Wired Controller VEWCL1E
Thank you for selecting LENNOX air conditioners. Please read this manual carefully before operation
and keep it for further reference.
To Users
Thank you for selecting LENNOX’s product. Please read this instruction manual
carefully before installing and using the product, so as to master and correctly use the
product. In order to guide you to correctly install and use our product and achieve
expected operating effect, we hereby instruct as below:
(1) This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsibility for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
(2) This instruction manual is a universal manual, some functions are only
applicable to particular product. All the illustrations and information in the
instruction manual are only for reference, and control interface should be
subject to actual operation.
(3) In order to make the product better, we will continuously conduct
improvement and innovation. We have the right to make necessary revision
to the product from time to time due to the reason of sales or production,
and reserve the right to revise the contents without further notice.
(4) For personal injury or property loss and damage caused by improper
operation such as improper installation and debugging, unnecessary
maintenance, violation of related national laws and rules and industrial
standard, and violation of this instruction manual, etc., we will bear no
liability.
(5) The final right to interpret for this instruction manual belongs to LENNOX.
Contents
1 Safety Notices (Please be sure to abide) .................................. 1
2 Operation Notices.......................................................................... 2
3 Instructions to Appearance and Display..................................... 3
3.1 LCD of Wired Controller........................................................................ 4
3.2 Instruction for LCD of Wired Controller............................................... 5
4 Buttons ............................................................................................ 5
4.1 Silkscreen of Buttons............................................................................. 5
4.2 Instruction for Buttons ........................................................................... 6
5 Instructions for Status Column..................................................... 7
6 Installation and Commissioning................................................. 10
6.1 Instruction of Wired Controller ........................................................... 11
6.2 Engineering Debugging of Air Conditioner....................................... 19
7 Operational Instructions of Air Conditioner.............................. 35
7.1 ON/OFF................................................................................................. 35
7.2 Setting of Modes .................................................................................. 36
7.3 Setting of Temperature........................................................................ 37
7.4 Setting of Fan Speed........................................................................... 38
7.5 Setting of Swing Function................................................................... 39
7.6 Setting of Functions............................................................................. 40
7.7 Gate-control Function.......................................................................... 49
7.8 Independent Swing* ............................................................................ 49
8 Operational Instructions of ERV+DX Coil Unit........................ 51
8.1 ON/OFF................................................................................................. 51
8.2 Setting of Modes .................................................................................. 52
8.3 Setting of Temperature........................................................................ 53
8.4 Setting of Fan Speed........................................................................... 53
8.5 Setting of Control Modes .................................................................... 54
8.6 Setting of Functions............................................................................. 55
9 Instructions to General Operation............................................. 57
9.1 Setting of Timer .................................................................................... 57
9.2 Service Hotline ..................................................................................... 59
9.3 Setting of Language ............................................................................ 61
9.4 Setting of Sound................................................................................... 61
9.5 Setting of Date and Time .................................................................... 61
9.6 Long-distance Shielding...................................................................... 61
10 Display of Errors ........................................................................ 62
10.1 Error Code List of ODU..................................................................... 63
10.2 Error Code List of IDU....................................................................... 67
10.3 Code List for Debugging................................................................... 70
10.4 Code List for Status........................................................................... 72
Wired Controller VEWCL1E
1
1 Safety Notices (Please be sure to abide)
Warning: If not abide strictly, it may cause severe damage to the unit or
the people.
Note: If not abide strictly, it may cause slight or medium damage to the unit
or the people.
This sign indicates that the operation must be prohibited. Improper
operation may cause severe damage or death to people.
This sign indicates that the items must be observed. Improper operation
may cause damage to people or property.
WARNING!
This product can’t be installed at corrosive, inflammable or explosive environment or
the place with special requirements, such as kitchen. Otherwise, it will affect the
normal operation or shorten the service life of the unit, or even cause fire hazard or
serious injury. As for above special places, please adopt special air conditioner with
anti-corrosive or anti-explosion function.
Wired Controller VEWCL1E
2
2 Operation Notices
The power supply for all indoor units must be unified.
Prohibit installing the wired controller at wet or sunshine places.
Do not knock, throw or frequently disassemble the wired controller.
Do not operate the wired controller with wet hands.
In one system network, you must set one indoor unit as the master indoor unit,
other indoor units are slave indoor units.
The operation mode of the system is basing on that of master indoor unit. Master
indoor unit can switch to any modes, while slave unit can’t switch to the mode that
is conflicting with master indoor unit.
When master indoor unit changes mode which cause operation mode of
slave indoor unit conflicts with that of system, the operation mode of slave unit will
switch to the operate mode of system automatically.
When two wired controllers control one (or more) indoor unit(s), the address of
wired controller should be different.
Functions with “*” are optional for indoor units. If a function is not included in an
indoor unit, wired controller can’t set the function, or setting of this function is
invalid to the indoor unit.
Wired Controller VEWCL1E
3
3 Instructions to Appearance and Display
Fig. 3.1Outline of wired controller
Wired Controller VEWCL1E
4
3.1 LCD of Wired Controller
Fig. 3.2LCD of air conditioner wired controller
Fig. 3.3 LCD of ERV+DX Coil unit wired controller
Wired Controller VEWCL1E
5
3.2 Instruction for LCD of Wired Controller
Table 3.1
No. Name Instruction
1 Status
It is for displaying date, time and the activated functional
icon
2 Mode It is for displaying operating mode
3 Temperature It is for displaying the temperature
4 Swing It is for displaying the current swing status
5
Fan speed
It is for displaying the fan speed
6 Control mode It is for displaying the control mode of the ERV+DX Coil unit
4 Buttons
4.1 Silkscreen of Buttons
Fig. 4.1 Silkscreen of buttons
Wired Controller VEWCL1E
6
4.2 Instruction for Buttons
Table. 4.1 Instruction for Buttons
No. Name Function
1 Fan
Switch fan speed: Auto, Low, Med. Low,
Medium,Med. High, and High
2 Left Turn page
Move the cursor
Set and view parameters
4 Right
3 Up Set the operating temperature of indoor unit
Move the cursor
Set and view parameters
8 Down
5 ON/OFF/Return Turn on/off the unit and return to the previous page
6 Mode
Switch the operating mode: Auto, Cool, Dry, Fan,
Heat, Floor, 3D Heat, etc.
7
Menu/OK
Select mode and confirm parameters
9 Swing/Control
Set the swing status of air conditioner or control
mode of ERV+DX Coil system
Note:
①When the button operation is invalid, the beeper beeps for twice to prompt.
②If there is no operation in wired controller for consecutive 20 seconds, the
backlight turns off and returns to the homepage.
