Levoit LV-H133 Manuel utilisateur

Tower True HEPA Air Puriﬁer

Model: LV-H133/LV-H133-RWH/LV-H133-RBK

Questions or Concerns?

If you have any questions or concerns, please reach out to us at

[email protected]. We hope you enjoy your new air puriﬁer!

USER MANUAL

EN DE ES ITFR

Package Contents

Speciﬁcations

Safety Information

Getting to Know Your Air Puriﬁer

Controls

Getting Started

Using Your Air Puriﬁer

About the Filter

Care & Maintenance

Troubleshooting

Warranty Information

Customer Support

Table of Contents

EN  ENGLISH

ES  ESPAÑOL

IT  ITALIANO

DE  DEUTSCH

FR  FRANÇAIS

Inhaltsverzeichnis

Lieferumfang

Technische Daten

Sicherheitshinweise

Ihr Luftreiniger

Bedienungstasten

Erste Schritte

Der Gebrauch Ihres Luftreinigers

Der Filter

Pﬂege und Wartung

Problemlösung

Garantie

Kundendienst

Índice

Contenido de la caja

Especiﬁcaciones

Información de seguridad

Componentes del puriﬁcador de aire

Controles

Primeros pasos

Usar su puriﬁcador de aire

El ﬁltro

Cuidado y mantenimiento

Solución de problemas

Información sobre la garantía

Atención al Cliente

Table des matières

Contenu de l’emballage

Caractéristiques techniques

Consignes de sécurité

Prise en main de votre

puriﬁcateur d’air

Commandes

Prise en main

Utilisation de votre puriﬁcateur d’air

À propos du ﬁltre

Entretien et maintenance

Dépannage

Informations relatives à la garantie

Service client

Indice

Contenuto della confezione

Speciﬁche

Informazioni di sicurezza

Componenti del puriﬁcatore d’aria

Comandi

Preparazione

Uso del puriﬁcatore d’aria

Il ﬁltro

Cura e manutenzione

Risoluzione dei problemi

Informazioni sulla garanzia

Assistenza Clienti

Package Contents

xAir Puriﬁer

xTrue HEPA Combination Filter

(Pre-Installed)

xUser Manual

Specifications

Power Supply AC 220-240V, 50/60Hz

Rated Power 33W

Ideal Room

Size

83 m² / 893 ft²

Note: Eective for

larger rooms, but

puriﬁcation will take

longer.

Operating

Conditions

Temperature:

-10°–40°C / 14°–104°F

Humidity: ≤ 85% RH

Noise Level 25–50dB

CADR (Clean

Air Delivery

Rate)

400 m³/h / 235 CFM

Standby

Power

< 0.5W

Dimensions 31.8 x 31.8 x 60 cm /

12.5 x 12.5 x 23.6 in

Weight 6.75 kg / 14.9 lb

SAFETY INFORMATION

• Only use your air puriﬁer as

described in this manual.

• Do not use your air puriﬁer

outdoors.

• Keep your air puriﬁer away from

water, and wet or damp areas.

Never place in water or other

liquids.

• Keep your air puriﬁer away from

heat sources.

• Do not use where combustible

gases, vapours, metallic dust,

aerosol (spray) products, or fumes

from industrial oil are present.

• Keep 1.5 m / 5 ft away from where

oxygen is being administered.

• Supervise children when they are

near the air puriﬁer.

• Do not place anything into any

opening on the air puriﬁer.

• Do not sit or place heavy objects

on the air puriﬁer.

• Keep the inside of the air puriﬁer

dry. To prevent moisture buildup,

avoid placing in rooms with major

temperature changes.

• Always unplug your air puriﬁer

before servicing (for example,

changing the ﬁlter).

• Do not use your air puriﬁer if it is

damaged or not working correctly,

or if the cord or plug is damaged.

Do not try to repair it yourself.

Contact Customer Support (see

15).

To reduce the risk of ﬁre, electric shock, or other injury, follow all instructions and

safety guidelines.

General Safety

• Keep the air puriﬁer near the outlet

it is plugged into.

• Never place the cord near any heat

source.

• Do not cover the cord with a rug,

carpet, or other covering. Do not

place the cord under furniture or

appliances.

• Keep the cord out of areas where

people walk often. Place the cord

where it will not be tripped over.

