Leica RTC360 Manuel utilisateur

Leica RTC360/RTC360 LT

User Manual

Version 3.1

English

Introduction

Congratulations on the purchase of a Leica RTC360/RTC360 LT series instru-

ment.

This manual contains important safety directions as well as instructions for

setting up the product and operating it. Refer to 1 Safety Directions for fur-

ther information.

Read carefully through the User Manual before you switch on the product.

To ensure safety when using accompanying battery charger, also observe the

directions and instructions contained in the User Manual of the battery char-

ger.

The content of this document is subject to change without prior notice. Ensure

that the product is used in accordance with the latest version of this docu-

ment.

Updated versions are available for download at the following Internet address:

https://myworld.leica-geosystems.com > myDownloads.

The model and serial number of your product are indicated on the type plate.

Always refer to this information when you need to contact your agency or

Leica Geosystems authorised service centre.

•Windows® is a registered trademark of Microsoft Corporation in the

United States and other countries

All other trademarks are the property of their respective owners.

On the last page of this manual, you can nd the address of Leica Geosystems

headquarters. For a list of regional contacts, please visit

http://leica-geosystems.com/contact-us/sales_support.

Name Description/Format

Leica

RTC360/

RTC360 LT

Quick Guide

Provides an overview of the product together

with technical data and safety directions. Inten-

ded as a quick reference guide.

ü ü

Leica

RTC360/

RTC360 LT

User Manual

All instructions required in order to operate the

product to a basic level are contained in the User

Manual. Provides an overview of the product

together with technical data and safety direc-

tions.

—ü

Leica

RTC360/

RTC360 LT

Check &

Adjust User

Manual

All instructions required in order to perform the

Check & Adjust of the instrument are contained

in the separate User Manual.

—ü

Purchase

☞

Product identication

Trademarks

Leica Geosystems

address book

Available documenta-

tion

Name Description/Format

Leica RTC360

myLearning

course

The course introduces the Leica RTC360 3D real-

ity capture solution. It covers the benets of

using it, how it works and how to use it.

https://learning.leica-geosystems.com/course/

view.php?id=142

— —

Refer to the following resources for all RTC360/RTC360 LT documenta-

tion/software:

•The supplied USB documentation card

•https://myworld.leica-geosystems.com

•https://learning.leica-geosystems.com/course/view.php?id=142

Table of Contents

1 Safety Directions 6

1.1 General Introduction 6

1.2 Denition of Use 6

1.3 Limits of Use 7

1.4 Responsibilities 7

1.5 Hazards of Use 8

1.6 Laser Classication 12

1.6.1 General 12

1.6.2 Scanning Laser 12

1.7 Electromagnetic Compatibility (EMC) 13

1.8 FCC Statement, Applicable in U.S. 15

1.9 ISED Statements (EN/FR), Applicable in Canada 17

2 Description of the System 18

2.1 Packing / Unpacking the Instrument 18

2.2 Container Contents 18

2.3 Backpack Contents 19

2.4 Instrument Components 19

2.5 System Components 20

2.6 System Concept 20

2.6.1 Power Concept 20

2.6.2 Data Storage Concept 20

3 User Interface 22

3.1 Power Button 22

3.2 Instrument Status 22

3.3 Screen 24

4 Operation 25

4.1 Instrument Setup 25

4.1.1 General Information 25

4.1.2 Lightweight Tripod Setup 25

4.1.3 Heavy Duty Tripod Setup 26

4.1.4 Upside-down Mounting 26

4.2 Power Supply 27

4.2.1 Batteries 27

4.2.2 Exchanging the Batteries 27

4.3 Operation - Getting Started 28

4.4 Imaging 30

4.5 Scanning 30

4.5.1 Ambient Conditions 30

4.5.2 Onboard Controls 31

4.5.3 Settings 34

4.5.4 Troubleshooting 38

4.5.5 Field of View (FoV) 39

4.6 Data Transfer 39

4.7 Working with the USB Data Storage Device 40

5 Care and Transport 41

5.1 Transport 41

5.2 Check & Adjust 41

5.3 Storage 41

5.4 Cleaning and Drying 42

5.5 Glass Cleaning Procedure 42

5.6 Maintenance 43

4 Table of Contents

6 Technical Data 44

6.1 General Technical Data of the Product 44

6.2 System Performance 44

6.3 Laser System Performance 45

6.4 Electrical Data 46

6.4.1 Pin Assignment of Lemo Ports 47

6.5 Environmental Specications 48

6.5.1 RTC360/RTC360 LT 48

6.5.2 GEB361 Battery and GEV282 AC/DC Power Supply 49

6.6 Dimensions 49

6.7 Weight 51

6.8 Accessories 51

6.9 Conformity to National Regulations 51

6.9.1 RTC360/RTC360 LT 51

6.9.2 Dangerous Goods Regulations 52

7 Software Licence Agreement/Warranty 53

Table of Contents 5

1 Safety Directions

1.1 General Introduction

The following directions enable the person responsible for the product, and

the person who actually uses the equipment, to anticipate and avoid opera-

tional hazards.

