Larson Electronics HL-85-LED-CPR-30-TRP Manuel utilisateur

HL-85-LED-CPR-30-TRP

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

1of 2

36W LED Spotlight

10 Million Candlepower - Pistol Grip - 3200 Lumens - 30' Cord w/

Trailer Plug

Instruction Manual

Thank you for your purchase of the Larson Electronics HL-85-LED-CPR-30-TRP.

WARNING:

READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.

CRITICAL SAFETY INSTRUCTIONS:

•INSTALLATION SHOULD ONLY BECONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY

RELEVANT LOCAL BUILDING CODES.

•RISK OFFIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL

SYSTEMS. IFNOTQUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.

•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.

•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.

•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP

OBJECTS. SUITABLE FOR DAMP LOCATIONS.

)IMPORTANT

READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE

REFERENCE. THE HL-85-LED-CPR-30-TRP MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL

CODE AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.

WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS

PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,

CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.

WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE

INSTALLATION OR PERFORMING ANY MAINTENANCE.

RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.

RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.

RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.

To begin operating the spotlight, plug in the cigarette adapter to any 12-24V DC

power outlet. Each unit is configured for either 12 volts or 24 volts DC. The 12

volt models can be plugged into 12 volt DC power supplies, which most

consumer vehicles operate on. The 24 volt models can be plugged into a 24

volt DC power supply, generally for military and heavy equipment.

Once plugged in, simply press the button to activate and deactivate the light.

Power transformers (DCP-11-DP) can be purchased through our website to run

this halogen spotlight from household wall outlets.

The HL-85-LED-CPR Spotlight is IP67 Waterproof, dustproof, shock proof, impact and vibration resistant.

Safety Warnings

For personal safety, always follow the safety instructions in this manual to ensure safe and long- term use. Failing to

do so can result in damage to the product or serious bodily injury

HL-85-LED-CPR-30-TRP

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

2of 2

Warnings

To prevent serious damage to eyesight, never look into spotlight when light is on. DO NOT shine light into the face of someone else.

DO NOT touch lensof spotlight whenlight is on or if it was recently on. The lens will be hot and could cause serious burns. DO NOT allow

children to handle or operate this light. DO NOT use this product for other than its intended use. DO NOT operate in close

proximity of Combustible or flammable materials. DONOTattempttooperate thislight if cord, plug, battery, bulb or any part of the light is

damaged or corroded. DO NOT leave the light facing down while light is on, this could start a fire.

For info on warranty and returns please visit our website: www.Larsonelectronics.com

MAINTENANCE

There are no serviceable parts inside the fixture. However, it is good practice to routinely clean and check the

fixture for proper function.

•Disconnect power running to the lamp and be sure the fixture is cool to the touch.

•Use a non-abrasive glass cleaning solution to clean the lens.

Note: It is not necessary to open the fixture and clean or touch the LED’s.

USE AND CARE

Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.

Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of

children when not in use.Inspect for good working condition prior to storage and before re-use.

REPLACEMENT PARTS

The HL-85-LED-CPR-30-TRP is designed to provide years of reliable performance. Should the need for replacement

parts arise, please contact Larson Electronics.

THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.

SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT

SALES@LARSONELECTRONICS.COM OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.

PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
