Levoit Tower Pro True HEPA Manuel utilisateur

Tower Pro True HEPA Air Puriﬁer

Model: LV-H134

USER MANUAL

Questions or Concerns?

Please contact us at [email protected].

EN  DE  FR  ES  IT

Package Contents

Speciﬁcations

Safety Information

Getting to Know Your Air Puriﬁer

Controls

Getting Started

Using Your Air Puriﬁer

About the FIlter

Care & Maintenance

Troubleshooting

Warranty Information

Customer Support

Inhaltsverzeichnis

Table des matières

Índice

Indice

Table of Contents

EN  ENGLISH

ES  ESPAÑOL

IT  ITALIANODE  DEUTSCHE

FR  FRANÇAIS

Contenu de l’emballage

Caractéristiques techniques

Consignes de sécurité

Prise en main de votre puriﬁcateur d’air

Commandes

Prise en main

Utilisation de votre puriﬁcateur d’air

À propos du ﬁltre

Entretien et maintenance

Dépannage

Informations relatives à la garantie

Service client

Lieferumfang

Technische Daten

Sicherheitshinweise

Ihr Luftreiniger

Bedienungstasten

Erste Schritte

Der Gebrauch Ihres Luftreinigers

Informationen zum Filter

Pﬂege und Wartung

Problemlösung

Garantie

Kundendienst

Contenuto della confezione

Speciﬁche

Informazioni di sicurezza

Componenti del puriﬁcatore d’aria

Comandi

Avvio

Uso del puriﬁcatore d’aria

Il ﬁltro

Cura e manutenzione

Risoluzione dei problemi

Informazioni sulla garanzia

Assistenza Clienti

Contenido de la caja

Especiﬁcaciones

Información de seguridad

Componentes del puriﬁcador de aire

Controles

Primeros pasos

Usar el puriﬁcador de aire

El ﬁltro

Cuidado y mantenimiento

Solución de problemas

Información sobre la garantía

Atención al Cliente

Package Contents Speciﬁcations

× Air Puriﬁer

×3-Stage Filter (Pre-Installed)

×Power Cord

×User Manual

Power

Supply AC 220–240V, 50Hz

Rated Power 45W

Ideal Room

Size

110 m² / 1184 ft²

Note:

• Eective for larger

rooms, but puriﬁcation

will take longer.

• Ideal Room Size

is based on 2 air

changes per hour

(ACH).

Operating

Conditions

Temperature:

-10°–40°C / 14°–104°F

Humidity: ≤ 85% RH

Noise Level ≤ 54dB

CADR (Clean

Air Delivery

Rate)

530 m³/h / 312 CFM

Standby

Power < 0.5W

Air Puriﬁer

Dimensions

32.6 x 32.6 x 74.2 cm /

12.8 x 12.8 x 29.2 in

Air Puriﬁer

Weight 8.44 kg / 18.6 lb

ENGLISH

User Manual

Tower Pro True HEPA Air Puriﬁer

Model: LV-H134

• Only use your air puriﬁer as described

in this manual.

• Do not use your air puriﬁer outdoors.

• Keep your air puriﬁer away from water,

and wet or damp areas. Never place in

water or other liquids.

• Keep your air puriﬁer away from heat

sources.

• Do not use where combustible gases

or vapours, metallic dust, aerosol

(spray) products, or fumes from

industrial oil are present.

• Keep 1.5 m / 5 ft away from where

oxygen is being administered.

• Supervise children when they are near

the air puriﬁer.

• Do not place anything into any opening

on the air puriﬁer.

• Do not sit or place heavy objects on the

air puriﬁer.

• Keep the inside of the air puriﬁer dry. To

prevent moisture buildup, avoid placing in

rooms with major temperature changes.

• Always unplug your air puriﬁer before

servicing (for example, changing the ﬁlter).

• Do not use your air puriﬁer if it is

damaged or not working correctly, or if

the cord or plug is damaged. Do not try

to repair it yourself. Contact Customer

Support (see page 16).

• WARNING: To reduce the risk of ﬁre

or electric shock, do not use this air

puriﬁer with any solid-state speed

controls (such as a dimmer switch).

• Not for commercial use. Household

use only.

To reduce the risk of ﬁre, electric shock, or other injury, follow all instructions and

safety guidelines.

General Safety

• Keep the air puriﬁer near the outlet it is

plugged into.

