Kramer VS-211H Manuel utilisateur

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VS-211H

Automatic HDMI Standby

Switcher

P/N: 2900-000681 Rev 5

VS-211H – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Defining the VS-211H Automatic HDMI Standby Switcher 5

4Using the VS-211H 6

4.1 Connecting the VS-211H 6

4.2 Selecting the Default Master Source Signal 7

4.3 Connecting the REMOTE Terminal Block Connector 8

5Technical Specifications 9

Figures

Figure 1: VS-211H Automatic HDMI Standby Switcher 5

Figure 2: VS-211H Connections 7

Figure 3: REMOTE Terminal Block Connector 8

VS-211H - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Products.

Congratulations on purchasing your Kramer VS-211H Automatic HDMI Standby

Switcher, which is ideal for providing backup switching for broadcast and post-

production applications.

VS-211H - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer VS-211H away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

VS-211H - Getting Started

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the Kramer Electronics input power wall

adapter that is provided with the unit

Warning:

Disconnect the power and unplug the unit from the wall

before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

VS-211H - Overview

3 Overview

The VS-211H is a high-performance automatic standby switcher for HDMI video

signals. The VS-211H automatically switches to the secondary input whenever the

primary video signal is interrupted. If the primary signal reappears, the unit

automatically switches back to the primary input.

In addition, the VS-211H features:

A maximum data rate of up to 2.25Gbps

HDTV compatibility

HDCP and HDMI compliance

3D pass through

EDID PassThru that passes EDID signals from source to display

A DEFAULT INPUT switch for selecting the default HDMI master source

signal

Contact closure remote control for forced operation

Active switching

VS-211H - Overview

3.1 Defining the VS-211H Automatic HDMI Standby

Switcher

This section defines the VS-211H.

Figure 1: VS-211H Automatic HDMI Standby Switcher

Feature

Function

ACTIVE INPUT 1,2 LEDs

Illuminate when input is active

ON LED

Illuminates when receiving power

OUT HDMI Connector

Connects to the HDMI output acceptor

IN 1 HDMI Connector

Connects to the HDMI input source 1

IN 2 HDMI Connector

Connects to the HDMI input source 2

DEFAULT INPUT Switch

Switches to select the default input (IN 1 or IN 2)

REMOTE IN 1 and IN 2 Terminal

Block Connectors

Connect to a contact closure switch

5V DC

+5V DC connector for powering the unit

VS-211H - Using the VS-211H

4 Using the VS-211H

This section describes how to:

Connect the VS-211H (see Section 4.1)

Select the default master source signal (see Section 4.2)

Connect the REMOTE connector (see Section 4.3)

4.1 Connecting the VS-211H

Always switch off the power to each device before connecting it to your

VS-211H. After connecting your VS-211H, connect its power and then

switch on the power to each device.

To connect the VS-211H, as illustrated in the example in Figure 2, do the following:

1. Connect the IN 1 HDMI connector to the HDMI input source 1 (for example,

DVD player 1).

2. Connect HDMI input source 2 (for example, DVD player 2) to the IN 2 HDMI

connector.

3. Connect HDMI acceptor (for example, an LCD display) to the OUT HDMI

connector.

4. Set the DEFAULT INPUT switch to whichever input is the master input, as

described in Section 4.2.

5. If needed, connect the remote switches to the REMOTE IN 1 and IN 2

terminal block connectors, as described in Section 4.3.

6. Connect the 5V DC power adapter to the power socket and connect the

adapter to the mains electricity.

VS-211H - Using the VS-211H

Figure 2: VS-211H Connections

4.2 Selecting the Default Master Source Signal

When active input sources are connected to IN 1 and IN 2, the DEFAULT INPUT

switch setting determines the default master input source.

If the master input signal is not detected, the VS-211H automatically activates the

standby input:

If IN 1 is the default input and it fails, IN 2 activates

If IN 2 is the default input and it fails, IN 1 activates

If the master input reactivates while the standby input is active, the unit

automatically switches back to the master input:

If IN 2 is active while IN 1 is the default input, when IN 1 reactivates, it is

switched to the output

If IN 1 is active while IN 2 is the default input, when IN 2 reactivates, it is

switched to the output
