Levoit LV-H126 Manuel utilisateur

Model No.: LV-H126

Personal HEPA Air Puriﬁer

ENGLISH  DEUTSCH

Questions or Concerns?

[email protected]

Package Contents

Speciﬁcations

Safety Information

Getting to Know Your Air Puriﬁer

·Filters

Getting Started

How to Use Your Air Puriﬁer

Keeping Things Clean

·General Cleaning

·When Should I Replace the Filters?

·Purchasing New Filters

·Replacing the Filters

·Filter Reminder Wheel

Troubleshooting

Warranty Information

Lieferumfang

Speziﬁkationen

Sicherheitsinformationen

Lernen Sie Ihren Luftreiniger Kennen

·Filter

Erster Schritt

Wie Sie Ihren Luftreiniger verwenden

Reinigung

·Allgemeine Reinigung

·Wann sollte ich die Filter austauschen?

·Neue Filter kaufen

·Filter austauschen

·Filter-Erinnerungsrad

Problembehandlung

Garantie

TABLE OF CONTENTS INHALTSVERZEICHNIS

English Deutsch

EN DE

SPECIFICATIONS

Power Supply AC 220-240V, 50/60Hz

Rated Power 35W

Eective Range 15 m² (161 ft²)

Weight 2.2 kg (4.8 lb)

Operating Conditions Temperature: -10C~40C

(14°F~104°F)

Noise Level ≤ 54dB

1 x Personal HEPA Air Puriﬁer

1 x Filter Set (Pre-Installed)

2 x Activated Carbon Pre-Filters (Additional)

1 x User Manual

PACKAGE CONTENTS

English

Personal HEPA Air Puriﬁer

Model No.: LV-H126

Français

Español

Italiano

SAFETY INFORMATION

To reduce the risk of ﬁre, electric shock, or injury, always follow the instructions and safety

guidelines in this manual.

IMPORTANT

General Safety

• Never place the cord near a source of heat (such as a

heater, stove, or radiator).

• Keep the cord out of areas where people walk often.

Place the cord where it will not be tripped over.

• Do not cover up the cord with a rug, carpet, or other

covering. Do not place the cord under furniture or another

appliance.

• Do not use your air puriﬁer if the cord or plug is damaged.

• Do not use an extension cord unless the air puriﬁer plug

can be fully inserted into the extension cord.

Power Cord Safety

• Only use your air puriﬁer as described in this manual.

• Do not use your air puriﬁer outdoors.

• Do not use your air puriﬁer near water. Never place your

air puriﬁer in water or liquid.

• Always supervise children when they are near the air

puriﬁer.

• Do not place any object into any opening on the air

puriﬁer.

• Do not use your air puriﬁer if it is damaged or not working

correctly (for example: if the motor fan will not rotate, if

the housing is broken, or if the cord or plug is damaged).

Do not try to repair it yourself. Doing so will void your

warranty. Please contact Customer Support (page 12)

immediately.

SAVE THESE INSTRUCTIONS

Front

Back

GETTING TO KNOW YOUR AIR PURIFIER

1. Housing

2. Front Cover

3. Air Outlet

4. Control Dial

5. Filter Reminder Wheel

6. Rear Cover / Air Inlet

7. Anti-Skid Pads

8. Power Cord

Your Levoit Personal HEPA Air Puriﬁer

uses a 3-stage air ﬁltration system.

1. Activated Carbon Pre-Filter

2. Advanced HEPA Filter

3. High-Eciency

Activated Carbon Filter

4. Pull Tabs (for easy removal)

Filters

GETTING STARTED

Figure 1.1

Figure 1.3

Figure 1.2

1. Carefully remove your air puriﬁer from the box and bag.

2. Remove the rear cover by pressing the top tab down.

[Figure 1.1] Then, lift o the rear cover.

3. Take the ﬁlters out of the puriﬁer. Remove the ﬁlters

from their plastic packaging.

4. Place the black pre-ﬁlter on top of the white HEPA ﬁlter.

Make sure the white pull tabs are folded over the pre-

ﬁlter.

5. Place the ﬁlters back into the air puriﬁer. The

pre-ﬁlter and pull tabs should be facing out.

[Figure 1.2]

6. Replace the rear cover.

a. Make sure the side with the ﬁlter reminder wheel

is facing out.

b. Insert the cover’s feet into the matching slots in

the back of the air puriﬁer. [Figure 1.3]

c. Press the rear cover into the housing until the

latch clicks.

7. Place your air puriﬁer on a ﬂat, stable surface, such as

a table.

NOTE:

• We recommend allowing 38 cm (15 inches) of clearance on all

sides of the puriﬁer. [Figure 1.4]

• Do not place anything on top of your air puriﬁer.

