Chapter1.Aboutthekeyboard

TheLenovo®USBSmartcardKeyboard(hereaftercalledthekeyboard)isafull-sizedkeyboardequippedwith

asmartcardreaderandtheThinkVantage®buttontoenhanceyourcomputingconvenienceandsecurity.

Thekeyboardenablesauthorizedusers’singlelogintothecomputerandpreventsunauthorizedaccess

tothenetworkofanorganization.Typically,theuser-accessvericationofthekeyboardsecuresthe

environmentfortransactionsperformedonbothpublicandprivatenetworks.TheThinkVantagebuttonon

thekeyboardprovidesquickaccesstotheThinkVantageProductivityCenterprogram,theLenovoCare℠

program,theLenovoThinkVantageToolboxprogram,ortheWindowsSystemInformationwindow.

Theoptionpackagecontains:

•LenovoUSBSmartcardKeyboard

•SoftwareandUserGuideDisc

•Setupandwarrantyposter

Productdescription

Thistopicprovidesgeneraldescriptionsaboutmainfeaturesofthekeyboard.

Figure1.Keyboardoverview

1ThinkVantagebutton4ScrollLockLED

2NumericLocklight-emittingdiode(LED)5SmartcardstatusLED

3CapsLockLED6Smartcardreader

ThinkVantagebutton

TheThinkVantagebuttonprovidesyouwithquickaccesstosomeoftheprogramsinstalledonyour

computer.

Note:BeforeusingtheThinkVantagebutton,ensurethatyouhaveinstalledtheLenovoUSBSmartcard

Keyboardhotkeydriver.

©CopyrightLenovo2009,20131

•Microsoft®Windows®XPandMicrosoftWindowsVista®:

PressingtheThinkVantagebuttonopenstheThinkVantageProductivityCenterprogramortheLenovo

Careprogram,whichcontainscomprehensivehelpandinformationforyourcomputer.

Ifthecomputerdoesnotcomewitheitheroftheprograms,pressingtheThinkVantagebuttonopensthe

WindowsSystemInformationwindow.

•MicrosoftWindows7:

PressingtheThinkVantagebuttonopensoneofthefollowingprograms.Ifthecomputerdoesnotcome

withanyofthefollowingprograms,pressingtheThinkVantagebuttonopenstheWindowsSystem

Informationwindow.

–LenovoSimpleTap:Thisprogramprovidesyouwithaquickwaytocustomizesomebasiccomputer

settings.

–LenovoSolutionCenter:Thisprogramenablesyoutotroubleshootandresolvecomputerproblems.

–LenovoThinkVantageToolbox:Thisprogramenablesyoutoevaluatesystemperformanceand

diagnoseandresolvecomputerproblems.

•MicrosoftWindows8andMicrosoftWindows8.1:

PressingtheThinkVantagebuttonopenstheLenovoDeviceExperienceprogram.

NumericLockLED

WhentheLEDison,thenumerickeypadonthekeyboardisenabled.WhentheLEDisoff,thecursor

controlonthenumerickeypadisdisabled.PresstheNumericLockkeytoswitchbackandforthbetween

thesemodes.

CapsLockLED

WhentheLEDison,theCapsLockmodeisenabled.Inthismode,youcantypeallalphabeticcharacters

(A-Z)inuppercasetextdirectly.WhentheLEDisoff,theCapsLockmodeisdisabled.Toenableordisable

theCapsLockmode,presstheCapsLockkey.

ScrollLockLED

WhentheLEDison,theScrollLockmodeisenabled.Thearrowkeyscanbeusedasscreen-scrollfunction

keysandthecursorcannotbemovedwiththearrowkeys.Notallapplicationprogramssupportthis

function.WhentheScrollLockLEDisoff,thearrowkeyscanbeusedforcursormovement,butnotas

screen-scrollfunctionkeys.PresstheScrollLockkeytoswitchbackandforthbetweenthesemodes.

SmartcardstatusLED

ThesmartcardstatusLEDisadual-colorLED,whichindicatestheworkingstatusofthesmartcardreader

ingreenandamber.

FormoreinformationaboutthesmartcardstatusLED,seeTable1“SmartcardstatusLED”onpage9.

Smartcardreader

Thesmartcardreaderisacompact,lightweight,high-performancedevicethatenhancescomputerand

networksecurity.Itsupportsmostmemorymodulesandmicroprocessorcards.

Thesmartcardreadersupportsthefollowing:

•Readingfromandwritingtoallmemoryandmicroprocessorsmartcards(T=0,T=1)thatconformto

InternationalOrganizationforStandardization(ISO)7816-1,2,3,4standards

2LenovoUSBSmartcardKeyboardUserGuide

Note:Lenovodoesnotprovideasmartcardwiththisoption.

