LevelOne FNS-7000B Manuel utilisateur

FNS-7000B

4-Bay Tower SATA NAS w/ 2-Port Gigabit Ethernet

User Manual

Ver1.00-0603

LIMITED WARRANTY

In no event shall the liability of Digital Data Communication Co., Ltd. (LevelOne) exceed

the price paid for the product from direct, indirect, special, incidental, or consequential

software, or its documentation. LevelOne offers no refunds for its products. LevelOne

makes no warranty or representation, expressed, implied, or statutory, with respect to

its products or the contents or use of this documentation and all accompanying software,

and specifically disclaims its quality, performance, merchantability, or fitness for any

particular purpose. LevelOne reserves the right to revise or update its products, software,

or documentation without obligation to notify any individual or entity.

CAUTION

1Back up your system periodically to avoid any potential data loss. LevelOne

disclaims any responsibility of all sorts of data loss or recovery.

2Should you return any components of FNS-7000B Turbo Server package for

refund or maintenance, make sure they are carefully packed for shipping. Any form of

damages due to improper packaging will not be compensated.

Table of Contents

Chapter 1 Overview..............................................................................6

1.1 Introduction....................................................................................6

1.2 Package Contents ............................................................................6

1.3 System Overview.............................................................................7

Chapter 2 Installation ..........................................................................8

2.1 Install Hard Disk..............................................................................8

2.2 Hard Disk Recommendation List ...................................................... 12

2.3 Connect FNS-7000B to Office Network ............................................. 13Chapter

3 LCD Panel Control ..............................................................15Chapter 4 Quick

Install Wizard...........................................................19Chapter 5 Use

Services.......................................................................27

5.1 File Server....................................................................................27

5.2 FTP Server.................................................................................... 27

5.3 Backup Server............................................................................... 28

5.4 Network Printer Service.................................................................. 28

Chapter 6 Administer .........................................................................29

6.1 Access Administration Page............................................................. 30

6.2 Server Administration .................................................................... 32

6.3 Quick Configuration

........................................................33

6.4 System Settings

............................................................39

6.4.1 Server Name............................................................................ 39

6.4.2 Date & Time............................................................................. 40

6.4.3 Language Setting ..................................................................... 42

6.4.4 View System Settings ............................................................... 42

6.5 Network Settings

..........................................................

.43

6.5.1 TCP/ IP Configuration................................................................ 43

6.5.2 Microsoft Networking ................................................................ 49

6.5.3 Apple Network.......................................................................... 51

6.5.4 Linux (NFS) Service .................................................................. 51

6.5.5 Web Service............................................................................. 52

6.5.6 FTP Service.............................................................................. 52

6.5.7 Network Printer Service............................................................. 53

6.5.8 View Network Settings .............................................................. 56

6.6 Disk Configuration

..........................................................

6.6.1 Create Disk Volume .................................................................. 58

6.6.2 Delete Disk Volume................................................................... 60

6.6.3 Examine Disk Volume................................................................ 61

6.6.4 Format Disk Volume.................................................................. 62

6.6.5 View Disk& VolumeStatus........................................................62

6.7 User Management

..........................................................

6.7.1 Users ...................................................................................... 63

6.7.2 User Groups............................................................................. 65

6.7.3 Quota ..................................................................................... 70

6.8 Network Share Management ............................................ 72

6.8.1 Create..................................................................................... 73

6.8.2 Property..................................................................................74

6.8.3 Access Control ......................................................................... 74

6.8.4 Delete.....................................................................................75

6.9 System Tools

................................................................

.76

6.9.1 SNMP Settings ......................................................................... 76

6.9.2 Alert Notification....................................................................... 77

6.9.3 Restart/ Shutdown.................................................................... 77

6.9.4 Hardware Settings....................................................................78

6.9.5 UPS ........................................................................................ 79

6.9.6 System Update......................................................................... 81

6.9.7 Change Logo............................................................................ 83

6.9.8 Remote Replication...................................................................84

6.9.10 Backup/ Restore/ Reset Settings ................................................ 91

6.9.11 USB CD/ DVD Backup/ Restore................................................... 92

6.10 Statistics & Logs

........................................................

....96

6.10.1 Active Users............................................................................. 96

6.10.2 Event Logs............................................................................... 96

6.10.3 DHCP Logs............................................................................... 96

Chapter 7 Access FNS-7000B..............................................................97

7.1 By Microsoft Windows .................................................................... 97

7.2 By Apple MAC OS .......................................................................... 99

7.3 By Linux OS................................................................................ 105

7.4 By Web Browser.......................................................................... 105

7.5 By File Transfer Protocol (FTP)....................................................... 106

Chapter 8 Maintenance.....................................................................109

9.1 Restart/ Shut down Server............................................................ 109

9.2 Reset Administrator Password and Network Settings........................ 110

5.1 Disk Failure or Malfunction............................................................ 111

5.2 Power Outage or Abnormal Shutdown ............................................

111Appendix A Web File

Manager.............................................................112Appendix B Configuring AD

Authentication.........................................117Appendix C Disk Configuration

Status.................................................127

Chapter 1 Overview

1.1 Introduction

Thank you for choosing FNS-7000B Turbo Server. This product has the following key

features:

ٛSimple installation, 5-min configuration and user-friendly management interface

for SMB users.

ٛHigh speed SATA HDD, supports hotswap, maximum capacity up to 1.6TB.

ٛDual Gigabit ports for load balance, fail over and standalone settings.

ٛDouble USB 2.0 ports for network printer sharing & UPS.

ٛLCD panel for instant display of IP address and important system info; IP settings

can be configured directly without access to PC.

ٛSupports hot redundant power supply to increase system reliability (optional).

ٛProvides various practical backup mechanisms. Professional remote replication

to remote NAS USB 2.0 interface for CD/DVD data burning Provides backup software

for Windows users, instant/scheduled backup

can be performed without IT professional

1.2 Package Contents

Your FNS-7000B package contains: FNS-7000B Turbo Server Power cord CD-ROM

(user manual, Quick Install Wizard and software inclusive) Quick Installation Guide

Ethernet cable x 2 Flat head screws x 16

Important Notice: Please back up your disk data periodically to avoid data loss due to

improper operation or disk failure of FNS-7000B. LevelOne is not responsible for any

data loss or recovery.

1.3 System Overview Front View

Chapter 2 Installation

2.1 Install Hard Disk Components:

FNS-7000B

HDD tray x 4

(included in FNS-7000B) 3.5” SATA hard disk (optional)

(included in FNS-7000B)

Screw driver (not included)

Hard Disk Installation Procedure

1Unfasten the round head screws and take out the disk trays from FNS-7000B.

2Place a hard disk in a hard disk tray.

Tray front

It is highly recommended that you install disks of the same brand and same size on

FNS-7000B. The server may function improperly if disks of different brands and size are

installed. Please refer to Chapter 2.2 for hard disk recommendation list.

1Turn around the disk tray. Make sure the hard disk screw holes match the holes

of the disk tray. Fasten the flat head screws to lock the disk as indicated below.

2When finished, open the tray cover of FNS-7000B and insert the disk to the

server. Push the disk towards the end until it is locked. Note that all disks should be

inserted in order from top to bottom (HDD1~HDD4).

5. Fasten the tray with round head screws.