The person responsible for the product must ensure that all users understand

these directions and adhere to them.

Warning messages are an essential part of the safety concept of the instru-

ment. They appear wherever hazards or hazardous situations can occur.

Warning messages...

•make the user alert about direct and indirect hazards concerning the use

of the product.

•contain general rules of behaviour.

For the users‘ safety, all safety instructions and safety messages shall be

strictly observed and followed! Therefore, the manual must always be available

to all persons performing any tasks described here.

DANGER, WARNING, CAUTION and NOTICE are standardised signal words for

identifying levels of hazards and risks related to personal injury and property

damage. For your safety, it is important to read and fully understand the fol-

lowing table with the different signal words and their denitions! Supplement-

ary safety information symbols may be placed within a warning message as

well as supplementary text.

Type Description

DANGER Indicates an imminently hazardous situation

which, if not avoided, will result in death or

serious injury.

WARNING Indicates a potentially hazardous situation or

an unintended use which, if not avoided,

could result in death or serious injury.

CAUTION Indicates a potentially hazardous situation or

an unintended use which, if not avoided,

may result in minor or moderate injury.

NOTICE

Indicates a potentially hazardous situation or

an unintended use which, if not avoided,

may result in appreciable material, nancial

and environmental damage.

☞Important paragraphs which must be

adhered to in practice as they enable the

product to be used in a technically correct

and efcient manner.

1.2 Denition of Use

•Measuring horizontal and vertical angles

•Measuring distances

•Scanning objects

•Capturing and recording images

•Recording measurements

Description

About warning

messages

Intended use

6 Safety Directions

•Computing with software

•Remote control of product

•Data communication with external appliances

•Use of the product without instruction

•Use outside of the intended use and limits

•Disabling safety systems

•Removal of hazard notices

•Opening the product using tools, for example screwdriver, unless this is

permitted for certain functions

•Modication or conversion of the product

•Use after misappropriation

•Use of products with recognisable damage or defects

•Use with accessories from other manufacturers without the prior explicit

approval of Leica Geosystems

•Inadequate safeguards at the working site

•Deliberate dazzling of third parties

1.3 Limits of Use

Suitable for use in an atmosphere appropriate for permanent human habita-

tion: not suitable for use in aggressive or explosive environments.

WARNING

Working in hazardous areas, or close to electrical installations or sim-

ilar situations

Life Risk.

Precautions:

▶Local safety authorities and safety experts must be contacted by the per-

son responsible for the product before working in such conditions.

The following advice is only valid for the AC/DC power supply and the battery

charger.

Suitable for use in dry environments only and not under adverse conditions.

1.4 Responsibilities

Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to as

Leica Geosystems, is responsible for supplying the product, including the User

Manual and original accessories, in a safe condition.

Reasonably foresee-

able misuse

Environment

☞

Environment

Manufacturer of the

product

Safety Directions 7

The person responsible for the product has the following duties:

•To understand the safety instructions on the product and the instructions

in the User Manual

•To ensure that it is used in accordance with the instructions

•To be familiar with local regulations relating to safety and accident pre-

vention

•To inform Leica Geosystems immediately if the product and the applica-

tion become unsafe

•To ensure that the national laws, regulations and conditions for the oper-

ation of the product are respected

1.5 Hazards of Use

WARNING

Distraction or loss of attention

During dynamic applications there is a danger of accidents occurring if the

user does not pay attention to the environmental conditions around, for

example obstacles, excavations or trafc.

Precautions:

▶The person responsible for the product must make all users fully aware of

the existing dangers.

WARNING

Inadequate securing of the working site

This can lead to dangerous situations, for example in trafc, on building sites

and at industrial installations.

Precautions:

▶Always ensure that the working site is adequately secured.

▶Adhere to the regulations governing safety, accident prevention and road

trafc.

NOTICE

Dropping, misusing, modifying, storing the product for long periods or

transporting the product

Watch out for erroneous measurement results.

Precautions:

▶Periodically carry out test measurements, particularly after the product

has been subjected to abnormal use and before and after important

measurements.

WARNING

Moving parts at the product during operation

Risk of squeezing extremities or entanglement of hair and/or clothes.

Precautions:

▶Keep a safe distance to the moving parts.

Person responsible

for the product

8 Safety Directions

If the instrument moves unexpectedly during operation, stop the instrument

via user interface (display, key) or alternatively remove the battery or main

power source to prevent further movements.

