LevelOne KVM-0260 Manuel utilisateur

Ver. 1.0.0-0803

KVM-0260

2-Port DVI USB KVM Switch

LevelOne

User Manual

English

Package Contents

1. KVM-0260

2. User Manual

3. Quick Installation Guide

Requirements

Console

• A DVI monitor capable of the highest resolution that you will be using on any computer in

the installation

• A USB keyboard and a USB mouse

• Speakers and microphone (optional)

Computers

The following equipment must be installed on each computer that is to be connected to the

system:

• A DVI video port

• A USB port for the keyboard, a USB port for the mouse, and a USB host controller

• Speaker and microphone ports (optional)

Installation

Make sure power to all computers being installed has been turned OFF.

1. Plug your keyboard, monitor, mouse, microphone and speakers into the appropriate

connectors at the end of the console cable. The ports are color coded and labeled with an

identifying icon.

Plug the keyboard in before plugging in the mouse. When using a

wireless composite keyboard and mouse, its USB cable must plug

into the KVM-0260’s keyboard port for the Hotkeys to function.

The mouse connector (black) is actually a USB port, and can accept

any USB compatible peripheral. You can even connect a hub to install

multiple USB devices.

2. Plug the keyboard, monitor, mouse, microphone, and speaker connectors of the KVM

cables into their respective ports on the computers you are installing.

3. Turn on the power to the computers.

Note: By default the KVM links to the first computer that is turned on.

Operation

Hotkey Port Selection

All hotkey port switches begin with tapping the Scroll Lock key twice.

[Scroll Lock] [Scroll Lock] [Enter]

Port Selection

Select port by tapping the Scroll Lock key twice. The tables below describe the actions that

each hotkey operation performs.

The default hotkey invocation key is the Scroll Lock key, but you can

choose the Ctrl key instead.

Do not switch ports while a USB device (printer, external drive, etc.) is

in process. Switching ports will terminate the operation.

Hotkey Summary Table

Hotkey Action

[Scroll Lock] [Scroll Lock] [Enter] Toggles the KVM and Audio focus between

the two ports.

Note: If the KVM and Audio focus are on

different ports, only the KVM focus switches.

[Scroll Lock] [Scroll Lock] [k] [Enter] Only toggles the KVM focus.

[Scroll Lock] [Scroll Lock] [s] [Enter] Only toggles the audio focus.

[Scroll Lock] [Scroll Lock] [a] [Enter] [n] Starts Auto Scan. The KVM focus cycles from

port to port at n second intervals.

Note: The n stands for the number of

seconds that the focus dwells on a port

before switching to the other one.

Replace the n with a number between 1 and

4 when entering this hotkey combination.

(See the table, below.)

[Scroll Lock] [Scroll Lock] [x] [Enter]

Toggles the hotkey invocation key between

the [Scroll Lock] key and the [Ctrl] key.

Scan Interval Table

n Secs.

1 3 secs.

2 5 secs. (Default)

3 10 secs.

4 20 secs.

Specifications

Function KVM-0260

Computer Connections 2

Port Selection Hotkey

Keyboard 1 x USB Type A Female (Purple)

Video 1 x DVI Male (Black)

Mouse 1 x USB Type A Female (Black)

Speaker 1 x Mini Stereo Jack Female (Green)

Console

Ports

Microphone 1 x Mini Stereo Jack Female (Pink)

Keyboard 2 x USB Type A Male (Purple)

Video 2 x DVI Male (Black)

Mouse 2x USB Type A Male (Black)

Speaker 2 x Mini Stereo Plug Male (Green)

Connectors

KVM

Ports

Microphone 2 x Mini Stereo Plug Male (Pink)

KB/Mouse 0.15m

Console Video 1.2m

Cable

Length Computers 0.6m, 1.2m

Emulation Keyboard/Mouse USB

Video 1920 x 1200@60Hz; DDC2B

Scan Interval 3, 5, 10, 20 Seconds

Operating Temp. 0-50°C

Storage Temp. -20-60°C

Environment

Humidity 0-80% RH, Non-condensing

Housing Plastic

Weight 0.62 kg

Physical

Properties

Dimensions (L x W x H) 10.9 x 3.8 x 2.2 cm

PC-MAC Keyboard Mapping

The PC Compatible (101/104 key) keyboard can emulate the functions of the Mac keyboard.

The emulation mappings are listed in the table below.

When using key combinations, press and release the first key (Ctrl or

Alt), then press and release the activation key.

PS/2 Mac Keyboard

[Shift] Shift

[Ctrl] Ctrl

[Win]

[Ctrl] [1]

[Ctrl] [2]

[Ctrl] [3]

[Ctrl] [4]

[Alt] L Alt/Option

[Prt_Sc] F13

[Scroll Lock] F14

[Desktop Menu] =

[Enter] Return

[Back Space] Delete

[Ins] Help

[Ctrl] [Win] F15

Troubleshooting:

Q: New Keyboard Functions Not Working?

A: You plugged in a new keyboard while the computers were running, so the operating

system failed to initialize the new keyboard functions. Restart the computers so that

the operating system can recognize the new functions.

Q: Why does the KVM auto-switch to a computer that is turned off?

A: The KVM recognizes computers based on power from USB. Some motherboards still

supply power to the USB even though the computer is turned off, causing the KVM to

mistakenly auto-switch to it. To remedy this problem, unplug the USB of the computer

that it is turned off.

Q: Why does it take so long to exit auto-scanning after pressing ESC?

A: Different keyboards transmit their keystroke inputs. We have found that the response

from some keyboards will be slower.

Q: Why is my USB 2.0 hub or device recognized as a USB 1.x?

A: The USB connector on the KVM acts only as a pass-through cable. So USB 2.0

compatibility will depend on the source of the USB (motherboard or adapter)

Q: Why DVI KVM Switch cannot detect VGA signal?

A: Although the DVI KVM Switch is using DVI-I connector, but the hardware itself cannot

recognize the analog signal from VGA device. So using the VGA to DVI connector

cannot help DVI KVM Switch to detect VGA device. DVI KVM Switch can only accept

digital signal from device with DVI connector.
