USER MANUAL

Model:

VS-1616D

16x16 Digital Matrix Switcher

Contents

1Introduction 1

2Getting Started 2

2.1 Quick Start 2

3Overview 4

3.1 Recommendations for Best Performance 5

3.2 Safety Instructions 5

3.1 Shielded Twisted Pair/Unshielded Twisted Pair 5

3.2 About the Power Connect™ Feature 6

3.3 Recycling Kramer Products 6

4Defining the VS-1616D 16x16 Digital Matrix Switcher 6

4.1 Using the IR Transmitter 10

5Installing the VS-1616D in a Rack 11

6Connecting the VS-1616D 16x16 Digital Matrix Switcher 12

6.1 Port Numbering 13

6.1.1 EDID Numbering Examples 14

6.2 Serial Data Flow on DGKat Plus RS-232 Cards 14

6.3 Audio Mode Selection on HDMI plus Audio Cards 15

6.4Connecting to the VS-1616D via RS-232 15

6.5 Connecting to the VS-1616D via Ethernet 16

6.5.1 Connecting the Ethernet Port directly to a PC 16

6.5.2 Connecting to the Ethernet Port via a Network Switch/Hub 18

7Operating Your Video Matrix Switcher 19

7.1 Startup Display 19

7.1.1 Viewing the Display 20

7.2 Using the Selector Buttons 20

7.3 Confirming Actions 20

7.3.1 Toggling between the At Once and Confirm Modes 21

7.3.2 Confirming a Switching Action 21

7.4 Switching Actions 21

7.4.1 Switching one Input to one Output 22

7.4.2 Switching Several Inputs to Several Outputs 22

7.4.3 Turning an Output Off 23

7.4.4 Turning Off Several Outputs 23

7.4.5 Recalling the Default Setup 23

7.5 Locking the Front Panel Buttons 24

8Using the Configuration Menus 24

8.1 Using the Setup Menu 26

8.1.1 Setup Menu—1: inXX=>ALL, Switching one Input to all Outputs 26

8.1.2 Setup Menu—3: outXX=>OFF, Turning an Output Off 26

8.1.3 Setup Menu—7: EDID, Assignment to an Input 27

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

8.1.4Setup Menu—9: Delay, Setting for an Output 28

8.1.5 Setup Menu—4: store setup XX, Storing the Setup in a Preset 28

8.1.6 Setup Menu—6: recall setup XX, Recalling a Preset 29

8.2 Using the Config Menu 29

8.2.1 Config Menu—Input Signal Detection Display 30

8.2.2Config Menu—Input Port Parameter Setting 31

8.2.3 Config Menu—Output Load Detection Display 33

8.2.4 Config Menu—Output Port Parameter Setting 34

8.2.5 Config Menu—Interface Configuration 36

8.2.6 Config Menu—Interface Reply Configuration 36

8.2.7 Config Menu—Protocol Switching 37

8.2.8 Config Menu—Store Default Setup 37

8.2.9 Config Menu—Total Matrix Reset 38

8.2.10 Config Menu—Display Firmware Versions 39

9Configuring the Number of Installed Input and Output Ports 39

10 Installing and Using the Test Module to Troubleshoot Video Problems 40

10.1 Installing the Test Module 40

10.2 Setting the Resolution of the Generated Video 40

10.3 Setting the Pattern of the Generated Video 41

10.4 Using the Test Module to Troubleshoot Video Problems 41

10.4.1 Testing the Projector Output 42

10.4.2 Testing the Output Signal Path to the Projector 42

10.4.3 Testing the Input and Output Signal Path to the Projector 43

11 I/O Card Hardware Installation Instructions 43

12 Upgrading the VS-1616D Firmware 44

13 Technical Specifications 45

14 Default Communication Parameters 47

15 Factory Default EDID 47

15.1 DVI Input Card 47

15.2 HDCP Input Card 48

15.3 HDMI Input Card 50

15.4 HDMI plus Audio Input Card 52

15.5 DVI Dual Channel Input Card 53

15.6 DGKat Input Card 55

15.7 HDBaseT Input Card 57

15.8 VGA Input Card 59

16 Communication Protocols 60

16.1 Protocol 3000 60

16.1.1 Kramer Protocol 3000 Syntax 60

16.1.2 Device Message Format 60

16.1.3 Command Terms 61

16.1.4 Entering Commands 61

16.1.5 Command Forms 62

Contents

iii

16.1.6 Chaining Commands 62

16.1.7 Maximum String Length 62

16.1.8 Table of Protocol 3000 Commands 62

16.2 Protocol 2000 63

Figures

Figure 1: VS-1616D 16x16 Digital Matrix Switcher Front Panel 7

Figure 2: VS-1616D Front Panel Numeric Keypad 8

Figure 3: VS-1616D 16x16 Digital Matrix Switcher Rear Panel Showing DVI cards 9

Figure 4: Connecting the VS-1616D 12

Figure 5: Sample Port Numbering 13

Figure 6: EDID Numbering Assignment 14

Figure 7: DGKat Card Serial Data Transmission 15

Figure 8: Audio Mode Selection on HDMI plus Audio Cards 15

Figure 9: Local Area Connection Properties Window 17

Figure 10: Internet Protocol (TCP/IP) Properties Window 18

Figure 11: Default Startup Status Display Sequence 19

Figure 12: Menu Tree 25

Figure 13: Resolution DIP-switch 41

Figure 14: Signal Paths for Isolating problems 42

Figure 15: Inserting the Card into a Slot 43

Figure 16: Card Handles 44

Tables

Table 1: VS-1616D 16x16 Digital Matrix Switcher Front Panel Features 8

Table 2: VS-1616D Front Panel Numeric Keypad Labels 8

Table 3: VS-1616D 16x16 Digital Matrix Switcher Rear Panel Features 10

Table 4: Port Numbering 13

Table 5: EDID Configuration Requests and Results 14

Table 6: Audio Mode DIP-switch Operation 15

