LaserLiner X2-Laser Manuel utilisateur

X2-Laser

1H360° 2V 1P

Laser

515 nm

X2-Laser

Function / Application

Green cross-line laser with horizontal laser circle and two vertical lines

– Exact horizontal and vertical alignment of objects

– Time-saving automatic alignment

– Easy alignment of slopes

– Visual signals indicate when the device is outside its self-levelling range

– Integrated hand-held receiver mode for outdoor applications

– Simple horizontal and vertical mounting on drywall construction proles

– Long battery operating time thanks to powerful lithium-ion rechargeable battery

Safety instructions

Using class 2 lasers

Laser radiation!

Do not stare into the beam!

Class 2 laser

< 1 mW · 515 / 650 nm

EN 60825-1:2014/AC:2017

Completely read through the operating instructions, the „Warranty and

Additional Information“ booklet as well as the latest information under

the internet link at the end of these instructions. Follow the instructions

they contain. This document must be kept in a safe place and if the

laser device is passed on, this document must be passed on with it.

General safety instructions

– The device must only be used in accordance with its intendedpurpose

and within the scope of the specications.

– The measuring tools and accessories are not toys. Keep out of reach

of children.

– Modications or changes to the device are not permitted, this will

otherwise invalidate the approval and safety specications.

– Do not expose the device to mechanical stress, extreme temperatures,

moisture or signicant vibration.

– The device must no longer be used if one or more of its functions fail

or the battery charge is weak.

Safety instructions

Dealing with electromagnetic radiation

– The measuring device complies with electromagnetic compatibility

regulations and limits in accordance with the EMC Directive 2014/30/EU.

– Local operating restrictions – for example, in hospitals, aircraft, petrol

stations or in the vicinity of people with pacemakers – may apply. Electronic

devices can potentially cause hazards or interference or be subject to hazards

or interference.

– Attention: Do not look into the direct or reected beam.

– Do not point the laser beam towards persons.

– If a person‘s eyes are exposed to class 2 laser radiation, they should shut

their eyes and immediately move away from the beam.

– Under no circumstances should optical instruments (magnifying glass,

microscope, binoculars) be used to look at the laser beam or reections.

– Do not use the laser at eye level (1.40 ... 1.90 m)

– Reective, specular or shiny surfaces must be covered whilst laser devices

are in operation.

– In public areas shield off the laser beam with barriers and partitions

wherever possible and identify the laser area with warning signs.

Special product features

Automatic alignment of the device with a magnetically

dampened pendulum system. The device is brought into

initial position and aligns itself autonomously.

Transport LOCK: The device is protected with a pendelum

lock during transport.

GRX-READY technology enables line lasers to be used even in

unfavourable light conditions.The laser lines pulsate at a high

frequency and this can be picked up by special laser receiversover

long distances.

When transporting, always switch off all lasers, secure pendulum and

push the slide switch (2) to the right.

X2-Laser

Green laser technology

1H360°

2V 1P S

Number and direction of the lasers

H = horizontal laser

V = vertical laser

P = plumb laser

S = slope function

Laser emitting window

Slide switch

aON

bOFF / Slope mode /

Transport lock

Rechargeable battery

compartment (bottom)

1/4”/5/8“-tripod threads

(bottom)

LED hand receiver mode

Hand receiver mode

LED status indicator /

Battery charge

Laser line selection button

Laser emitting window,

reference beam

a b

Devices with PowerGreen++ technology have extremely bright

green laser diodes of the highest performance class that allow

very good visibility of laser lines at great distances, on dark

surfaces and in bright ambient lighting conditions.

Approx. 6 times brighter than a typical red laser with 630 - 660 nm

1Use of lithium-ion rechargeable battery

– The power supply unit is to be used in enclosed

spaces only; do not expose to moisture or rain as

this may result in the risk of electric shock.

– Charge the device‘s battery completely

prior to use.

– Connect the power supply unit to the mains and

connecting socket on the battery pack. Only use

the power supply unit provided. Using a different

power supply unit will invalidate the warranty.

– The LED on the battery pack lights up red

while the battery is charging. When the LED

changes to green, charging is complete.

– The status indicator (7) flashes if the battery charge is low, until the device

shuts down to protect the battery.

