513-1417H-AL FAQS

The links below will work in most PDF viewers and link to the topic area by clicking

the link. We recommend Adobe Reader version 10 or greater available at:

http://get.adobe.com/reader

CONTENTS

513-1417H-AL FAQS.......................................................................................................... 1

Batteries ................................................................................................................................ 1

Atomic Clock Factory Restart......................................................................................... 2

Atomic clock ......................................................................................................................... 2

Power Requirements .......................................................................................................... 2

12-Hour time format.......................................................................................................... 2

Fahrenheit/Celsius.............................................................................................................. 2

HI | LO Records................................................................................................................... 2

Dashes, HH.H, LL.L or stuck Indoor Temperature | Humidity.................................... 2

Inaccurate Indoor Temperature Reading........................................................................ 3

Set Time Alarm.................................................................................................................... 3

Activate/Deactivate time alarm........................................................................................ 3

Snooze Alarm ...................................................................................................................... 3

Manually Set Time/Date: Program Menu ...................................................................... 3

Does the clock have a backlight?..................................................................................... 5

Time is off by hours............................................................................................................ 5

Daylight Saving Time......................................................................................................... 5

Atomic clock is dim............................................................................................................. 5

Atomic clock has distorted or frozen display.................................................................. 5

Atomic clock is blank: No letters, numbers or dashed lines ....................................... 6

Atomic clock drains batteries quickly.............................................................................. 6

Atomic clock has missing segments................................................................................ 6

Batteries

Explanation: Many problems are resolved with fresh batteries of the appropriate

voltage. Many items sent in under warranty, work when tested with fresh batteries.

Batteries manufactured this year will have an expiration date 10 years (or more) in

the future. Battery technology has improved and batteries will maintain voltage

longer in storage. However, the environment the batteries reside in for the 10 years

can deplete the power.

A minimum voltage of 1.48V for each battery is necessary for proper

performance.

La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 2

Use batteries dated at least six years in advance of the current year. Batteries

dated earlier than six years from now may still work, but may be unstable in

performance.

Good name brand batteries make less noise, which reduces the chance of RF

(radio frequency) interference from the battery compartment.

Atomic Clock Factory Restart

Explanation: The factory restart returns the atomic clock and remote sensor to an

“out-of-the-box” default state and often resolves an issue.

Factory Restart:

1. Remove batteries from atomic clock.

2. Press one of the buttons on the atomic clock at least 20 times to clear all

memory.

3. Verify that the atomic clock is blank before proceeding (there may be lines

painted on the screen that will show when there is no power).

4. Leave clock without power for 15 minutes (very important).

5. Install fresh batteries in the atomic clock.

Atomic clock

Power Requirements

2-AA alkaline batteries may be used.

12-Hour time format

Time can display in 12-hour only

Fahrenheit/Celsius

Use the program menu to switch between Fahrenheit and Celsius.

HI | LO Records

Explanation: The atomic clock shows the daily HI | LO temperature and humidity

records each day starting at midnight (12:00 AM). The atomic clock automatically

resets the HI | LO records at midnight (12:00 AM).

•Press and release the PLUS button to view the HI temperature, than Humidity

record.

•Press and release the MINUS button to view the LO temperature, than Humidity

record.

Dashes, HH.H, LL.L or stuck Indoor Temperature | Humidity

Explanation: These symbols are error messages indication the indoor sensor is

outside of its readable range. For indoor readings, this is generally a power related

issue.

La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 3

Batteries may be overpowered or underpowered. Remove batteries from the

atomic clock.

Press any button 20 times. Leave the atomic clock unpowered for 1-2 hours.

Install fresh Alkaline batteries with correct polarity.

If the indoor temperature is still shows dashes, HH.H or LL.L, the atomic clock

may need replacement.

Inaccurate Indoor Temperature Reading

Explanation: When the indoor temperature is inaccurate, it is often due to the

location of the display or overpowered/under powered batteries. You can test the

accuracy at you home.

Side-by-side test: Bring the remote sensor in the house and place it next to the

atomic clock for 2 hours.

Compare indoor and remote temperature. The temperature should be within 4

degrees to be within tolerance.

Look for heat sources such as sunlight, door or window frames or reflected heat

or cold near the atomic clock.

Set Time Alarm

Hold the ALARM button for 5 seconds to enter the alarm setting mode.

1. The alarm hour digit will flash in the time display.

2. Press and release the + or - buttons to select the hour.

3. Press and release the ALARM button to set the minutes.

4. The minute digits will flash.

5. Press and release the + or - buttons to adjust the minutes.

6. Confirm with the ALARM button and exit.

Activate/Deactivate time alarm

Press and release the ALARM button once to show alarm time.