• Never place the cord near any heat

source.

• Do not cover the cord with a rug,

carpet, or other covering. Do not place

the cord under furniture or appliances.

• Keep the cord out of areas where

people walk often. Place the cord

where it will not be tripped over.

Plug & Cord

Your Levoit air puriﬁer complies with all

standards regarding electromagnetic ﬁelds

(EMF). If handled properly and according

to the instructions in this user manual, the

appliance is safe to use based on scientiﬁc

evidence available today.

Electromagnetic Fields (EMF)

Safety Information

READ AND SAVE THESE INSTRUCTIONS

Getting to Know Your Air Puriﬁer

F. Dust Sensor

G. Filter

H. Power Cord Port

I. Filter Cover

A. LED Display / Control Panel

B. Air Outlet

C. Housing

D. Power Cord

E. Air Intake

(triangles at the bottom)

Front Back

G H

A. Fan Speed Button

B. Auto Mode Button

C. Sleep Mode Button

D. PM2.5 Value (µg/m³)

E. Display O Button

F. Check Filter Indicator

A G

B F

LED Display

GETTING TO KNOW YOUR AIR PURIFIER CONT.

G. Timer Button

H. Air Quality Indicator

I. On/O Button

J. Timer Display

K. Fan Speed Indicator

Controls

On/O Button

Turns the air puriﬁer on/o.

Fan Speed Indicator Chart

Fan Speed Fan Speed Indicator

Low

Medium

High

Fan Speed Button

Cycles through fan speeds: low, medium, and high.

Auto Mode Button

Turns Auto Mode on/o (see page 9).

Sleep Mode Button

Turns Sleep Mode on/o (see page 9).

Display O Button

• Turns the display o.

• Press any button (except ) to turn the display back on.

Check Filter Indicator

Lights up red to remind you to check the ﬁlter (see page 12).

Timer Button

Sets the timer (see page 10).

Figure 1.1

Figure 1.4

Figure 1.3

Figure 1.2

4. Push the cover securely closed.

[Figure 1.4]

5. Remove the “ATTENTION” notice that

covers the display on top of the air puriﬁer.

6. Attach the power cord to the port

underneath the ﬁlter cover at the bottom

of the air puriﬁer. [Figure 1.5]

Getting Started

1. Remove the ﬁlter cover. Pull the ﬁlter

from the housing. [Figure 1.1]

2. Take the ﬁlter out of its plastic

packaging, then reinstall it into the

housing. Make sure the handle on the

ﬁlter is facing out. [Figure 1.2]

3. Replace the ﬁlter cover by lining up the

cover’s feet with the matching slots on

the bottom of the housing. [Figure 1.3] Note: If you are not planning to use

the air puriﬁer for a long period of

time, keep the ﬁlter clean by leaving

it inside its plastic packaging until it

is ready to be used.

Figure 1.5

Auto Mode adjusts the fan speed

automatically based on air quality. For

example, if the air quality is bad, the fan will

be set to high speed.

• Tap to turn Auto Mode on/o.

• Tapping or will also exit Auto

Mode.

This indicator uses an automatic sensor to

display the air quality.

Auto Mode

Air Quality Indicator

Sleep Mode uses the lowest possible fan

speed to operate quietly.

• Tap to turn Sleep Mode on/o.

• Tapping or will also exit Sleep

Mode.

Sleep Mode

Air Quality Indicator Chart

Indicator

Colour Air Quality Fan Speed

Blue Very Good Sleep Mode

Green Good Low

Orange Moderate Medium

Red Bad High

Using Your Air Puriﬁer

1. Place the air puriﬁer on a level surface.

Leave 38 cm / 15 inches of clearance on

all sides of the air puriﬁer. [Figure 2.1]

2. Plug in. Tap to turn on the air

puriﬁer. The fan will start automatically.

3. Optionally, tap to change the fan

speed. You can also select Auto Mode

or Sleep Mode, or set a timer.

a. For best results, or to address a

speciﬁc air quality issue such as

smoke, run the air puriﬁer at high

speed for 15–20 minutes before

using a lower speed or Auto Mode.

b. To eectively clean air, keep

windows and doors closed while the

air puriﬁer is on.

4. Tap to turn o the air puriﬁer.

General Operation

Figure 2.1

38 cm / 15 in

USING YOUR AIR PURIFIER CONT.