Open the battery compartment and

insert lithium-ion battery as

illustrated (contacts first).

To insert the lithium-ion

rechargeable battery

Power supply

Do not open the rechargeable battery. This could cause short-circuits.

Make sure there are no conductive objects in the vicinity of the

battery contacts. Short-circuiting of these contacts can cause burn

injuries or fire.

The battery may only be charged with the battery charger provided

and used only in this laser device. Any other use may cause injury

or fire.

X2-Laser

The transport restraint must be released for horizontal and vertical

levelling. The laser lines flash when the device is outside the automatic

levelling range of 3°. Position the device such that it is within the

levelling range.

Horizontal and vertical levelling

Release the transport restraint, push the slide switch (2) to the left.

The horizontal laser line appears. The laser lines can be switched individually

with the selection button.

Slope mode

Do not release the transport restraint, push the slide switch (2) to the right.

Select the laser using the selector button (8). Sloping planes and tilts

can now be measured. In this mode, the laser lines no longer align

automatically. This is signalised by the laser lines flashing.

LASER LASER LASER LASER LASER

LASER LASER LASER LASER

1 Sek.

Due to the special optics required to generate a continuous 360° laser

line, the underlying technology may cause differences in brightness in

different areas of the line. This may lead to different ranges in hand

receiver mode.

Observe the laser receiver‘s operating instructions for line lasers.

Hand receiver mode

Optional: Working with the laser receiver GRX

Use an GRX laser receiver (optional) to carry out levelling at great distances

or when the laser lines are no longer visible. To work with a laser receiver,

switch the line laser to hand-held receiver mode by keeping button 6

(hand-held receiver mode on / off) pressed. The laser lines will now pulsate

with high frequency, making the laser lines darker. The laser receiver can

detect these pulsating laser lines.

X2-Laser

A2 A2

< 0,2 mm / m = OK

Preparing the calibration check

It is possible for you to check the calibration of the laser. To do this, position

the device midway between 2 walls, which must be at least 5 metres apart.

Switch the device on (Laser cross ON). The best calibration results are

achieved if the device is mounted on a tripod.

1. Mark point A1 on the wall.

2. Turn the device through 180° and mark point A2.

You now have a horizontal reference between points A1 and A2.

Performing the calibration check

3. Position the device as near as possible to the wall

at the height of point A1.

4. Turn the device through 180° and mark point A3.

The difference between points A2 and A3 is the tolerance.

When A2 and A3 are more than 0.2 mm / m apart, an adjustment

is necessary. Contact your authorised dealer or else the

UMAREX-LASERLINER Service Department.

Checking the horizontal line

Position the device about 5 m from a wall and

switch on the cross laser. Mark point B on the

wall. Turn the laser cross approx. 2.5 m to the

right and mark point C. Check whether the

horizontal line from point C is level with point B

to within ± 1 mm. Repeat the process by turning the laser to the left.

2,5 m

<1 mm = OK

Checking the vertical line

Position the device about 5 m from a wall. Fix a plumb bob with a line of 2.5 m

length on the wall, making sure that the bob can swing freely. Switch on the

device and align the vertical laser to the plumb line. The precision is within the

specified tolerance if the deviation between the laser line and the plumb line

is not greater than ± 1 mm.

Regularly check the calibration before use, after transport and after

extended periods of storage.

Calibration

The meter needs to be calibrated on a regular basis to ensure it produces

accurate measurement results. We recommend carrying out calibration

once a year.

Information on maintenance and care

Clean all components with a damp cloth and do not use cleaning agents,

scouring agents and solvents. Remove the battery pack before storing for

longer periods. Store the device in a clean and dry place.

X2-Laser

EU directives and disposal

This device complies with all necessary standards

for the free movement of goods within the EU.

This product is an electric device and must be

collected separately for disposal according to

the European Directive on waste electrical and

electronic equipment.

