LevelOne

WGR-6013

300Mbps Wireless Gigabit Router

Quick Installation Guide

Default Settings

IP Address 192.168.1.1

Password admin

Wireless Mode Enable

Wireless SSID LevelOne

Security None

This Quick Installation Guide only describes the most basic

situations and settings. All detailed information is described in the

user manual.

Package Contents

•WGR-6013

•Power Adapter

•RJ-45 Cable

•CD-ROM with Manual and QIG

•Quick Installation Guide

•Antenna x2 (for detachable only)

If any of the above items are missing, please contact your retailer

or distributor.

(Figure 1)

Reset Status LED WAN LED WiFi LED LAN LED WPS/Wiless On

Other LED indicator:

LED status Description

Status Green in flash Device status is working.

WAN LED Green RJ45 cable is plugged

Green in flash Data access

LAN LED Green RJ45 cable is plugged

Green in flash Data access

WiFi LED

Green WLAN is on

Green in flash Data access

Green in fast flash Device is in WPS PBC mode

Green in dark Wi-Fi Radio is disabled

Power JACK

WAN PORT

LAN PORT

(Figure 2)

(Figure 3)

(Figure 4)

(Figure 5)

Installation (Figure 1)

1. Please connect the WGR-6013 to the RJ-45 Ethernet Port of

your PC. Then Power-On the WGR-6013.

2. Installation is now completed. You can now begin to

configure the device.

Check Your Network Settings to login web UI (Figure 2)

1. Please make sure your PC can get IP address automatically,

so the router can communicate with your PC during

configuration.

Select “Control Panel” > “Network Connections”.

Right click the “Local Area Connection” and choose

“Properties”.

Select the TCP/IP protocol for your network card.

Click on the Properties button. You should then see the

following screen and make sure you have selected “Obtain

IP address automatically”

Before you begin, please have your ISP‟s username and

password details ready.

English

Configuration

1. Start your WEB browser (Internet Explorer recommended).

In the Address box, enter the following:

http://192.168.1.1 (Figure 3)

2. When prompted, use the following password.

Password: admin (Figure 4)

3. The first time you connect to the WGR-6013, you should run

the Setup Wizard to configure the Internet Connection.

Select Wizard and click Next.(Figure 5)

This wizard will guide you through the setup in 5 easy steps.

Note: For effective wireless security, LevelOne recommends

WPA2-PSK encryption methods.
