Kyocera ECOSYS PA6000x Manuel utilisateur

2022.5 3VC0T5611001

Pull the Cassette 1 completely out

of the machine.

123

2Adjust the paper length and width guide to the

paper size required.

Fan the paper, then tap

it on a level surface.

Load paper.

4Gently push the Cassette 1 back in.

Step 3 Loading Paper

+ Set print side face-up.

+ No bent or folder edges in the paper.

Such paper may cause paper jams.

+ Set the quantity of the paper less than

the maximum paper indication on the

side or the cassette.

+ If the paper is loaded without adj

usting the paper length guide and the pa

per width guides, skewed paper feeding,

and a paper jam will occur.

Step 2 Install Waste toner box

Open the top cover. After Removing the packing material,

shake and install the toner container. Close the top cover.

567

(for inch models)

Open the Box. Remove the machine carefully from the box

grasping both sides.

Lift the main unit from the handles by cardboard handles.

Step 1 Setting up the Printer

Recommended Installation Space

*1: The value when an optional rear tray (PT-320) is installed to the the ECOSYS PA5000x,

ECOSYS PA5500x and ECOSYS PA6000.

100 mm

(3.94")

300 mm

(11.81")

400 mm

(15.75")

400 mm

(15.75")

500 mm (19.69")

200 mm (7.87")

500 mm (19.69") *1

Installation Environment

Kyocera Recommends selecting the Location for the printer as follows:

1. Room Temperature range: 50 to 90.5°F

2. Humidity Level: 10 to 80%

3. Power:

Avoid the following locations when selecting a site for the machine.

Adverse environmental conditions may affect the image quality.

+ Avoid locations near a window or with exposure to direct sunlight.

+ Avoid locations with vibrations.

+ Avoid locations with rapid temperature fluctuations.

+ Avoid locations with direct exposure to hot or cold air.

+ Avoid poorly ventilated locations.

3VC0T5611001

Setup GuideECOSYS PA6000x / ECOSYS PA5500x

ECOSYS PA5000x / ECOSYS PA4500x

A dedicated 120VAC 60Hz 15A outlet

A dedicated 200-240VAC 50/60Hz 15A outlet

120 V Specification Model:

230 V Specification Model:

Step 7 Installing Software

Access the following URL and select your model and OS.

Download Center: https://kyocera.info/

For Windows

Download and run the Web Installer and follow the

on-screen instructions to install the driver and software.

For Mac

Download and run the driver and follow the on-screen

instructions to install.

Report Print:

Exit

Menu Map

Yes No

Print.

Are you sure?

Status Page

[▲] [▼] key > [Status Page] > [OK] key > [Yes]

Status Page

Config. List

Menu:

Report:

Report Print

Exit

Job Log History

Report

USB Drive

Counter

Exit

[Menu] key > [▲] [▼] key > [Report] >

[OK] key > [▲] [▼] key > [Report Print] > [OK] key

Step 6 Printing a Status Page

Step 4 Powering on the Printer

Turn the power switch ON at the front of the printer.

Connect the power cord to the rear of the machine and the

other end to the power outlet.

NOTE

Prepare the device and

information according to

the your environment.

For details of the network

settings, refer to the

Operation Guide.

6When the following screen

appears, select [Finish].

Completing Setup

Please read the [Read

me] to make more

detail settings.

Readme Finish

5Select [Change] when you set whether

notify low toner via panel or not.

If you set it later, select [Skip].

Skip

Setup (3/3)

Set whether norify

low toner via

Paner or not.

Change

Skip

Setup (1/3)

Set the time zone,

date and time.

Change

Select [Change] when you

change the time zone, date

and time. Follow the instruc

tions on the screen. If not,

select [Skip].

The setup screen appears.

2Select [Yes].

Welcom.

Set up your machine

now.

Are your sure?

Yes No

Language:

English

Deutsch

Français

Press [◀] [▶] key to select

default language > [OK] key.

Step 5 Default Settings of the Machine

The screen moves to the

next step.

The screen moves to the next

setp.

Select [Change] when you

set the IP address to use

the machine on the network.

Follow the instructions on the

screen. If you set it later,

select [Skip].

Skip

Setup (2/3)

Set the IP address to

enable the machine to

run on your network.

Change