The air puriﬁer will remember its

programmed settings when turned o,

and will resume these settings when it is

turned back on. The air puriﬁer must remain

plugged in for the memory function to work.

Memory Function

The PM2.5 value on the display shows the

amount of particles (µg) that are detected

within 1 cubic metre (m³).

PM2.5 refers to particulate matter (PM) that

is less than or equal to 2.5 micrometres

(µm) in diameter. These particles, also

known as “ﬁne particles”, are so small that

they can only be detected with an electron

microscope, and stay in the air longer than

heavier air particles such as dust and pollen.

Your air puriﬁer is equipped with a laser dust

sensor that detects the amount of PM2.5

particles that are in a given space (µg/m³).

Generally, the lower the number, the better

your air quality. A number above 135 indicates

that there is an unhealthy amount of ﬁne

particles in the air.

You can set a timer between 1– 12 hours.

1. Tap repeatedly (or press and

hold ) to set a time.

2. Once you choose a time, the timer will

ﬂash 5 times and start counting down.

3. The air puriﬁer will automatically turn o

once the timer is ﬁnished.

4. To cancel a timer, tap repeatedly

until the timer reads “- - - -”. The timer

will ﬂash 5 times to conﬁrm cancellation.

PM2.5 Value & Air Quality

Timer

Note:

• You can change the fan speed at

any time while the timer is counting

down. The timer will work with any

mode.

• Pressing or unplugging the air

puriﬁer will cancel the timer.

Note: The air puriﬁer will not

remember timers.

Autres manuels pour Tower Pro True HEPA

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Levoit Purificateur d'air

Levoit

Levoit Core LAP-C161-WAS Manuel utilisateur

Levoit

Levoit LV-H135-RWH Manuel utilisateur

Levoit

Levoit LV-PUR131 Manuel utilisateur

Levoit

Levoit Core 300 Manuel utilisateur

Levoit

Levoit Core 200S Manuel utilisateur

Levoit

Levoit LAP-C161-AUSW Manuel utilisateur

Levoit

Levoit Vital 100-RXW Manuel utilisateur

Levoit

Levoit Vital 100 Manuel utilisateur

Levoit

Levoit Tower Pro True Manuel utilisateur

Levoit

Levoit LV-H126 Manuel utilisateur

Levoit

Levoit Vital 100S Manuel utilisateur

Levoit

Levoit LV-H132 Manuel utilisateur

Levoit

Levoit Tower Pro True HEPA Manuel utilisateur

Levoit

Levoit Vital 100 Manuel utilisateur

Levoit

Levoit LV-H133 Manuel utilisateur

Levoit

Levoit LV-H132XR Manuel utilisateur

Levoit

Levoit LV-H134 Manuel utilisateur

Levoit

Levoit LV-PUR131 Manuel utilisateur

Levoit

Levoit Smart True HEPA Core 300S Series Manuel utilisateur

Levoit

Levoit Tower Pro True HEPA Manuel utilisateur

Levoit

Levoit Core 300 Manuel utilisateur

Levoit

Levoit Core LAP-C161-WUS Manuel utilisateur

Levoit

Levoit LV-H135 Manuel utilisateur

Levoit

Levoit Pet Care True HEPA Core P350 Manuel utilisateur

Manuels Purificateur d'air populaires d'autres marques

IKEA

IKEA UPPÅTVIND Manuel utilisateur

Nash

Nash AP-1 PureSmart Manuel utilisateur

LG PH-U450 Series Manuel utilisateur

DeLonghi

DeLonghi DDSX 220WFA Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manuel utilisateur

Sharp

Sharp FU-40SE Manuel utilisateur

Philips

Philips AC2721 Manuel utilisateur

Hitachi

Hitachi EP-A3000 Manuel utilisateur

TruSens

TruSens Z-2000 Manuel utilisateur

Motorola

Motorola MBP87SN Manuel utilisateur

Beko

Beko ATP 7100I Manuel utilisateur

Carrier

Carrier INFINITY 1620 Manuel utilisateur

AtmosAir

AtmosAir P2002 Manuel utilisateur

Winix

Winix NK300 Manuel utilisateur

Friedrich

Friedrich C-90A Instructions d'utilisation et d'installation

Surgically Clean Air

Surgically Clean Air JADE2.0 Manuel utilisateur

Base aire

Base aire 555 Pro Manuel utilisateur

Champion

Champion CP25 Manuel utilisateur
