying: 53 dBA; Scanning: 54 dBA; Idle: 34 dBA

Size (WxDxH) 660 mm x 810 mm x 1,153 mm (26 in. x 31.9 in. x 45.4 in.)

Weight 173.7 kg (383 lb.)

Duty Cycle2Maximum monthly duty cycle: Up to 200,000 pages per month

Recommended Monthly

Page Volume35,000 - 33,000 pages per month

Media Specifications

Paper Capacity (sheets)

Standard

Maximum

Input: 3,140 (3,040 + 100 MPF); Output: 400

Input: 3,140 (3,040 + 100 MPF); Output: 3,500 (500 + 3,000)

Paper Sources

Standard

Maximum

Input: 5; Output: 1

Input: 5; Output: 3

Media Information

Types

Size

Weight

Plain paper, paper labels, card stock, transparencies, envelopes

Letter, Legal, Tabloid, A4, A5, A3, JIS B5, JIS B4, Executive, Folio, Statement,

Universal (3.9 in. x 17 in. to 5.5 in. x 11.7 in.), envelopes (7 3/4, 10, DL, C5)

Plain paper: 17 to 28 lb. (60 to220 g/m2); Card stock: up to 110 lb. (220 g/m2)

Shipping Dimensions

Lexmark X945e MFP

740 mm x 925 mm x 1480

mm. 216.4 kg. (26.1 in. x

36.4 in. x 58.3 in.

476 lb).

In the Box

The Lexmark X945e MFP departmantal network colour multifunction solution includes print, colour copy, fax and scan

capabilities. The easy-to-use e-Task touch screen lets you easily automate document workflow processes.

X945e MFP

Lexmark X945e MFP

Lexmark X945e

• High Capacity Feeder

•

13,000-page Black Toner Cartridge

• 12,000-page Cyan, Magenta

and Yellow Toner Cartridges1

• 80+GB Hard Disk

• Photoconductor Kit

• Setup Sheets

• Software / Documentation CD

• Warranty Sheet

• Supplies Use and Return Flyer

• Phone cord

• Power Cord

Part Numbers

Supplies 36,000-page Black Toner Cartridge1X945X2KG

22,000-page Cyan Toner Cartridge1X945X2CG

22,000-page Magenta Toner Cartridge1X945X2MG

22,000-page Yellow Toner Cartridge1X945X2YG

Black Photoconductor Kit C930X72G

3-pack Colour Photoconductor Kit C930X73G

30,000-page Waste Toner Box C930X76G

Advanced Booklet Staples 21Z0357

Staple Cartridge, 3 pack 25A0013

Routine Maintenance Items

100,000-page Fuser Maintenance Kit 40X4031

600,000-page Tansfer Belt Maintenance Kit 40X4032

150,000-page ADF Maintenance Kit 40X4033

Memory Options 128MB SDRAM 13N1523

256MB SDRAM 13N1524

512MB SDRAM 13N1526

32MB Flash Card 1021208

64MB Flash Card 1021209

Warranty 1-year Next Business Day Onsite Repair Base

1-year Next Business Day Onsite Repair extended warranty 2349452

2-year Next Business Day Onsite Repair extended warranty 2349453

3-year Next Business Day Onsite Repair extended warranty 2349454

— 520-sheet Drawer

(standard)

— High Capacity Feeder

(standard)

100-sheet

Multipurpose

Feeder (standard)

Standard Finisher, —

3 hole (21Z0308)

Advanced Finisher,

3 hole (21Z0309)

1Average continuous black or continuous composite CMY declared cartridge yield up to this number of standard pages in accordance with ISO/IEC 19798.

2Duty Cycle is defined as the maximum number of pages a device could deliver in a month. This metric provides a comparison of

robustness in relation to other Lexmark printers and MFPs.

3 Recommended Monthly Page Volume is a range of pages that helps customers evaluate Lexmark’s product offerings based on the

average number of pages customers plan to print on the device each month. Lexmark recommends that the number of pages

per month be within the stated range for optimum device performance, based on factors including: supplies replacement inter-

vals, paper loading intervals, speed, and typical customer usage

Solutions Traditional Chinese Font Card 1021242

Simplified Chinese Font Card 1021241

Japanese Font Card 1021243

Korean Font Card 1021240

Bar Code Card and Forms Card 21Z0367

PrintCryptionTM Card 21Z0370

Card for IPDS and SCS/Tne 21Z0368

Connectivity Internal Print Servers1

MarkNet N8030 Fiber Ethernet 14S0220

MarkNet N8050 802.11g Wireless 14S0165

External Print Servers2

N4050e 802.11g Wireless 14T0145

Local Connections

RS-232C Serial Interface Card 1021092

Parallel 1284-B Interface Card 1021091

Cables 6-foot USB Cable 1021294

10-foot Parallel Cable 1021231

Media Glossy Paper (letter, 200 sheets) 12A5950

Professional Colour Laser Transparencies (letter, 50 sheets) 12A8240

Additional Part Numbers

Terms & Conditions

Lexmark, MarkNet and Lexmark with diamond design are trademarks of Lexmark

International, Inc., registered in the United States and/or other countries.

PrintCryption is a trademark of Lexmark International, Inc. PCL is a registered

trademark of Hewlett Packard Company.

All other trademarks

are the property of

1Use of Internal Print Server disables network card resident in printer.

2Requires USB Connection.