Plug & Cord

READ AND SAVE THESE

INSTRUCTIONS

• WARNING: To reduce the risk of

ﬁre or electric shock, do not use

this air puriﬁer with solid-state

speed controls (such as a dimmer

switch).

• Not for commercial use. Household

use only.

GETTING TO KNOW YOUR AIR PURIFIER

A. LED Display / Control Panel

B. Air Outlet

C. Housing

D. Power Cord

E. Air Intake

(triangles at the bottom)

Front Back

H I

Function Diagram

A. Fan Speed Button

B. Auto Mode Button

C. Sleep Mode Button

D. Display O Button

E. Check Filter Indicator

F. Timer Button

G. On/O Button

H. Air Quality Indicator

I. Timer Display

J. Fan Speed Indicator

LED Display

F. Air Quality Sensor

G. Air Quality Sensor Cover

H. Filter

I. Filter Cover

CONTROLS

On/O Button

Turns the air puriﬁer on/o.

Fan Speed Button

Cycles through fan speeds:

low, medium, and high.

Auto Mode Button

Turns Auto Mode on/o

(see 8).

Sleep Mode Button

Turns Sleep Mode on/o (see

9).

Display O Button

• Turns the display o.

• Press any button (except

) to turn the display

back on.

Check Filter Indicator

Lights up red to remind you to

check the ﬁlter (see 1110).

Timer Button

Sets the timer (see 9).

Fan Speed

Indicator Fan Speed

Low

Medium

High

GETTING STARTED

1. Remove the ﬁlter cover. Pull the ﬁlter

from the housing. [Figure 1.1]

2. Take the ﬁlter out of its plastic

packaging, then reinstall it into the

housing. Make sure the pull tabs on the

ﬁlter are facing out. [Figure 1.2]

3. Replace the ﬁlter cover by lining up the

cover’s feet with the slots in the bottom

of the housing. [Figure 1.3]

4. Push the cover securely closed.

[Figure 1.4]

Note:

• If you are not planning to use the air

puriﬁer for a long period of time, keep

the ﬁlter clean by leaving it inside its

plastic packaging until it is ready to be

used.

Figure 1.1

Figure 1.4

Figure 1.2

Figure 1.3

Figure 2.1

Figure 2.2

USING YOUR AIR PURIFIER

1. Place the air puriﬁer on a level surface.

[Figure 2.1] Leave 38 cm / 15 inches of

clearance on all sides of the puriﬁer.

[Figure 2.2]

2. Plug in. Tap to turn on the air

puriﬁer. The fan will start automatically.

3. Optionally, tap to change fan

speed. You can also select Auto Mode

or Sleep Mode, or set a timer.

a. For best results, or to address a

speciﬁc air quality issue such as

smoke, run the air puriﬁer at high

speed for 15–20 minutes before

using a lower speed or Auto Mode.

b. To eectively clean air, keep

windows and doors closed while

the air puriﬁer is on.

4. Tap to turn o the air puriﬁer.

Auto Mode adjusts the fan speed

automatically based on air quality. For

example, if the air quality is bad, the fan will

be set to high speed.

• Tap to turn Auto Mode on/o.

• Tapping or will also exit Auto

Mode.

General Operation

Auto Mode

15 in /

38 cm

Air Quality Indicator Chart

Indicator

Colour Air Quality Fan Speed

Blue Very Good Sleep Mode

Green Good Low

Orange Moderate Medium

Red Bad High

This indicator uses an automatic sensor to

display the air quality. This sensor uses an

infrared light to detect airborne particles

The air puriﬁer will take 30 seconds to

detect the air quality each time it is turned

on. During this time, the air quality indicator

colour will be blue. After 30 seconds, the air

quality indicator colour will change based

on the detected air quality.

Air Quality Indicator

Note:

• You can change the fan speed at any

time while the timer is counting down.

The timer will work with any mode.

• Pressing or unplugging the air

puriﬁer will cancel the timer.

Note: The air puriﬁer will not remember

timers.

USING YOUR AIR PURIFIER CONT.

Sleep Mode Memory Function

Timer

1. Tap repeatedly (or press and hold

) to set a time.

2. Once you choose a time, the timer will

ﬂash 5 times and start counting down.

