LENCO HP-H005 Manuel utilisateur
Model: +3+
User manual - Turntable with bluetooth transmission
Gebruikshandleiding - Platenspeler met Bluetooth-overdracht
Bedienungsanleitung - Plattenspieler mit Bluetooth-Übertragung
Guide d’utilisation - tourne-disque avec transmission Bluetooth
Manual de usuario – Tocadiscos con transmisión Bluetooth
2AQ4R-HP-H005
1
Index
English..........................................................................................................2
Nederlands.................................................................................................24
Deutsch......................................................................................................48
Français......................................................................................................73
Español.......................................................................................................98
Version: 1.0
2
English
HP-H005
CAUTION:
Usage of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
This unit should not be adjusted or repaired by anyone except qualified service
personnel.
PRECAUTIONS BEFORE USE
KEEP THESE INSTRUCTIONS IN MIND:
1. Do not use this device near water.
2. Clean only with a slightly damp cloth.
3. Do not cover or block any ventilation openings. When placing the device
on a shelf, leave 5 cm (2”) free space around the whole device.
4. Install in accordance with the supplied user manual.
5. * Don’t step on or pinch the power adaptor. Be very careful, particularly
near the plugs and the cable’s exit point. Do not place heavy items on
the power adaptor, which may damage it. Keep the entire device out of
children’s reach! When playing with the power cable, they can seriously
injure themselves.
6. * Unplug this device during lightning storms or when unused for a long
period.
7. Keep the device away from heat sources such as radiators, heaters,
stoves, candles and other heat-generating products or naked flame.
8. Avoid using the device near strong magnetic fields.
9. Electrostatic discharge can disturb normal usage of this device. If so,
simply reset and restart the device following the instruction manual.
During file transmission, please handle with care and operate in a static-
free environment.
3
10. Warning! Never insert an object into the product through the vents or
openings. High voltage flows through the product and inserting an
object can cause electric shock and/or short circuit internal parts. For
the same reason, do not spill water or liquid on the product.
11. Do not use in wet or moist areas such as bathrooms, steamy kitchens or
near swimming pools.
12. Do not use this device when condensation may occur.
13. Although this device is manufactured with the utmost care and checked
several times before leaving the factory, it is still possible that problems
may occur, as with all electrical appliances. If you notice smoke, an
excessive build-up of heat or any other unexpected phenomena, you
should disconnect the plug from the main power socket immediately.
14. This device must operate on a power source as specified on the
specification label. If you are not sure of the type of power supply used
in your home, consult your dealer or local power company.
15. * The socket outlet must be installed near the equipment and must be
easily accessible.
16. * Do not overload ac outlets or extension cords. Overloading can cause
fire or electric shock.
17. * Devices with class 1 construction should be connected to a main
socket outlet with a protective earthed connection.
18. * Devices with class 2 construction do not require a earthed connection.
19. Keep away from rodents. Rodents enjoy biting on power cords.
20. * Always hold the plug when pulling it out of the main supply socket. Do
not pull the power cord. This can cause a short circuit.
21. Avoid placing the device on any surfaces that may be subject to
vibrations or shocks.
4
22. To clean the device, use a soft dry cloth. Do not use solvents or petrol
based fluids. To remove severe stains, you may use a damp cloth with
dilute detergent.
23. The supplier is not responsible for damage or lost data caused by
malfunction, misuse, modification of the device or battery replacement.
24. Do not interrupt the connection when the device is formatting or
transferring files. Otherwise, data may be corrupted or lost.
25. If the unit has USB playback function, the usb memory stick should be
plugged into the unit directly. Don’t use an usb extension cable because
it can cause interference resulting in failing of data.
26. The apparatus shall not be exposed to dripping or splashing and make
sure that no objects filled with liquids, such as vases, are placed on or
near the apparatus.
27. * To completely disconnect the power input, the mains plug of the
apparatus shall be disconnected from the mains, as the disconnect
device is the mains plug of apparatus.
28. If the unit works with battery, Battery shall not be exposed to excessive
heat such as sunshine, fire or the like.
29. Attention should be drawn to the environmental aspects of battery
disposal.
30. The apparatus can only be used in moderate extremely cold or climates
warm environments should be avoided.
31. The rating label has been marked on the bottom or back panel of the
apparatus.
32. This device is not intended for use by people (including children) with
physical, sensory or mental disabilities, or a lack of experience and
knowledge, unless they’re under supervision or have received
instructions about the correct use of the device by the person who is
responsible for their safety.