Table 7: Available PC Resolutions for Generated Video (Jumper off) 41

Table 8: Available HD Resolutions for Generated Video (Jumper on, default) 41

Table 9: Technical Specifications of the 16x16 Digital Matrix Switcher 45

Table 10: Technical Specifications of VS-1616D Compatible Cards 46

Table 11: Default Communication Parameters for the VS-1616D 47

Table 12: Hex Table (IN 1-16 to OUT 1-16) 63

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 1,000-plus different models now

appear in 11 groups1

Congratulations on purchasing your Kramer VS-1616D 16x16 Digital Matrix

Switcher. This product is ideal for the following typical applications:

that are clearly defined by function.

•Professional display systems requiring video signal routing

•Broadcast, presentation and production facilities, as well as monitoring in

large duplication systems

•Rental/staging applications

The package includes the following items:

•VS-1616D 16x16 Digital Matrix Switcher

•Power cord

•Kramer RC-IR3infrared remote control transmitter (including the required

batteries and a separate user manual2)

•This user manual2

Note: Throughout this user manual the chassis configuration is shown with 16 DVI

inputs and 16 DVI outputs as a representation only. The following cards are

available and may be mixed in the same chassis:

•DVI

•DVI dual link

•DVI (HDCP)

•DVI (over 4LC fiber optic cable)

•DVI (over fiber optic cable) with 670 module (HDCP)

•HDMI (HDCP)

•HDMI plus analog audio (HDCP)

•HDMI plus digital audio (HDCP)

•HDMI plus RS-232 (HDCP)

•HDBaseT plus IR and RS-232 plus Ethernet

•VGA

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers; GROUP 3: Control Systems; GROUP 4: Format/Standards

Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7: Scan Converters and Scalers;

GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra

Products

2 Download up-to-date Kramer user manuals from http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

2.1 Quick Start

The following quick start chart summarizes the basic setup and operation steps.

Getting Started

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3 Overview

The Kramer VS-1616D is a high performance matrix switcher chassis that supports

up to 16 x 16 ports1for various signals (depending on the type of cards installed).

It features a very high bandwidth2

The VS-1616D is highly configurable–you can add or remove inputs and outputs

independently in groups of two and mix different types of input/ouput cards in the

same chassis. For example, you can configure a device as a 4 x 12 or a 16 x 8

matrix switcher to exactly suit your needs.

of up to 3.2Gbps (for the chassis only, effective

bandwidth of the system depends on the I/O cards) that ensures transparent

performance even in the most critical applications. The cards re-clock and equalize

the signals and the chassis can route any or all inputs to any or all outputs

simultaneously.

The VS-1616D features:

•Full 16 x 16 non-blocking matrix array to switch any of the 16 input digital

signals to any or all outputs (see Section 6

•Easy access to 59 preset memory locations for quick access to user-defined

setups

)

•The Kramer 2000 Protocol for serial control

•A 40 character by 2 line LCD that shows the operational status or the

configuration menu

•A lock function to prevent tampering with the front panel

•A default EDID (Extended Display Identification Data) for each input

•I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID

handling and processing algorithm ensures plug and play operation for DVI

systems

•Non-volatile EDID storage

•Kramer Core™—flexible infrastructure conversion. Copper, fiber or

Twisted Pair, all can be used at the same time according to input/output

module selection. The matrix receives signals from compatible Kramer

transmitters, automatically converts between available infrastructure options

and sends the signals to compatible Kramer receivers

•Equalization and re-clocking on all card types

You can operate the VS-1616D via the front panel buttons3

•RS-232 serial commands transmitted by a touch screen system, PC or other

serial controller

or remotely via:

1 Can also be configured for other sizes (up to a maximum of 16 x 16)

2 For maximum bandwidth supported by each type of card see the Technical Specifications in Section 13

3 The VS-1616D is a sophisticated device but has been designed to be as simple as possible to operate. Due to space limitations on the

front panel 32 input/output selector buttons are instead substituted by a keypad. For details of how to route inputs to outputs, see

Section 7.2

Overview

•Ethernet over a LAN

•The infrared remote control transmitter

The VS-1616D is housed in a 19" rack-mountable enclosure.