Figure 1.4

38 cm

pull tabs

facing out

HOW TO USE YOUR AIR PURIFIER

1. Plug the power cord into a powered electrical

outlet.

2. Turn on your air puriﬁer by turning the control dial.

[Figure 2.1]

3. Turn o your puriﬁer by turning the control dial to

“OFF”.

NOTE: Do not use your air puriﬁer with a dimmer switch (or

any other solid-state speed control device). This increases the

risk of ﬁre and electric shock.

Figure 2.1

Mode Speed

1Low

2Medium

3High

To maintain your health and product performance,

please only use ocial Levoit replacement ﬁlters. You

can purchase new air ﬁlters from Amazon.co.uk by

searching for “B07FVP6VKF”. You can also scan the

QR code.

For any questions, contact Customer Support (page

12).

Purchasing New Filters

KEEPING THINGS CLEAN

Wipe the surface of the air puriﬁer with a clean, dry,

soft cloth.

NOTE: Some cleaning products will damage the air puriﬁer.

Do not use alcohol or harsh cleaners.

Activated Carbon Pre-Filter

The activated carbon pre-ﬁlter should be replaced

every 2-3 months. Your air puriﬁer comes with 2 extra

pre-ﬁlters.

HEPA Filter

The HEPA ﬁlter (the main ﬁlter) should be replaced

every 6-8 months.

You may need to change your ﬁlters sooner or later

depending on how often you use your air puriﬁer.

Using your air puriﬁer in an environment with relatively

high pollution may mean you will need to change the

ﬁlters more often.

Watch out for the signs of expired ﬁlters:

• Increased noise when the air puriﬁer is on.

• Decreased airﬂow.

• Unusual odors coming from the air puriﬁer.

• Clogged ﬁlters. If the white HEPA ﬁlter has turned

gray, then the ﬁlters should be replaced.

NOTE: Do not wash and reuse ﬁlters. The ﬁlters cannot be

cleaned, only replaced.

When Should I Replace the Filters?

General Cleaning

1. Turn o and unplug your air puriﬁer.

2. Remove the rear cover (see Getting Started,

page 6).

3. Use the white pull tabs to take the old ﬁlters out

of the puriﬁer.

4. (Optional) Clean out any dust or hair inside the

puriﬁer using a vacuum hose (or a handheld

vacuum). Do not use water or other liquids to

clean the puriﬁer.

5. Remove the new ﬁlters from their packaging and

place them into the puriﬁer, with the pull tabs

facing out. The pre-ﬁlter and pull tabs should be

facing out. [Figure 3.1]

6. Replace the rear cover.

7. (Optional) Use the ﬁlter reminder wheel to track

your ﬁlter change.

Figure 3.1

You can use the ﬁlter reminder wheel to track when

you need to change your ﬁlters. Use a tool (such as

a small screwdriver) to turn the wheel. The wheel is

marked with the numbers 1-12.

2 Ways to Use the Filter Reminder Wheel:

• Method 1: When you start using the air puriﬁer,

turn the wheel to the number of the current

month (January is “1”, December is “12”), so you

can track how long the ﬁlter is used.

• Method 2: When you start using the air puriﬁer,

turn the wheel 6 months ahead as a reminder.

Example: If you replace the ﬁlters in February (the

2nd month on the calendar), you can turn the

wheel to “8” to remind you to replace your ﬁlters

again in August (the 8th month).

Replacing the Filters Filter Reminder Wheel

6 month

reminder

TROUBLESHOOTING

Problem Possible Solution

Air puriﬁer does not turn on, or shuts o

unexpectedly.

Make sure the puriﬁer is plugged into a powered electrical outlet.

Make sure the power outlet is working. Try plugging the cord into

another outlet.

Unplug the power cord, and check the cord to see if it is damaged.

If you ﬁnd damage, immediately stop using the puriﬁer and contact

Customer Support (page 12).

If the problem continues, stop using the puriﬁer and contact

Customer Support (page 12).

Airﬂow is reduced signiﬁcantly. Make sure the ﬁlters are removed from their packaging.

The fan speed may be too low. Turn the control dial to the 2 or 3

setting.

The ﬁlters may be dirty. Check to see if the ﬁlters need to be

replaced (see When Should I Replace the Filters?, page 8).

Make sure there is at least 38 cm (15 inches) of clearance on all sides

of the puriﬁer.

If the airﬂow is still too low, contact Customer Support (page 12).

Air puriﬁer makes an unusual noise while

turned on.

Make sure the ﬁlters are properly in place (see Getting Started,

page 6).

The puriﬁer may be defective or damaged. Immediately stop using

the air puriﬁer and contact Customer Support (page 12).

DO NOT try to open the puriﬁer housing.