Press and release the ALARM button to activate/deactivate the Alarm.

The bell icon will disappear when the alarm is no longer active.

Snooze Alarm

When the alarm sounds, press the LIGHT button to trigger snooze alarm for 10

minutes. The snooze icon will flash when the snooze feature is active.

To stop alarm for one day, press ALARM button, while in snooze mode. The bell

icon will remain solid.

Note: When the alarm sounds, it continues for 2 minutes and then shuts off

completely.

Manually Set Time/Date: Program Menu

1. Hold the SETTINGS button to enter settings mode.

2. Press the +or -buttons to adjust the values.

3. Press the SETTINGS button to confirm adjustments and move to the next item.

La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 4

Setting order:

1. Language: English | Español

2. Beep ON | OFF

3. Atomic ON | OFF

4. Time Zone

5. DST ON | OFF (Daylight Saving Time)

6. Hour

7. Minutes

8. Year

9. Month

10. Date

11. Fahrenheit | Celsius

1. Hold the SETTINGS button for 5 seconds.

2. ENGLISH will flash.

3. Press and release the + or - buttons to select Español.

4. Confirm with the SETTINGS button and select beep ON | OFF

5. BEEP and ON will flash.

6. Press and release the + or - buttons to turn this feature OFF.

7. Confirm with the SETTINGS button and select atomic time ON | OFF.

8. ATOMIC and ON will flash.

9. Press and release the + or - buttons to turn this feature OFF.

10.Confirm with the SETTINGS button and select Time Zone.

11.ZONE-EST will flash.

12.Press and release the + or - buttons to change time zones.

13.Confirm with the SETTINGS button and select DST (Daylight Saving Time) ON |

OFF.

14.DST and ON will flash.

15.Press and release the + or - buttons to turn this feature OFF.

16.Confirm with the SETTINGS button and move to the hour.

17.The hour digit will flash.

18.Press and release the + or - buttons to select the hour.

19.Press and release the SETTINGS button to set the minutes.

20.The minute digits will flash.

21.Press and release the + or - buttons to adjust minutes.

22.Confirm with the SETTINGS button and select the year.

23.The year will flash.

24.Press and release the + or - buttons to set the year.

25.Press the SETTINGS button again to confirm and to enter the month setting.

26.The month will flash.

27.Press and release the + or - buttons to set the month.

28.Press the SETTINGS button again to confirm and enter the date setting.

29.The date will flash. (Day of the week will set automatically)

30.Press and release the + or - buttons to set the date.

31.Confirm all calendar settings with the SETTINGS button and select

Fahrenheit/Celsius.

32.°F will flash.

33.Press and release the + or - buttons to select Celsius.

34.Confirm with the SETTINGS button and exit.

La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 5

Does the clock have a backlight?

No, as this clock is battery operated there is no backlight.

Time is off by hours

Check to see if the WWVB Tower icon appears on the atomic digital clock. If not,

the digital clock has not received a WWVB time signal in the past 24 hours.

Reposition the digital clock with the front or back facing Colorado.

Check that the Time Zone selected correctly reflects your location. Adjust the

time zone in the Program Menu.

Check that the DST indicator is correct for your location (On this clock, please

change the DST setting to OFF unless you live in Arizona). Adjust the DST

indicator in the Program Menu.

Large buildings, metal roofed buildings and buildings or rooms full of electrical

and/or radio equipment make it difficult to receive the WWVB time signal.

Daylight Saving Time

Dependent on your location, position of the clock in your home, and atmospheric

interference, it may take up to 5 nights for the change from Daylight Savings

Time to Standard Time and vice-versa to occur.

Check for a WWVB Tower Icon showing on the atomic digital clock. The tower

icon indicates you have received the WWVB signal from Ft Collins CO in the past

24 hours.

Check that the clock is in the correct Time Zone.

Check whether the DST indicator is ON or OFF. On this clock, please change the

DST setting to OFF unless you live in Arizona.

Check for fresh batteries. Without proper batteries, the antenna will have a

harder time picking up the signal.

Position the digital clock in a window (with the front or back) facing Ft. Collins,

Colorado and leave for up to five nights. If you do not have a window facing this

direction, position the clock near an outside wall and point the unit in this

general direction.

Atomic clock is dim

Explanation: Most atomic clocks have a dark background. Place the atomic clock

at eye level, to determine if it is dim. Atomic clocks that sit in the sunlight can

develop a cloudy film over time.