To achieve the best performance:

•Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables)

•Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer VS-1616D in a

location free from moisture and away from excessive sunlight and dust

3.1 Recommendations for Best Performance

To achieve the best performance:

•Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighboring electrical appliances and position your

VS-1616D away from moisture, excessive sunlight and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

3.2 Safety Instructions

Caution: No operator serviceable parts inside the unit

Warning: You use only the power cord that is supplied with the

unit. Do not open the unit. High voltages can cause

electrical shock! Servicing by qualified personnel only.

Warning: Disconnect the power and unplug the unit from the wall

before installing

3.1 Shielded Twisted Pair/Unshielded Twisted Pair

Kramer engineers have developed special twisted pair cables to best match our

digital twisted pair products; Kramer's BC-DGKat524, BC-DGKat623 and

BC-DGKat7a23 shielded twisted pair (STP) cables. These specially built cables

significantly outperform regular CAT 6 and CAT 7a cables.

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Defining the VS-1616D 16x16 Digital Matrix Switcher

3.2 About the Power Connect™ Feature

The Power Connect™ feature here means that the VS-1616D can supply power to

the TP transmitters and receivers (for example, the PT-573 and PT-574) as long as

the devices are within 90m (270ft) of each other. The Power Connect™ feature

applies as long as the cable can carry power and the distance does not exceed 90m

on standard CAT 5 cable. For longer distances heavier gauge cable should be

used1

3.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

4 Defining the VS-1616D 16x16 Digital Matrix Switcher

Figure 1, Table 1, Figure 2and Table 2define the front panel of the VS-1616D.

1 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances

Autres manuels pour VS-1616D

Table des matières

Autres manuels Kramer Commutateur matriciel

Kramer

Kramer 3216HDEE Manuel utilisateur

Kramer

Kramer Sierra Video 3232V3 Manuel utilisateur

Kramer

Kramer Sierra Video 1616V5 Manuel utilisateur

Kramer

Kramer 1616DEE Manuel utilisateur

Kramer

Kramer 3232DS Manuel utilisateur

Kramer

Kramer Sierra Video 3232V5S Manuel utilisateur

Kramer

Kramer VS-1616D-MD Manuel utilisateur

Kramer

Kramer VS-44UHDA Manuel utilisateur

Kramer

Kramer VP-8x4 Manuel utilisateur

Kramer

Kramer VS-62HA Manuel utilisateur

Kramer

Kramer VP-8x8 Manuel utilisateur

Kramer

Kramer Sierra Video 3232V3S Manuel utilisateur

Kramer

Kramer 88V3 Manuel utilisateur

Kramer

Kramer VP-773A Manuel utilisateur

Kramer

Kramer Sierra Video 6432V5Sxl Manuel utilisateur

Kramer

Kramer VS-88DVI Manuel utilisateur

Kramer

Kramer VP-8x8 Manuel utilisateur

Kramer

Kramer VS-84HN Manuel utilisateur

Kramer

Kramer MTX3-16-M Manuel utilisateur

Kramer

Kramer VS-806YC Manuel utilisateur

Kramer

Kramer 88DEE Manuel utilisateur

Kramer

Kramer Sierra Pro XL 1616V3 Manuel utilisateur

Kramer

Kramer Sierra Pro XL 1608V3 Manuel utilisateur

Kramer

Kramer Sierra Video 6448V5xl Manuel utilisateur

Manuels Commutateur matriciel populaires d'autres marques

Broadcast Tools

Broadcast Tools SS 8.2 Manuel utilisateur

Altimium

Altimium MATF32 Manuel utilisateur

ALFAtron

ALFAtron ALF-MUK44N Manuel utilisateur

Monoprice

Monoprice Blackbird 15377 Manuel utilisateur

PTN

PTN FMX12 Manuel utilisateur

CYP

CYP nT15GX01 Manuel utilisateur

TESmart

TESmart HMA0402A40 Manuel utilisateur

Octava

Octava HD4XSTPMX Manuel utilisateur

Intelix

Intelix FLX-88 Mode d'emploi

Roland

Roland XS-1HD Manuel utilisateur

Atlona

Atlona AT-HDMI-22M Manuel utilisateur

Link

Link HD8X8 Manuel utilisateur

AMX

AMX AVS-OP-2020-117 Instructions et recettes

Lindy

Lindy 38042 Manuel utilisateur

Extron electronics

Extron electronics MTPX Plus Series Manuel utilisateur

Key Digital

Key Digital Champion KD-16x16CS Manuel utilisateur

Shinybow USA

Shinybow USA SB-8811 Manuel utilisateur

Optimus

Optimus Compact Manuel utilisateur