5
33. This product is intended for non professional use only and not for
commercial or industrial use.
34. Make sure the unit is adjusted to a stable position. Damage caused by
using this product in an unstable position or by failure to follow any
other warning or precaution contained within this user manual will not
be covered by warranty.
35. Never remove the casing of this apparatus.
36. Never place this apparatus on other electrical equipment.
37. Do not use or store this product in a place where it is subject to direct
sunlight, heat, excessive dust or vibration.
38. Do not allow children access to plastic bags.
39. Only use attachments/accessories specified by the manufacturer.
40. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as the power
supply cord or the plug, when liquid has been spilled or objects have
fallen into the apparatus, when the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
41. *Do not use a damaged power cord or plug or a loose outlet. Doing so
may result in fire or electric shock.
42. Prolonged exposure to loud sounds from personal music players may
lead to temporary or permanent hearing loss.
INSTALLATION
•Unpack all parts and remove protective material.
•*Do not connect the unit to the mains before checking the mains voltage
and before all other connections have been made.
*Those instructions are related only to products using power cable or AC
power adaptor.
6
COMPONENTS, FEATURES AND CONNECTIONS
1. Counterweight
2. Anti-skating Stub
3. Turntable Platter
4. Tonearm Lift Lever
5. Tonearm Rest
6. 33/45 Selector
7. Tonearm
8. Stop/Start Knob
9. Cartridge
10. Lid
11. Lid Hinge
12. Ground Connector
13. PHONO & Line Out Jacks
14. PHONO & Line Out Switch
15. Anti-skating Weight
16. USB-PC port
17. AC-DC Power Jack
18. Bluetooth Indicator
19. Power Rocker Switch
7
Please check thoroughly and make sure you find the following items that
come along with this package:
1) Unit
2) Adaptor with EU-UK plug-end
3) Counterweight
4) Platter with Belt
5) 45 RPM Adaptor
6) Turntable mat
7) Instruction Manual
8) Cartridge Alignment Protractor
9) USB-PC Cable
10)2pcs lid spare rubber
11)Anti-skating Weight
This turntable is supplied with a factory fitted and adjusted cartridge.
**The following instructions for adjusting the cartridge are provided in case
the cartridge is replaced by a different model at a later date.
Installing the Lid
Install the Lid carefully over the hinge prongs.
Turntable Platter and Belt Setup
1. Install the drive belt over the inner ring under the platter and make
sure it won’t fall off during the setup.
2. Place the platter through the turntable
spindle, then rotate the platter until you see
the drive motor pulley through the window at
the top left corner.
3. Carefully grab the drive belt and put it
around the slot of motor pulley.
4. Connect the power adapter to the turntable and power on the
turntable.
5. Set the Motor Start/Stop switch to the Start position to see if the
platter motor spins. If the platter does not spin, try the steps listed
above again.
8
Cartridge Down force Adjustment
The Counterweight supplied is suitable for cartridges weighing between
3.0-6.0g.
-Gently push and turn the Counterweight onto the rear of the tonearm
(with the scale facing toward the front of the turntable).
-Remove the cartridge protection cap.
-Lower the tonearm lift and position the cartridge in the space between
tonearm rest and platter.
Carefully rotate the Counterweight until the tonearm balances out. The
tonearm should return to the balanced position if it is moved up or down.
This adjustment must be done carefully.
-Once the tonearm is correctly balanced return it to its’ rest. Hold the
Counterweight without moving it, and gently rotate the Down force
Scale ring until the zero is in line with black line on the rear of the
tonearm. Check whether the arm still balances out.
9
-Rotate the counterweight counter clockwise (seen from the front) to
adjust the down force according to the cartridge manufacturer’s
recommendations. One mark on the scale represents 0.05g of down
force.
NOTE: The recommended down force for the factory fitted cartridge is
3.5±0.5g.
Anti-skating force adjustment
The anti-skating force must be adjusted corresponding to the down force as
follows:
Down force
Groove in the stub
5 - 10mN
1 st from bearing rings
10 - 15mN
15 – 20mN
2 nd " " "
3rd " " "
20mN and bigger
4 th " " "
Slip the loop of the anti-skating weight's thread over the 3rd groove of the
stub to set the correct anti-skating force for the factory-fitted cartridge. Feed
the thread through the loop of the wire support.