Further safety and supplementary notices at:

http://laserliner.com/info/?an=AJQ

Technical data (Subject to technical changes without notice. 20W41)

Self-levelling range

± 3°

Accuracy

± 0.2 mm / m

Levelling

auto

Visibility (typical)*

60 m

Working range with hand receiver

(depends on how the technology

affects the difference in brightness)

60 m

Laser wavelength

515 nm

Plumb laser wavelength

650 nm

Laser class 2 / < 1 mW (EN60825-1:2014/AC:2017)

Degree of protection

IP 54

Power supply Li-ion battery pack 3.7V / 5.2Ah;

Power supply 5V/DC / 2000mAh

Operating time

approx. 6 hours

Charging time

approx. 6 hours

Operating conditions

0°C ... 50°C, max. humidity 80% rH,

no condensation, max. working altitude

4000 m above sea level

Storage conditions -10°C ... 70°C,

max. humidity 80% rH

Dimensions (W x H x D)

126 x 130 x 81 mm

Weight

642 g (including battery pack)

* at up to 300lux

Autres manuels pour X2-Laser

Table des matières

Autres manuels LaserLiner Niveau laser

LaserLiner

LaserLiner AutoSmart-Laser Manuel utilisateur

LaserLiner

LaserLiner Quadrum DigiPlus Manuel utilisateur

LaserLiner

LaserLiner DigiLevel Pro 120 Manuel utilisateur

LaserLiner

LaserLiner AutoCross-Laser ACL 4P RX Manuel utilisateur

LaserLiner

LaserLiner SuperCross-Laser SCL 3 Manuel utilisateur

LaserLiner

LaserLiner Cubus Manuel utilisateur

LaserLiner

LaserLiner DigiLevel Pro 30 Manuel utilisateur

LaserLiner

LaserLiner AutoCross Laser ACL 2 Manuel utilisateur

LaserLiner

LaserLiner ClassicLiner Green 8P Manuel utilisateur

LaserLiner

LaserLiner CompactCross-Laser Manuel utilisateur

LaserLiner

LaserLiner BeamControl-Master Manuel utilisateur

LaserLiner

LaserLiner PrecisionPlane-Laser 4G Pro Manuel utilisateur

LaserLiner

LaserLiner SuperPlane-Laser 3D Manuel utilisateur

LaserLiner

LaserLiner 080.50 Manuel utilisateur

LaserLiner

LaserLiner DigiLevel Laser Manuel utilisateur

LaserLiner

LaserLiner DualAxis-Laser Manuel utilisateur

LaserLiner

LaserLiner SuperSquare-Laser Manuel utilisateur

LaserLiner

LaserLiner EasyCross-Laser Manuel utilisateur

LaserLiner

LaserLiner PowerPlane-Laser 3D Manuel utilisateur

LaserLiner

LaserLiner Centurium Express Manuel utilisateur

LaserLiner

LaserLiner SuperCross-Laser 2P Manuel utilisateur

LaserLiner

LaserLiner SuperCross-Laser 2 Manuel utilisateur

LaserLiner

LaserLiner SmartLine-Laser G360 Manuel utilisateur

LaserLiner

LaserLiner X2-Laser Manuel utilisateur

Manuels Niveau laser populaires d'autres marques

Nedo

Nedo ET-5 Manuel utilisateur

geo-FENNEL

geo-FENNEL Maxi-Liner FL 65 HP Manuel utilisateur

Spectra

Spectra LL300N Manuel utilisateur

geo-FENNEL

geo-FENNEL Selection PRO FLG 40-PowerCross GREEN SP Manuel utilisateur

Nedo

Nedo Crossliner 4 Manuel utilisateur

Lasertec

Lasertec FX360G Manuel utilisateur

Flex

Flex ALC 8 Manuel utilisateur

Black & Decker

Black & Decker LZR5 Manuel utilisateur

Johnson

Johnson 40-6692 Manuel utilisateur

Cocraft

Cocraft HL 20-SG Manuel utilisateur

Zircon

Zircon iLine Manuel utilisateur

HWH

HWH 310 SERIES Manuel utilisateur

Leica

Leica iCON robot 60 Manuel utilisateur

DeWalt

DeWalt DW082 Manuel utilisateur

imex

imex EL20 Manuel utilisateur

Fixturlaser

Fixturlaser NXA D I-0912 Manuel utilisateur

Wacker Neuson

Wacker Neuson PAL450 Manuel utilisateur

Metrica

Metrica 33806 Manuel utilisateur
