LevelOne FSW-0809 Manuel utilisateur

LevelOne

FSW-0809

4+4 PoE Fast Ethernet Switch

User Manual

v1.0 - 0706

Safety

FCC Warning

This equipment has been tested and found to comply with

the regulations for a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when

the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in

accordance with this user’s guide, may cause harmful

interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful

interference, in which case the user will be required to

correct the interference at his or her own expense.

CE Mark Warning

This is a Class B product. In a domestic environment, this

product may cause radio interference, in which case the

user may be required to take adequate measures.

Table of Content

INTRODUCTION ..............................................1

FEATURES.......................................................2

PACKAGE CONTENT .....................................3

HARDWARE DESCRIPTION...........................4

FRONT PANEL .................................................4

REAR PANEL...................................................4

LED INDICATORS.............................................6

System Power............................................6

PoE status (Port 1 ~ Port 4) ......................6

PoE MAX...................................................7

Ethernet port status (Ports 1~8)................7

POE RULE........................................................8

INSTALLATION..............................................10

TECHNICAL SPECIFICATIONS....................11

iii

Introduction

The FSW-0809 Switch integrates 100Mbps

Fast Ethernet and 10Mbps Ethernet network

capabilities in a highly flexible package. And

this switch’s Port-1 to Port-4 are Power over

Ethernet (PoE) ports, and it will automatically

detects the presence of IEEE 802.3af-compliant

powered device (PD) and provides power

through the Port-1 to Port-4. The switch

provides up to 15.4 W for PoE port and can be

used to WLAN access point, IP phone, video

camera and other PD devices. The Switch will

automatically detect the network appliance’s

requirements, and the switch will supplies the

required power current to each appliance.

Purpose

Power over Ethernet (PoE) integrates power

and data onto one single cabling infrastructure,

eliminating the need to have AC power

available at all locations. PoE is already widely

adopted in the market, saving up to 50% of

overall installation costs by eliminating the need

to install separate electrical wiring and power

outlets.

Features

8 ×10/100Mbps Auto-negotiation Fast

Ethernet RJ45 ports with 4-port PoE

function (port-1 ~ port-4)

Compliant with 802.3af specification

Supports PoE power up to 15.4W for PoE

port

Supports PoE power up to 30W for all PoE

ports

Supports PoE Powered Device (PD)

classification identify

Each port supports auto MDI/MDIX, so

there is no need to use cross-over cables or

an up-link port

Full/half duplex transfer mode for each port

Wire speed reception and transmission

Up to 1K unicast addresses entities per

device, self-learning, and table aging

96KBytes packet buffer

Supports IEEE 802.3x flow control for full-

duplex mode ports

Supports Back-pressure flow control for

half-duplex mode ports

Package Content

Open the shipping cartons of the Switch and

carefully unpacks its contents. The carton

should contain the following items:

– FSW-0809

– AC power adapter (Output: DC48V, 0.8A)

– Four rubber feet

– User Manual

If any item is found missing or damaged, please

contact your local reseller for replacement.

Hardware Description

This chapter describes the front panel, rear

panel, and LED indicators of the Switch.

Front Panel

LED Indicator:

Comprehensive LED indicators display the

status of the switch and the network (see the

LED Indicators chapter below).

Rear Panel

PoE Ports (Port 1~4):

These ports are PoE Enabled ports, the PoE

port will automatically activated when a

compatible terminal is identified, the Switch will

supply power through the Ethernet port to the

connected PoE device.

Note: The PoE ports will not offer the power to

the Legacy devices.

Ethernet Ports (Port 5~8):

These ports support network speeds of either

10Mbps or 100Mbps, and can operate in half-

and full- duplex transfer modes. These ports

also supports automatic MDI/MDIX crossover

detection function gives true “plug and play”

capability, just need to plug-in the network

cable to the hub directly and don’t care if the

end node is NIC (Network Interface Card) or

switch and hub

DC Power Jack:

Power is supplied through an external DC

power adapter. Check the technical

specification section for information about the

DC power input voltage.

Since the switch does not include a power

switch, plugging its power adapter into a power

outlet will immediately power it on.

LED Indicators

The front panel LEDs provides instant status

feedback, and, helps monitor and troubleshoot

when needed.

System Power

On :

When the Power LED lights on, the Switch

is receiving power.

Off :

When the Power turns off or the power cord

has improper connection.

PoE status (Port 1 ~ Port 4)

Green :

When the PoE powered device (PD) was

connected and the port supplies power

successfully.

Yellow :

When the PoE port have the following

failure happens:

PoE power circuit shortage

Power over current: over the power

current of PD’s classification

Out of PoE voltage of 44 ~ 57 VDC

output

Off : No PoE powered device (PD) connected.