3. The air puriﬁer will automatically power

o once the timer is ﬁnished.

4. To cancel a timer, tap repeatedly

until the timer reads “- - - -”. The timer

will ﬂash 5 times to conﬁrm cancellation.

Sleep Mode uses the lowest possible fan

speed to operate quietly.

• Tap to turn Sleep Mode on/o.

• Tapping or will also exit Sleep

Mode.

You can set a timer between 1–12 hours.

The air puriﬁer will remember its

programmed settings while turned o and

resume those settings when turned back

on. The air puriﬁer must remain plugged in

for the memory function to work.

ABOUT THE FILTER

A. Nylon Pre-Filter

• Captures large particles such as

dust, lint, ﬁbres, hair, and pet fur.

• Maximises the life of the True

HEPA Filter by protecting it.

B. H13 True HEPA Filter

• Removes at least 99.97% of

airborne particles 0.3 micrometres

(µm) in diameter.

• Filters small particles such as

mould spores, ﬁne dust, smoke

particles, and allergens such as

pollen, dust mites, and pet dander.

C. High-Eciency Activated Carbon Filter

• Physically adsorbs smoke,

odours, and fumes.

• Filters compounds such as

formaldehyde, benzene,

ammonia, hydrogen sulphide,

and volatile organic compounds

(VOCs).

The True HEPA Combination Filter uses a 3-stage ﬁltration system to purify air.

Autres manuels pour LV-H133

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Levoit Purificateur d'air

Levoit

Levoit Pet Care True HEPA Core P350 Manuel utilisateur

Levoit

Levoit LV-H126 Manuel utilisateur

Levoit

Levoit LV-PUR131 Manuel utilisateur

Levoit

Levoit VeSync Core Pro 400S Manuel utilisateur

Levoit

Levoit Core 200S Manuel utilisateur

Levoit

Levoit True HEPA Core 300-RAC Manuel utilisateur

Levoit

Levoit Tower Pro True HEPA Manuel utilisateur

Levoit

Levoit Classic 300S Manuel utilisateur

Levoit

Levoit LV-H133 Manuel utilisateur

Levoit

Levoit Tower Pro True HEPA Manuel utilisateur

Levoit

Levoit Pet Care True HEPA Core P350 Manuel utilisateur

Levoit

Levoit Core 200S Manuel utilisateur

Levoit

Levoit Vital 100 Manuel utilisateur

Levoit

Levoit Core P350-RAC Manuel utilisateur

Levoit

Levoit PlasmaPro 600S Manuel utilisateur

Levoit

Levoit Tower Pro True Manuel utilisateur

Levoit

Levoit Core 300 Manuel utilisateur

Levoit

Levoit LV-PUR131S Manuel utilisateur

Levoit

Levoit LV-H132 Manuel utilisateur

Levoit

Levoit Core 300 Manuel utilisateur

Levoit

Levoit Core 200S Manuel utilisateur

Levoit

Levoit Vital 100 Manuel utilisateur

Levoit

Levoit Vista 200-RXW Manuel utilisateur

Levoit

Levoit Vital 100 Manuel utilisateur

Manuels Purificateur d'air populaires d'autres marques

IKEA

IKEA UPPÅTVIND Manuel utilisateur

Nash

Nash AP-1 PureSmart Manuel utilisateur

LG PH-U450 Series Manuel utilisateur

DeLonghi

DeLonghi DDSX 220WFA Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manuel utilisateur

Sharp

Sharp FU-40SE Manuel utilisateur

Philips

Philips AC2721 Manuel utilisateur

Hitachi

Hitachi EP-A3000 Manuel utilisateur

TruSens

TruSens Z-2000 Manuel utilisateur

Motorola

Motorola MBP87SN Manuel utilisateur

Beko

Beko ATP 7100I Manuel utilisateur

Carrier

Carrier INFINITY 1620 Manuel utilisateur

AtmosAir

AtmosAir P2002 Manuel utilisateur

Winix

Winix NK300 Manuel utilisateur

Friedrich

Friedrich C-90A Instructions d'utilisation et d'installation

Surgically Clean Air

Surgically Clean Air JADE2.0 Manuel utilisateur

Base aire

Base aire 555 Pro Manuel utilisateur

Champion

Champion CP25 Manuel utilisateur