This is generally a power related issue.

Batteries may be overpowered or underpowered. Remove batteries from atomic

clock.

Press any button 20 times. Leave the atomic clock unpowered for 1-2 hours.

Install fresh alkaline batteries with correct polarity.

Atomic clock has distorted or frozen display

Explanation: On a brand new atomic clock, check for thin plastic film of printed

scratch guard that may be on the screen of the atomic clock. This thin piece of

plastic has printed numbers for store displays. When the batteries are installed, the

“real” numbers show behind the printed scratch guard and create distortion.

With all power removed, the atomic clock should be blank.

La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 6

If numbers still appear, please check for scratch guard.

Power:

Check that the batteries are installed correctly.

This is generally a power related issue.

Batteries may be overpowered or underpowered.

Remove batteries from atomic clock.

Press any button 20 times. Leave the batteries out of the display for 2 hours.

Insert batteries into the atomic clock.

Atomic clock is blank: No letters, numbers or dashed lines

Check that the batteries are installed correctly.

Batteries may be overpowered or underpowered.

Remove batteries from atomic clock.

Press any button 20 times. Leave the batteries out of the display for 2 hours.

Insert batteries into the atomic clock.

Atomic clock drains batteries quickly

Test a new set of alkaline batteries. Write down the date of installation and the

voltage of the batteries.

When the batteries fail, please note the date and voltage again. This is helpful in

determining the problem.

Check for leaking batteries, which may damage the atomic clock.

Atomic clock has missing segments

Explanation: When parts of numbers, letters, or pictures are missing on the

display, it is often power related.

Batteries may be overpowered or underpowered. Remove batteries from atomic

clock.

Press any button 20 times. Leave the atomic clock unpowered for 1-2 hours.

Install fresh alkaline batteries with correct polarity.

Table des matières

Autres manuels La Crosse Technology Horloge

La Crosse Technology

La Crosse Technology BBB84022 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8256-AL Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-8029U Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-8100 Fiche technique

La Crosse Technology

La Crosse Technology WS-8007CTWC Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-3942 Manuel utilisateur

La Crosse Technology

La Crosse Technology 513-1417v6 Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-3051B Manuel utilisateur

La Crosse Technology

La Crosse Technology 433-3833 Manuel utilisateur

La Crosse Technology

La Crosse Technology BBB87733 Manuel d'utilisation et d'entretien

La Crosse Technology

La Crosse Technology WS-8117U-IT Manuel utilisateur

La Crosse Technology

La Crosse Technology 513-1429THV2 Dimensions

La Crosse Technology

La Crosse Technology W86111V2 Manuel utilisateur

La Crosse Technology

La Crosse Technology W86111V2 Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-5120 433 Manuel utilisateur

La Crosse Technology

La Crosse Technology Radio Controlled Analog Clock WT-3181bz Manuel utilisateur

La Crosse Technology

La Crosse Technology WT-8112U Manuel utilisateur

La Crosse Technology

La Crosse Technology W86111V2 Manuel utilisateur

La Crosse Technology

La Crosse Technology 102819 Manuel utilisateur

La Crosse Technology

La Crosse Technology 513-1919 Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8115U Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-1235UA-SS Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-3840TX Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-3229A Manuel utilisateur

Manuels Horloge populaires d'autres marques

Silicon Laboratories

Silicon Laboratories SI5324 Manuel utilisateur

Heathkit

Heathkit GC-1005 Manuel utilisateur

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manuel utilisateur

Andrew O'Malley

Andrew O'Malley DOTKLOK Manuel utilisateur

ALGE-Timing

ALGE-Timing ASC3 Manuel utilisateur

Bodet

Bodet Profil 960 Manuel utilisateur

Nixie Clock

Nixie Clock Divergence Meter Manuel utilisateur

Mini Gadgets

Mini Gadgets MCPro Manuel utilisateur

Casio

Casio TMR-200 Manuel utilisateur

Progetti

Progetti ILTEMPOSTRINGE Manuel

BVItech

BVItech BV-101 Manuel utilisateur

Progetti

Progetti KALIMERO Manuel

Sharp

Sharp SPC900 Manuel utilisateur

Datexx

Datexx DF0063 Manuel utilisateur

LG LEC-005 Manuel utilisateur

IKEA

IKEA ROTBLÖTA Manuel utilisateur

U-Line

U-Line Н-2811 Manuel utilisateur

Digiview

Digiview RC305EL Manuel utilisateur