CAUTION

Not properly secured accessories

If the accessories used with the product are not properly secured and the

product is subjected to mechanical shock, for example blows or falling, the

product may be damaged or people can sustain injury.

Precautions:

▶When setting up the product, make sure that the accessories are correctly

adapted, tted, secured, and locked in position.

▶Avoid subjecting the product to mechanical stress.

WARNING

Instrument mounted sideways or upside down

If the instrument is mounted in a tilted, that is non-upright way, or even

upside down, for example at a ceiling, it may drop due to an unintentional

release of the locking lever which may result in serious injury.

Precautions:

▶Only use the GAD121 adapter plate for tilted or upside-down mounting.

▶Make sure that the locking lever is secured by the locking screw from

unintended release by turning the locking screw in anticlockwise direction

until the locking lever is locked. If the locking lever cannot be moved, it is

secured.

WARNING

Exposure of batteries to high mechanical stress, high ambient temper-

atures or immersion into uids

This can cause leakage, re or explosion of the batteries.

Precautions:

▶Protect the batteries from mechanical inuences and high ambient tem-

peratures. Do not drop or immerse batteries into uids.

WARNING

Short circuit of battery terminals

If battery terminals are short circuited e.g. by coming in contact with jewellery,

keys, metallised paper or other metals, the battery can overheat and cause

injury or re, for example by storing or transporting in pockets.

Precautions:

▶Make sure that the battery terminals do not come into contact with

metallic objects.

☞

Safety Directions 9

WARNING

Inappropriate mechanical inuences to batteries

During the transport, shipping or disposal of batteries it is possible for inap-

propriate mechanical inuences to constitute a re hazard.

Precautions:

▶Before shipping the product or disposing it, discharge the batteries by the

product until they are at.

▶When transporting or shipping batteries, the person in charge of the

product must ensure that the applicable national and international rules

and regulations are observed.

▶Before transportation or shipping, contact your local passenger or freight

transport company.

WARNING

Overheating hazard

If the ventilation slots are covered while the product is being used, the

product can overheat and cause injury or re.

Precautions:

▶Make sure that the ventilation slots are not covered by any objects while

the product is being used.

WARNING

If the product is improperly disposed of, the following can happen:

•If polymer parts are burnt, poisonous gases are produced which may

impair health.

•If batteries are damaged or are heated strongly, they can explode and

cause poisoning, burning, corrosion or environmental contamination.

•By disposing of the product irresponsibly you may enable unauthorised

persons to use it in contravention of the regulations, exposing themselves

and third parties to the risk of severe injury and rendering the environ-

ment liable to contamination.

•The product includes parts of Beryllium inside. Any modication of some

internal parts can release dust or fragments, creating health hazard.

Precautions:

▶The product must not be disposed with household waste.

Dispose of the product appropriately in accordance with

the national regulations in force in your country.

Always prevent access to the product by unauthorised

personnel.

Product-specic treatment and waste management information can be

received from your Leica Geosystems distributor.

☞Applies only for California. The product contains CR Lithium Cell(s)

with perchlorate material inside – special handling may apply.

See http://www.dtsc.ca.gov/hazardouswaste/perchlorate/

10 Safety Directions

Autres manuels pour RTC360

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Leica Instrument de mesure

Leica

Leica Rod Eye 140 Manuel utilisateur

Leica

Leica GS09 Manuel utilisateur

Leica

Leica NA300 Series Manuel utilisateur

Leica

Leica iCON PA10 Manuel utilisateur

Leica

Leica TS11 Manuel utilisateur

Leica

Leica DISTO D3a BT Manuel utilisateur

Leica

Leica Lino L2 Manuel utilisateur

Leica

Leica DISTO D810 touch Manuel utilisateur

Leica

Leica 3D Disto Manuel utilisateur

Leica

Leica Roteo 20HV Manuel utilisateur

Leica

Leica FlexLine plus Manuel utilisateur

Leica

Leica TS02 Manuel utilisateur

Leica

Leica PINMASTER II PRO Manuel utilisateur

Leica

Leica Disto Special5 Manuel utilisateur

Leica

Leica RANGEMASTER CRF 1000-R Manuel utilisateur

Leica

Leica RANGEMASTER 1200 scan Manuel utilisateur

Leica

Leica DISTO A6 Manuel utilisateur

Leica

Leica Viva TS16 Manuel utilisateur

Leica

Leica Rugby 640G Manuel utilisateur

Leica

Leica Pinmaster Manuel utilisateur

Leica

Leica 3D Disto Manuel utilisateur

Leica

Leica RANGEMASTER CRF 1200 Manuel d'instructions

Leica

Leica AT930 Manuel utilisateur

Leica

Leica TPS1200+ Series Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