•Securepersonalidenticationnumber(PIN)entrymode(PINauthenticationwithouttransmittingthePIN

tothehostcomputer)

•Userauthenticationthroughthird-partyapplications

•ThinkVantageClientSecuritySolution

FormoreinformationaboutusingsmartcardswiththeThinkVantageClientSecuritySolutionprogram,

refertothehelpinformationsystemfortheprogram.

Note:Forthesmartcardreaderspecications,seeAppendixA“Productspecications”onpage11.

Cableslot

Thecableslotprovidesaconvenientwaytochangethelocationwherethecableleavesthekeyboard.You

canroutethekeyboardcableintotheleftorrightslottoreducecableclutterandoptimizedeskspace.

Tiltfeet

Therearethreetiltfeetpositionsforsettingthekeyboardtoacomfortabledegree.Youcanplacethe

keyboardatanangleof4degrees,6degrees,or9degreesatyourpreference.

Systemrequirements

Tousethekeyboard,yourcomputermusthaveanavailableUniversalSerialBus(USB)connectorand

oneofthefollowingoperatingsystemsinstalled:

•MicrosoftWindowsXP(32-bit)

•MicrosoftWindowsVista(32-bitor64-bit)

•MicrosoftWindows7(32-bitor64-bit)

•MicrosoftWindows8(32-bitor64-bit)

•MicrosoftWindows8.1(32-bitor64-bit)

Chapter1.Aboutthekeyboard3

4LenovoUSBSmartcardKeyboardUserGuide

Chapter2.Installation

ThischapterprovidesinstructionsonhowtoinstalltheLenovoUSBSmartcardKeyboard.

Installingthedrivers

ThekeyboardcanbeusedoncomputersthathaveaWindowsXP,WindowsVista,Windows7,Windows

8,orWindows8.1operatingsysteminstalled.Beforeusingthekeyboard,installthefollowingdrivers

onthecomputer:

•LenovoUSBSmartcardKeyboardhotkeydriver

•Lenovokeyboardsmartcardreaderdriver

Note:Forthelatestversionofthedriversandthedocumentation,goto:

http://www.lenovo.com/think/support

ToinstallthedriversontheWindowsXP ,WindowsVista,Windows7,Windows8,orWindows8.1operating

system,dothefollowing:

1.Saveanyopendocumentsandexitallapplications.

2.InserttheSoftwareandUserGuideDiscintotheopticaldrive.Thediscstartsautomatically.Ifthedisc

doesnotstartautomatically,dooneofthefollowing:

•Iftheautoplaywindowopens,clickRunViewHtml.exe.

•Iftheautoplaywindowdoesnotopen,dothefollowing:

–FortheWindowsXP,WindowsVista,orWindows7operatingsystem,gointoMyComputeror

Computer,thendouble-clicktheCD/DVDdriveicon.

–FortheWindows8orWindows8.1operatingsystem,openFileExplorerandclickComputeror

ThisPC,thendouble-clicktheCD/DVDdriveicon.

3.Selectyourlanguage.

4.ClickSoftwareintheleftpaneofthewindow.

5.Followtheinstructionsonthescreentoinstallthedevicedriver.

Note:FortheWindowsXPusers,itisrecommendedtoinstallthesmartcardreaderdrivertousethesmart

cardreaderofthekeyboard.FortheWindowsVista,Windows7,Windows8,orWindows8.1users,itis

alsorecommendedtoinstallthesmartcardreaderdrivertouseotherspecicfunctionsincludingthe

securePINentry.

Installingthekeyboard

Thistopicprovidesinstructionsonhowtoinstallthekeyboardafteryouinstallthedrivers.

©CopyrightLenovo2009,20135

Toinstallthekeyboard,dothefollowing:

1.Adjustthetiltfeettosetthekeyboardnearyourcomputertoyourpreference.

2.Routethekeyboardcableintotherightorleftcableslotaccordingtoyourpreference.

3.ConnectthekeyboardcabletoanavailableUSBconnectoronthecomputer.Theoperatingsystemwill

identifythekeyboardandthesmartcardreader.Then,thekeyboardisreadyforuse.

Figure2.Connectingthekeyboardtothecomputer

Usingthesmartcardreader

Thistopicprovidesinstructionsonhowtousethesmartcardreaderofthekeyboard.

Tousethesmartcardreaderofthekeyboard,dothefollowing:

1.Insertasmartcardintothesmartcardreaderslotwiththecontactpadfacingup.

Note:Forinformationonusingthesmartcard,contactthesmartcardmanufacturer.

Figure3.Insertingasmartcardintothesmartcardreader

2.ThesmartcardstatusLEDwillbeoningreenforawhile.Thenthesmartcardreaderisreadyforuse.

Attention:Toavoidtransmissionerrorsandlossofdata,donotremovethesmartcardwhenthesmartcard

readerisactive.

6LenovoUSBSmartcardKeyboardUserGuide
